CABLE COLOR SCHEME
Item
Cable Color
Power
Black
Input
Yellow
Green
Output
White
Communication
Brown
Not used
Orange
CABLE SELECTION
Item
1
Power (DC12V)
WIEGAND Output
2
Buzzer Control
LED Control
3
RS-232 Cable
Signal Line
Red
DC +12V
GND
Blue
Buzzer Control
LED Control
Out Wiegand 0
Out Wiegand 1
RS-232(TX)
NC
Belden #9409, 18 AWG 2 Conductor, Unshielded
Belden #9409, 18 AWG 2 Conductor, Unshielded
Belden #9512, 22 AWG 4 Conductor, Shielded
Belden #9514, 22 AWG 8 Conductor, Shielded
Belden #9829, 24 AWG 2-twisted pair, Shielded
Description
DC +12V supplied
Earth-grounding for power
BUZZER Control Input Port
LED Control Input Port
Wiegand Data 0 Output Port
Wiegand Data 1 Output Port
RS-232 Transmission Output Port
Not Connected
Cable Type
Cable Type
EnglisEnglish _ 7
