Quick Start Guide
USB 2.0 Portable Laptop
Crash Cart KVM Adapter
Model: B032-VU1
The complete Owner's Manual is available on
Tripp Lite's website: www.tripplite.com/support
El manual completo esta disponible en español en la
página de Tripp Lite: www.tripplite.com/support
Le manuel complet est disponible en français sur le
site Web de Tripp Lite : www.tripplite.com/support
Полная русскоязычная версия настоящего руководства
представлена на веб-сайте компании Tripp Lite по
адресу: www.tripplite.com/support
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
1
17-10-489-933694-EN.indd 1
12/4/2017 10:35:45 AM
Advertisement
Table of Contents
Related Manuals for Tripp Lite 8TLB032VU1
Summary of Contents for Tripp Lite 8TLB032VU1
- Page 1 Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a $100 value! www.tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2017 Tripp Lite. All rights reserved. 17-10-489-933694-EN.indd 1 12/4/2017 10:35:45 AM...
-
Page 2: Product Features
Product Features • USB Console Adapter provides direct laptop-to- computer desktop access • Compact design with integrated cables makes it perfect for systems administrators on the move; no need for a bulky crash cart • Supports VGA video resolutions up to 1920 x 1200 @ 60 Hz •... -
Page 3: System Requirements
Product Features • Bus-powered; no external power required • Firmware upgradeable System Requirements • Laptop with an available USB port • Computer with an available VGA or DVI-I (requires a VGA to DVI adapter) monitor port and a USB port •... -
Page 4: Installation
Installation 1. Connect the included USB Mini-B cable between the USB Mini-B port on the unit and an available USB-A port on the laptop. 2. Connect the built-in USB cable to an available USB-A port on the computer you wish to access with the laptop. - Page 5 Installation Remote View Window The Windows client provides a Remote View window with a Control Panel for accessing the connected computer. When the Remote View window opens, the Control Panel is hidden. Access it by moving your mouse pointer over the top center of the screen. The Control Panel includes multiple functions and settings that allow you to manage and control your connection.
-
Page 6: Control Panel
Control Panel Icon Description Capture – Click to take a snapshot of the remote display. The snapshot image is saved in a directory selected in the Configure Panel screen of the Control Panel’s Settings menu. See Section 6.2.7 in the owner’s manual for details. - Page 7 Control Panel Icon Description Mouse Sync Settings – Click to toggle between Automatic and Manual mouse sync. When Automatic syncing is selected, an A will appear on the mouse icon. When manual, an M will appear. Automatic Mouse Sync automatically locks in and syncs the local and remote mouse pointers for you, eliminating the need for any manual resyncing.
-
Page 8: Specifications
Specifications Number of Computer Connections Local Port Connectors USB Mini-B (Female) Computer Port Connectors HD15 (Male), USB-A (Male) Online LED Blue Max Video Resolution 1920 x 1200 @ 60 Hz Operating Temperature 32° to 104°F (0° to 40°C) Range Storage Temperature -4°... - Page 9 Warranty and Product Registration 3-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
- Page 10 Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
- Page 11 Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to: • Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country) •...
