Function Of Major Mechanical Parts - Sharp VC-AA350A Service Manual

VC-AA350A/L/M/W
VC-AA352W,AA360A,AA370A
VC-AA550A/L/W,AA560A,AA570A
3. FUNCTION OF MAJOR MECHANICAL PARTS (TOP VIEW)
1
2
3
7
No.
1 Full erase head
2 Supply pole base ass'y
3 Tension arm
4 Idler wheel ass'y
5 Open guide
6 Supply reel disk
7 Supply main brake
8 Take-up main brake
9 Pinch drive cam
10 A/C head ass'y
17
15 26
6 12
Function
6
18
10
4 13
No. Function
11 Reverse guide lever ass'y
12 Reel relay gear
13 Take-up reel disk
14 Pinch roller lever ass'y
15 Drum ass'y
16 Loading motor block
17 Drum driver motor
18 Take-up pole base ass'y
26 Auto head cleaner ass'y
16
14
9
11
5
8
