USER'S GUIDE

9000HD

HIGH-DEFINITION DIGITAL SATELLITE &

TERRESTRIAL RECEIVER

Panarex Electronics

SUN VALLEY, CALIFORNIA, USA

Table of Contents

Summary of Contents for Pansat 9000HD

Page 1 USER’S GUIDE 9000HD HIGH-DEFINITION DIGITAL SATELLITE & TERRESTRIAL RECEIVER Panarex Electronics SUN VALLEY, CALIFORNIA, USA ⓒ 2007 by Panarex Electronics 1...
Page 2 PREFACE IMPORTANT SAFETY INSTRUCTIONS 1 OVERVIEW 1) INTRODUCTION 2) FEATURES 3) ACCESSORIES 4) REMOTE CONTROL UNIT 5) FRONT PANEL 6) REAR PANEL 7) UNIVERSAL II REMOTE INTERFACE PROGRAMMING 8) CONNECTION DIAGRAM 2 OPERATION 1. START UP 2. INSTALLATION 3. CHANNEL EDIT 4.
Page 8: General Features
1. OVERVIEW 1. INTRODUCTION This product is designed for using Digital Satellite and allows you to enjoy a lot of broadcasting whenever you want to watch it anytime. By simply pressing the button of the remote control unit, the vivid picture and life –like sound of digital broadcasting that your TV portrays through this product, allows you to watch whatever channel you wish of the digital broadcasting.
Page 9 Parental Lock, Channel Rename, Channel Skip Manual PID/ Satellite & TP/ Network Scan S/PDIF (Digital Audio or Dolby AC3 stream out) Diseqc 1.2 and USALS Compatible Comparable of Setting the Frequency for SMATV System Universal II Remote Integrated USB2.0 (Host), Support to USB Memory Stick UHF Ready (U-30 Kit optional) 3 PLEASE CHECK THE FOLLOWING ACCESSORIES ARE ENCLOSED ▪...
Page 10: How To Use The Remote Control Key
4. HOW TO USE THE REMOTE CONTROL KEY Function Turns the selected equipment (Set Top Box, AUX, TV) on/off. TV/SAT Toggles between TV & SAT operation Enable remote to control the receiver Enable remote to control aux any unit VIDEO Toggles between TV &...
Page 11: Operating Principle
Shows signal quality Multi picture (Max 16 CH) TIME Time shows current time Changes channel directly. Controls the numerical operation. PAUSE Holds the picture or release the pause Operating Principle ▪ Select an item by using up and down key and change the value of the highlighted (selected) item by using keys shown on the screen.
Page 14: Front Panel
5. FRONT PANEL POWER To put Power in and out of standby mode. VOLUME To make volume up and down & to change the value of a selected line CHANNEL To move up and down in the menus, To change channels. Menu To enter main menu screen.
Page 15: Rear Panel
6. REAR PANEL NAME FUNCTION IF INPUT IF INPUT from LNB to receiver IF OUTPUT IF Loop-through output to 2 receiver TV OUT Output to TV ANT IN Input from off-air TV or cable etc. VIDEO Composite Video Output AUDIO L Left Audio Output AUDIO R Right Audio Output...
Page 18 2. OPERATING 1. Start Up If you are watching TV through the RF-cable, you need to adjust the channel number. The type of TV and channel numbers are set to NTSC and channel 3 at the factory. Please follow the brief procedure below and watch the satellite programs. Select the language Select the antenna setup in main menu screen Adjust LNB configuration per each satellite...
Page 19: Installation
2. Installation Press the OK key. Use common password “0000.” Channel edit is not accessible until satellite channel scanned and saved. Antenna setup is appeared on screen as upper second figure. 2.1 Antenna Setup In this section you, all parameters can be set to get enough signal & quality levels to be locked. 2.1.1 Satellite ▲▼, •...
Page 20: Positioner Setting
22KHz control is automatically set for each LNB alternative or you can change it by yourself. 2.1.3 LNB Lo-Freq If the required LNB frequency is not available, select “Standard” and then input the frequency manually using the numeric keys. 2.1.4 22Khz In case you are using a dual LNB or two antennas connected to a 22KHz tone switch box, make 22KHz tone switch “ON”...
Page 21: Satellite Scan
2) USALS (DiSEqC 1.3 automatic operation) (1) Satellite Position It points out the position of saved satellite. You can change the position of the satellite by numeric keys. (2) My Longitude Please input Local Longitude by numeric keys (3) My latitude Please input Local Latitude by numeric keys (4) Reference position This is the same as DiSEqC 1.2 Reference...
Page 22: Advanced & Tp Scan
(1)Press OK key and select wanted satellite by using ▼&▲keys. (If you want to scan several satellites once, you can control keys.) ◀ ▶ Then press OK key to execute scanning. (2) You can select satellite whatever you chose though. (3) Transponder will be consecutively scanned all selected satellites.
Page 23: Edit Tp/Satellite
2.3.7 PID Scan Select Auto or Manual mode. Type PID number at manual mode. 2.3.8 Scan Option Select scan option by using keys (ALL, FTA). ◀ ▶ 2.3.9 Network Scan Select ‘ON’ or ‘OFF by using keys ◀ ▶ 2.3.10 Start Scan After all setting is finished, then press OK to start scan.
