Parts of the washing machine

洗衣机的部件
Machine body 洗衣机机体
Lint filter box
棉绒过滤盒
Pulsator
波轮
Control panel
操作面板
Cabinet
洗衣机机壳
List of accessories 附件清单
Name
名称
Water inlet hose assembly
进水管组件
Drain hose
排水软管
＊
Screw
螺丝
＊
Bottom Cover
底盖
Operation manual
说明书
Installation manual
安装说明书
NOTE 注意
＊ Bottom cover and Screw are applied by service staff.
底盖和螺丝由安装人员进行提供。
Keep the Operation manual and installation manual
for future reference.
请妥善保管操作手册和安装手册，以便将来使用。
6
Top lid
盖板
Water inlet hose
connecting port
Drain hose
排水软管
Power cable
电源插头
Adjustable foot
可调节脚
Quantity
数量
1 set
1套
1
1
1
1
1
Common symptom
Symptom
There is a noise on the
Keep the washing machine away from radio
radio or television, and the
and television as far as possible.
image is unclear.
The white powdery material is the result of the
combination of ingredients in detergent and
After washing is finished,
ingredients in water. (Wipe away with cloth.)
there are white lines around
Please note that it will stick on where it is left.
the washing / spin drying tub.
Using liquid detergent or injecting water and rinsing
twice can prevent this phenomenon.
Is the power cord properly plugged in?
Not working.
Isn't the power supply interrupted
Light cannot be on.
or isn't the breaker tripped?
Isn't the washing machine inclined or unstable?
Does the clothing deviate to one side during spin drying?
There is abnormal sound.
Are there hair clips or other foreign metal objects
Others
mixed in the clothing?
Water is not supplied if the top lid is open.
No water supply.
Please close the top lid properly.
Are the screws or the installation position of the
Leaking tap. water nozzle connection loose?
Is the water nozzle connection inclined or wobbly?
Automatic sensing function does not work
when water is left in the tub.
Water amount is decided by the weight of laundry.
Water amount is not suitable
If there is much synthetic clothing or laundry net is used,
for laundry load
the laundry is weighed lightly.
If there is wet clothing, the laundry is weighed heavily
To adjust water level, press the WATER LEVEL key.
The breaker trip Connect only the washing machine,
when the plug is inserted reset the breaker, and operate
Inspection of a washing machine that have been used for many years.
Does not operate sometimes.
"CHILD LOCK" does not work during
operation.
Water leakage (water hose, spinning
Check Are there
tub, tap connection).
situations
There is burnt smell.
like these?
There is an abnormal sound or
vibration during operation.
Your hand feels numb while touching
the machine.
Power cable or plug is unusually hot.
Reason/Solution
To avoid injuries or accidents, please pull
out the plug from the plug socket.
Stop using
Call the nearest Sharp Service Center to
the machine
check your machine. Consult Sharp Service
Center for check and repair fees.
