Fujitsu F2MC-8FX Series Setup Manual
F2mc-8fx family mb95330 series 8-bit microcontroller ev board
Hide thumbs
Also See for F2MC-8FX Series:
- User manual (110 pages) ,
- Application note (53 pages) ,
- Setup manual (30 pages)
Related Manuals for Fujitsu F2MC-8FX Series
Summary of Contents for Fujitsu F2MC-8FX Series
- Page 1 Fujitsu Semiconductor (Shanghai) Co., Ltd. MCU-AN- 500070-E-14 Setup Guide F²MC-8FX FAMILY 8-BIT MICROCONTROLLER MB95330 SERIES EV BOARD MB2146-440-E SETUP GUIDE...
- Page 2 EV Board MB2146-440-E Setup Guide V1.4 Revision History Revision History Date Author Change of Records 2009-11-10 Kevin Wang V1.0, First draft 2009-11-30 Kevin Wang V1.1,Modify 2010-01-12 Kevin Wang V1.2,Add speed module 2010-01-26 Kevin Wang V1.3, Modify speed module 2010-02-09 Kevin Wang V1.3,Update EVB picture and SCH 2010-04-19 Kevin Wang...
-
Page 3: Preface
EV Board MB2146-440-E Setup Guide PREFACE PREFACE Thank you for purchasing the F2MC-8FX Family EV board: MB2146-440-E. This product is an EV board for F2MC-8FX MB95330 Series MCU, which comes with MB2146-08-E (F2MC-8FX Family MB95330 Series BGM Adapter), MB2146-440-E, and F2MC-8L/8FX Family SOFTUNE Professional Pack Evaluation Version. -
Page 4: Revision History
EV Board MB2146-440-E Setup Guide PREFACE ■ Caution of the Products Described in this Document Caution of the Products Described in this Document The following precautions apply to the product described in this manual. The following precautions apply to the product described in this manual. Indicates a potentially hazardous situation which, if not avoided appropriately, Indicates a potentially hazardous situation which, if not avoided appropriately, WARNIN... - Page 5 The information, such as descriptions of function and application circuit examples, in this document are presented solely for the purpose of reference to show examples of operations and uses of FUJITSU SEMICONDUCTOR device; FUJITSU SEMICONDUCTOR does not warrant proper operation of the device with respect to use based on such information.
-
Page 6: Table Of Contents
EV Board MB2146-440-E Setup Guide CONTENTS CONTENTS REVISION HISTORY ......................2 PREFACE ..........................1 ■ Handling and Use ......................1 ■ Notice on this Document ....................1 ■ Caution of the Products Described in this Document ............ 2 CONTENTS ..........................4 1 ... -
Page 7: Bgma Manual
EV Board MB2146-440-E Setup Guide Chapter 1 BGMA Manual 1 BGMA Manual This chapter gives introduction on how to set up BGMA. 1.1 BGMA Overview Below is a close look of MB95330 Series BGMA. The part number is MB2146-08-E. It provides a debugging platform for the MB95330 Series MCU in a small size of 55.7mm (W) X127mm (D) X30mm (H). -
Page 8: Idc10 Interface Description
EV Board MB2146-440-E Setup Guide Chapter 1 BGMA Manual 1.3 IDC10 Interface Description Pin Number Pin Name Description UVCC Target MCU V Target MCU V RSTIN Target MCU reset input RSTOUT Target MCU reset output Reserved Reserved Reserved Target MCU debugging pin Reserved Reserved 1.4 BGMA USB Configuration... - Page 9 EV Board MB2146-440-E Setup Guide Chapter 1 BGMA Manual Select Install from a list or specific location (Advanced), then click Next. Figure 1.4-2 Install BGMA in Windows (2) Select …\Drivers from the folder where SOFTUNE is installed, click Next. Figure 1.4-3 Install BGMA in Windows (3) Page 7...
-
Page 10: Led Description
