Setting the Options for FAX/TEL AUTO SW
If you set FAX/TEL AUTO SW, you can control precisely how the machine handles incoming calls by
adjusting the following settings:
• Adjust the time the machine takes to check whether a call is from a fax machine or a telephone (RING
START TIME setting).
• Adjust the length of time the machine rings when the call is a voice call (F/T RING TIME setting).
• Set whether the machine switches to receive mode after the ring time set in F/T RING TIME has elapsed
(DEFAULT ACTION setting).
• You can also set these options from the MultiPASS Suite. (
• The default settings and selectable settings vary depending on the current country selection.
What Happens When FAX/TEL AUTO SW is Selected
Type of call
Telephone charges
begin for the caller.
RING START TIME
F/T RING TIME
5-2
Telephone
The machine answers without ringing.
The machine listens for the fax tone.
The fax tone is not detected.
The machine starts ringing.
If you don't pick up the handset.
DEFAULT ACTION
Choose between:
RECEIVE and DISCONNECT.
RECEIVE
Not all fax machines are capable of sending a fax
tone. For those cases if you set the DEFAULT
ACTION to RECEIVE, the machine switches to
receive mode automatically and starts receiving the
document. If no document comes in, it disconnects
the call after approximately 40 seconds.
MultiPASS Suite User's Guide)
Fax
Sending document
manually
The fax tone
is detected.
Fax
Sending document
automatically
The document is
received automatically.
The fax tone is
detected and the
machine switches to
receive mode.
Pick up the handset
to talk.
DISCONNECT
The machine
disconnects the call.
