Oven Door

Lift-Off Oven Door
The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.
To Remove the Door:
frame to the unlocked position.
3. Firmly grasp both sides of the door near the top.
4. Close door until the top of the door is approximately
6" from the range frame.
5. Lift door up and away from the range until both hinge
arms are clear of the slots in the range frame.
To Replace the Door:
2. With the door at the same angle as the removal
position, rest the notch on the underside of the left
hinge arm on the bottom edge of the left hinge slot.
The notch in the hinge arm must be fully seated into
the bottom of the slot. Repeat for the right side.
3. Fully open the door. If the door will not fully open, the
notches in the bottoms of the hinge arms have not
seated correctly in the bottom edge of the slot. Lift the
door off the range and repeat previous step.
down to the locked position.
5. Close the oven door.
Lift-Off Upper Oven Door
The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.
To Remove the Door:
2. Lift up on the hinge lock toward the oven frame until
they stop.
4. On both sides of the door, press down on the release
buttons on each hinge.
5. Lift door up until it is clear of the hinge.
locking tabs.
Oven
frame
26
Bottom
edge of
To Replace the Door:
2. Lift up on the hinge locks toward the oven frame until
3. The hinges will release to the 45-degree position. The
4. Slide the door back onto the hinges. Make sure the
5. Fully open the door.
7. Close the oven door.
Door
frame
Release
buttons
Hinge arm
slot
Notch
Rest notch on bottom edge
of hinge slot
the fully open position.
they stop.
hinge locks will contact the oven frame.
buttons pop back out.
Removal position
lock
