Bosch Smart Home
Light/shutter control unit II
Product description
The product is suitable for controlling shutters,
sun blinds and Venetian blinds. Alternatively,
one or two lamps or other consumers can be
switched on and off independently of each other.
The module measures the power consumption
of connected lamps and consumers.
Description of the symbols
Caution!
Note about hazards
Note:
Additional
important information
Note about the installation video
8-750-002-316
Advertisement
Table of Contents
Related Manuals for Bosch BMCT-SLZ
Summary of Contents for Bosch BMCT-SLZ
- Page 1 Bosch Smart Home 8-750-002-316 Light/shutter control unit II Product description The product is suitable for controlling shutters, sun blinds and Venetian blinds. Alternatively, one or two lamps or other consumers can be switched on and off independently of each other.
-
Page 2: Safety Instructions
Safety instructions ▶ The device is not a toy! Do not allow children to play with it. Never leave the packaging material lying around unattended. Plastic film and small parts may pose a danger to children. ▶ When remotely or automatically controlling a device, it is not always possible to guarantee that commands are actually executed or that the correct device status is displayed in the... - Page 3 shutters / Venetian blinds / sun blinds which are equipped with obstacle detection or for which at least a comparable level of protection with regard to crushing injuries is ensured by means of other design features. Always consult an expert for this assessment and for the installation of any structural safety measures which may be required.
- Page 4 ▶ Only operate the device indoors and do not expose it to moisture, vibrations, constant sunlight or other sources of heat, extreme cold temperatures and mechanical stress. ▶ Only use the device together with original components and recommended products from Bosch partners.
- Page 5 ▶ The device is only intended for private use. You can also use the explanatory video and additional information on our website as an additional aid for mounting, installing, starting up and restoring the factory settings on your Bosch Smart Home light control unit: www.bosch-smarthome.com/rom/ light-shutter-module-2...
- Page 6 Product overview Item Description System button Status LED Terminals The status LED (2) shows the status of the light/ shutter module using flashing codes. Status LED Device status Recommended action Flashes orange Tuning mode (is Please wait active) or device is communicating with the controller Flashes green...
-
Page 7: Notes Regarding Installation
Notes regarding installation The standards and directives applicable in your country must be observed during planning, set-up, operation and maintenance. A 230 volt alternating current power supply is required for this product (there must be a phase and neutral conductor). The product is only intended for fixed installation in in-wall switch boxes with a minimum depth of 50 mm and a screw... - Page 8 The power circuit to which the device and the load are connected must be secured with a circuit breaker in accordance with EN 60898-1 (trigger characteristics B or C, max. 16 A rated current, min. 6 kA breaking capacity, energy limitation class 3). Installation guidelines in accordance with the applicable national standards, e.g.
-
Page 9: Installation
Installation The module can be used to control shutters / sun blinds / Venetian blinds or to control lighting. You must connect the module according to your desired purpose, then link it with the Smart Home controller and configure the purpose (shading or lighting) in the app. - Page 10 Installation/ Configuration as a shading module Before you start: Be sure to shut off the power circuit breaker! Connect the controls in accordance with the connection diagram below: Motor connection diagram Connection Description External conductor Neutral conductor Up switch Down switch Motor up connection Motor down connection...
- Page 11 The end positions of the drive must have already been set up / configured in advance. To do this, follow the instructions on your drive. If the module has not been paired with the Smart Home controller and configured with the shading function, the inputs S1/S2 do not trigger any movement.
- Page 12 Activation/deacti- vation Connection Description External conductor Neutral conductor Switch – Lamp Earth conductor If the module has not been paired with the Smart Home controller and configured with the light control unit function, the inputs S1/S2 do not trigger any switch commands.
- Page 13 Multiway switching Connection Description External conductor Neutral conductor Switch – Lamp Earth conductor You can use the module together with switches. For the device to function correctly, it must be paired with the Smart Home controller and the corresponding configuration must have been carried out in the app.
- Page 14 Connection of 2 lamps Connection Description External conductor Neutral conductor Switch 1 Switch 2 Lamp 1 Lamp 2 Earth conductor If the module is connected correctly, switch the fuse back on.
-
Page 15: Resetting To Factory Settings
Ensure that you have a Bosch Smart Home controller and the Bosch Smart Home app and have successfully configured both. Now start the Bosch Smart Home app and select “Add new device”. Follow the instructions in the app. Once the module has been switched on via the fuse, it is in tuning mode for 3 minutes. -
Page 16: Maintenance And Cleaning
To re-configure the device, first delete it in the device management section of the Bosch Smart Home app and then add it again in the usual configuring process. The module settings, whether it is used for shading or for light, are deleted after the module is reset to factory settings. -
Page 17: Environmental Protection And Disposal
Electronic Equipment). Use your country’s specific return and collection systems when disposing of waste electrical or electronic devices. Open source software This Bosch Smart Home product uses open- source software. License information for the components used can be found in the attached documents. - Page 18 Technical data Device type designation BMCT-SLZ Measurement ± 3 W at < 100 W / precision ±3 % at > 100 W Protection type IP20 Measurement category CAT III Protection class Technical modifications reserved Device protection Thermal cutoff Ambient temperature – 20 °C … + 50 °C Symbol description Dimensions 40.5 × 47 × 22 mm Motors (W × H × D)
