Page 1 USER’S GUIDE 250SM DIGITAL SATELLITE RECEIVER Panarex Electronics Sun Valley, California, USA ⓒ 2007 by Panarex Electronics...
Page 7: Specification
PREFACE 1. OVERVIEW 1. WHAT IS THIS PRODUCT FOR? 2. WHAT FEATURE DOES THIS PRODUCT OFFER? 3. FOR YOUR SAFETY 4. PLEASE CHECK THE FOLLOWING ACCRSSORIES ARE ENCLOSED 5. HOW TO USE THE REMOTE CONTROL KEY 6. FRONT PANEL 7. REAR PANEL 8.
Page 8: What Feature Does This Product Offer
1. OVERVIEW 1. WHAT IS THIS PRODUCT FOR? This product is designed for using Digital Satellite and allows you to enjoy a lot of broadcasting whenever you want to watch it anytime. By simply pressing the button of the remote control unit, the vivid picture and life –like sound of digital broadcasting that your TV portrays through this product, allows you to watch whatever channel you wish of the digital broadcasting.
Page 9: Additional Features
▪ Satellite Scan – Simultaneous Scan with various Satellites ▪ DiSEqC 1.2 & USALS Compatible ▪ Comparable of Setting the Frequency for SMATV System ▪ Software Upgrade via USB Memory Stick or RS232C (Receiver to Receiver, PC to Receiver) ▪ UHF- Ready (U-30 Kit optional) ▪...
Page 10: How To Use The Remote Control Key
5. HOW TO USE THE REMOTE CONTROL KEY Function Turns the selected equipment (Set Top Box, AUX, TV) power on/off. TV/SAT Toggles between TV & SAT operation Enable remote to control the receiver Enable remote to control aux any unit VIDEO Toggles between TV &...
Page 11: Operating Principle
Shows signal quality Multi Picture (Max 16 CH) TIME Time shows current Time Changes channel directly. Controls the numerical operation. PAUSE Holds the picture or release the pause Operating Principle ▪ Select an item by using up and down key and change the value of the highlighted (selected) item by using keys shown on the screen.
Page 14: Front Panel
6. FRONT PANEL POWER To put power in and out of standby mode. VOLUME To make volume up and down. CHANNEL To move up and down in the menus, To change channels. Menu To enter main menu screen. Exit To move to previous menu. Display To show channel number, error messages, remote control commands and time in standby mode.
Page 15: Rear Panel
7. REAR PANEL NAME FUNCTION S-VHS Super Video output to TV or VCR Option for UHF Remote Control lit S/PDIF For digital audio output RS232 Serial port used for software upgrade Left Audio Output Right Audio Output Component Video Output Component Video Output TV OUT Output to TV...
Page 16 8. SIMPLE DIGITAL CONNECTION When connecting receiver to TV and VCR with RF Cable (Single Antenna) 9. ANALOGUE / DIGITAL CONNECTION When connecting receiver to analogue receiver and VCR with RF Cable ⓒ 2007 by Panarex Electronics...
Page 17 2. OPERATING 1. Start Up If you are watching TV through the RF-cable, you need to adjust the channel number. The type of TV and channel numbers are set to PAL-G and channel 38 at the factory. For USA, Ch3 is factory preset. Please follow the brief procedure below and watch the satellite programs.
Page 18: Installation
2. Installation Press the OK key. Use common password “0000”. Parental control and channel edit are not accessible until satellite channel scanned and saved. Antenna setup is appeared on screen as upper second figure. 2.1 Antenna Setup In this section you could know how to operate LNB set-up. 2.1.1 Satellite •...
Page 19: Positioner Setting
• Universal 2 (9750MHz & 10750 MHz) • Single-SL (5150MHz & 5750 MHz) • Single-SH (5150MHz & 5750 MHz) • Standard for USA (10750 or 11250) • Single Stack (10750(V) / 10175(H)) 2.1.4 LNB Lo-Freq If the required LNB frequency is not available, select “Standard” and then input the frequency manually using the numeric keys.
Page 20: Satellite Scan
2) USALS (DiSEqC 1.3) (1) Satellite Position It points out the position of saved satellite. Change satellite position number to maximize quality level if needed. (2) Local Longitude Please input Local Longitude by numeric keys and adjust E.W by using ◀ ▶ keys. (3) Local latitude Please input Local Latitude by numeric keys and adjust N.S by using ◀...
Page 21: Smart Search
(3) Set scan option by using ◀ ▶ keys. Select items in the list and press OK. (4) PID data can be applied manually. (5) Choose scan type (ALL or FTA) using ◀ ▶ keys. Then press OK to search in Scan Start. 2.4 Smart Search Smart Scan enables to search and scan all channels in the satellite without any preprogrammed data.
Page 22 2.5.1 How to add a new satellite • Select “New” in the satellite name by using CH ▲▼ keys. Press VOL ▲▼ keys to input the name of satellite in keyboard menu. Then press OK to save. • If you want to add TP, please refer to 2.5.3 item. 2.5.2 How to rename a satellite •...
Page 23: Channel Edit
3. Channel Edit You can edit channels of Satellite in this mode. (1) You can sort the channels out upon your preference. (2) You can rearrange the channel list. (3) You can delete channels. (4) You can skip channels. (5) You can change the channel name, as you want. (6) To enter channel edit mode, you need to press 4 digits password (factory setting is “0-0-0-0“).
Page 24: User Setup
3.3 How to delete the channel (1) Select Delete and press OK (2) Select a delete mode by using the keys ◀ ▶ (3) Select a channel you want to delete by using the keys ◀ ▶ (4) Press OK key. (5) All channels that you selected are deleted.
Page 25: Parental Control
4.1 Time After selecting Time, you can adjust the time. Also select “ON” at Timer by pressing keys and press OK button. ◀ ▶ You can set the wakeup time and sleeping time to turn receiver on and off automatically according to the time programmed.
Page 26 (4) To execute factory setting (5) To enter installation menu. In case of forgotten password programmed call Pansat’s dealer to get master factory password. 4.3 Language Press EXIT key after you select your preferable language and audio language by using VOL ◀▶...
Page 27: Factory Setting
If you do not want to continue this mode, press EXIT key before you enter password. Common password is “0000”. In case selected password is forgotten, call Pansat’s dealer to get factory master password.
Page 28: Program Guide
7. Program Guide ▪ The title and start time of the program is shown as in the right figure after pressing EPG key. ▪ Select the particular channel The channel will be changed. ▪ If you want to watch TV with full screen, Press EXIT. 8.
Page 29: Multi Pictures
10. Multi Pictures 1. Press and select the multi picture mode (2X2 or 3X3 or 4x4) that you want. 2. Move the cursor and select one picture to play 11. Embedded ▪ If you insert smart card inside the receiver smart card reader, the receiver will recognize it automatically. 12.
Page 32: Black-And-White
5. TROUBLE SHOOTING There may be various reasons for the abnormal of the unit. Therefore, if the unit does not work properly, Check the unit according to the procedures shown in the table below. Problem Possible causes Remedy LED on front panel AC Power cord disconnected Connect power cord properly into the Does not light...