Page 24 2.4.3 How to delete/restore a satellite • Press OK key after selecting a satellite you want to delete. • Press OK to confirm, otherwise press EXIT to cancel. The color of the deleted satellite name in the list is changed. •...
Page 25: Automatic Scan
2.5.1 Automatic Scan If you select this menu, Automatic DVB-T signal reception setup will be done. 2.5.2 Manual Scan You can adjust the channel, Frequency, Network scan. 2.5.2.1 Channel You can select the channel by using key Channel selection (6~12, 21~69) ◀...
Page 26: Channel Edit
3. Channel Edit 3.1 Channel Edit After pressing the password, you can edit channels of satellite in this mode. (1) You can sort the channels out upon your preference. (2) You can rearrange the channel list. (3) You can delete channels. (4) You can select P-Lock menu.
Page 27 ▪ P-Lock ▪ S-ID Select the mode that you want to sort and press OK (3) Press EXIT to exit from this mode. 3.1.2 How to move the channel (1) Press OK key after selecting Move key (2) Press keys to select a channel to move and then move the selected channel to the new position by ◀...
Page 28 3.1.4 How to lock/unlock the channel (1) Select P-LOCK and press OK. (2) Select the channel that you want to lock and press keys ◀ ▶ (3) This channel is now locked and the symbol of lock will be shown as a locked channel. (4) You can release the locked channel if you press ◀...
Page 29: Favorite Edit
(1) Press OK after selecting RENAME mode (2) Select the channel of which you want to change name (3) Press OK to enter the character input mode (4) Put new names, as you want using the 4 arrows keys. The maximum number of characters is 20. (4) After completion of entering new, press OK 3.2 Favorite Edit (1) Select one channel of channel list.
Page 30: Time Setting
4.1 Time Setting 4.1.2 Current Time After selecting Time mode, you can adjust the time as follows. - Current Year > Set up by pressing numeric keys - Current Month / Day> Set up by pressing numeric keys - Current Time> Set up by pressing numeric keys 4.1.3 Timer After selecting timer, you can see timer list and adjust the time as follows.
Page 31: Parental Control
- Wakeup service No. - Sleep Time > > Set up by pressing numeric keys 4.2. Parental Control After selecting parental control and entering the correct password, the screen as shown in the right appears. The default password at the factory is “0-0-0-0”You may change the PIN code, which is your password in other words, and lock the receiver to prevent children from watching programs.
Page 32: Osd Language
(5) To enter Installation menu. (6) To video format change menu In case of forgotten password programmed call Pansat’s dealer to get master factory password. 4.3 Language 4.3.1 OSD Language Press EXIT key after you select your preferable language and audio language by using VOL keys.
Page 33: Osd Setting
4.4.1 TV Screen Format You can set the TV aspect ratio (4:3 for normal TV & 16:9 for wide TV) by pressing VOL keys. ◀▶ 4.4.2 Video Format You can set it by pressing VOL ◀▶ keys (1080i, 720p, 480p) When you change Video Format, enter the Password.
Page 34: Factory Setting
That is, factory setting functions your STB (Set Top Box) the first stage. If you do not want to continue this mode, press EXIT key before you enter password. Common password is “0000”. In case selected password is forgotten, call Pansat’s dealer to get factory master password.
Page 35: Channel List
Warning! Please use USB memory stick only. Don’t use any other product like USB charger. Don’t use USB related products which cannot meet DC5V, & Max .100mA. 1. USB menu can be watched after inserting USB stick in normal video mode and the menu list can be displayed. 2.
Page 36: Red Button
7.1 Red Button If you press the red button, you can sort the channels by Satellite, Alphabet, CAS. 7.2 Green Button If you press the green button, you can find the channels including the alphabet which you insert. 8. Program Guide ▪...
Page 37: Recall The Favorite Channel
10. Recall the Favorite Channel ▪ Press FAV key to recall a stored favorite channel. ▪ Favorite channel is programmed and stored in the Favorite Edit menu. 11. Download Procedure between Receiver & PC 1. Turn the receiver power on. 2.
Page 38: Specification
3. SPECIFICATION * All specifications are subject to change without any notice. ⓒ 2007 by Panarex Electronics 38...
Page 39: Troubleshooting
4. TROUBLE SHOOTING There may be various reasons for the abnormal of the unit. Therefore, if the unit does not work properly, check the unit according to the procedures shown in the table below. Problem Possible causes Remedy LED on front panel AC Power cord disconnected Connect power cord properly into the Does not light...
