- Page 1 Bosch Smart Home Plug Instruction Manual...
- Page 2 Start making your home smart! Set up your product in just three steps Please be sure to install the Bosch Please ensure that you have a Bosch Smart Home Controller first. Smart Home Controller and the Bosch Smart Home App, and that you have set both of them up successfully.
- Page 3 Dear Customer, Congratulations on purchasing your Bosch Smart Home Plug, it will help to make your home even smarter by connecting electrical appliances to the Bosch Smart Home System. The Bosch Smart Home Plug allows you to easily control electrical appliances from a coffee machine to a lamp conveniently in or away from your home.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1.0 Product description ....08 4.0 The smart plug ......14 6.0 Connecting to your 7.0 Product details ......28 1.1 Intended use ......09 4.1 Product overview ....... 14 electrical appliance ....22 7.1 Technical data ......28 6.1 Connecting instructions ..... -
Page 5: Product Description
The plug turns your electrical applian- Quick to install, the plug is ready to The product may only be used togeth- Bosch Smart Home App to ensure ces smart by enabling you to control use once it has been inserted into a er with original Bosch Smart Home that the product is set up correctly. -
Page 6: In The Box
2.0 IN THE BOX Plug Do not open or modify the product in any way. Any other use is conside- red unintended use. We will not assume liability for any resulting damage. To operate the plug you will require the app, a controller and an internet connection. -
Page 7: Warning Notices
3.0 WARNING NOTICES 3.2 Safety instructions 3.1 Explanation of symbols Warning. Risk of injury even to the point of death from electric shock! This alerts you to danger. Touching live electrical parts can lead to electric shock. ▶ Do not open the product. ▶... -
Page 8: The Smart Plug
4.0 THE SMART PLUG Item Part Explanation 4.1 Product overview Indicator for status or fault Side view System button Confirmation button QR code Scan for device identification LED state Explanation Fault – please contact our service team on 00800 8437 6278 Orange Process or update is being performed Front side... -
Page 9: Set-Up
Start the Bosch Smart Home App and select “Add device”. Please ensure that you have a Bosch Smart Home Controller and the Bosch Smart Home App, and that you have set both of them up successfully. From this point, the app guides you through the installation process. -
Page 10: Connecting To Your Smart Home
5.2 Connecting to your smart home The app will prompt you to scan the From this point, the app guides you through QR code on the product. You will find the installation process. You will find a brief the QR code on the rear of the plug. description in the following pages of this instruction manual. -
Page 11: Configuring The Device
5.3 Configuring the device Scanning the QR code from within the The plug’s LED indicates the status If the device is not able to establish a connection to the controller app starts the configuration process. of the configuration attempt using the within 3 minutes, the configuration mode is ended. -
Page 12: Connecting To Your Electrical Appliance
6.0 CONNECTING TO YOUR ELECTRICAL APPLIANCE 6.1 Connecting instructions Risk of injury even to the point of death from electric shock! Prevailing regulations must be observed when connecting the product. Touching live electrical parts can lead to electric shock. Failure to comply with the regulations can lead to material damage ▶... - Page 13 Ensure the smart plug is not damaged do not plug into socket if the casing is damaged in any way. ▶ Connect the plug to an accessible, ▶ Do not insert plugs in a row. ▶ Do not use plugs in multiple socket grounded wall socket.
-
Page 14: Connecting Process
6.2 Connecting process ▶ Do not use plugs to disconnect appli- ances from the mains. The load is not galvanically isolated from the mains. ▶ Devices with electronic power supply units (e.g. TV or high voltage LED light sources) are no ohmic loads. They can generate inrush currents with more than 100 A. -
Page 15: Product Details
7.0 PRODUCT DETAILS 7.1 Technical data Model Plug AA Power consumption in standby < 0.3 W Article number 8-750-000-295 Max. switching power 3680 W Supply voltage 230 V/50 Hz Load type Ohmic load, cosφ ≥ 0.95 Current consumption 13 A max. - Page 16 Operating type (IEC 60034-1) Radio range in free-field conditions > 100 m IEC protection class 70 mm x 79 mm x 39 mm Dimensions (W x H x D) (without mains plug) Radio frequency band 868,0-868,6 MHz/869,4-869,65 MHz Weight 155 g...
-
Page 17: Declaration Of Conformity
7.2 Declaration of conformity 7.3 Faults in radio operation Hereby, Robert Bosch Smart Home The full text of the EU declaration of Faults in radio operation (e.g. due to Apart from the transmission power GmbH declares that the radio conformity is available at the following... -
Page 18: Open-Source Software
7.4 Open-source software core_cm3.h This Bosch Smart Home product uses open-source software. You will find Copyright (C) 2009-2013 ARM Limited. All rights reserved. Redistribution and the license information for the compo- use in source and binary forms, with or without modification, are permitted nents used on the opposite side. -
Page 19: Environmental Protection And Disposal
7.5 Environmental protection and disposal THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIB- Electrical and electronic equipment To dispose of electrical and electronic UTORS „AS IS“ AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, that is no longer usable and defective equipment or batteries, use your BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY or used batteries must be separated... -
Page 20: Further Information
Before you transfer or sell your device, delete your personal in the online FAQs at information. To do this, reset the device to its factory settings www.bosch-smarthome.com/faq (see online FAQs). - Page 21 #BeSmarter...
- Page 22 INTERCONNECTED SMART HOME PRODUCTS Save on heating costs, protect your valuables, create mood lighting and much more: Bosch Smart Home offers a complete, intelligent system to make your life more comfortable, safer and more sustainable. More at www.bosch-smarthome.com Radiator Thermostat...
- Page 23 Robert Bosch Smart Home GmbH Schockenriedstraße 17 70565 Stuttgart, Germany 00800 8437 6278 (free for UK) Mon–Fri 7:00 a m –8:00 pm 8:00 a m –6:00 pm service@bosch-smarthome.com...
