Sharp VL-AX1S/H Service Manual

Liquid crystal digital camcorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1. SPECIFICATIONS .............................................................................................................................. 2
2. PART NAMES .................................................................................................................................... 3
3. DISASSEMBLY OF THE SET ............................................................................................................ 4
4. MECHANISM ADJUSTMENT JIGS AND PARTS .............................................................................. 7
ITEMS AND INTERVALS ................................................................................................................... 8
6. MECHANICAL ADJUSTMENTS AND CHECKS ................................................................................ 9
7. TAPE RUNNING ADJUSTMENT ..................................................................................................... 12
(DISASSEMBLY AND REASSENBLY) ........................................................................................... 14
9. ADJUSTING THE ELECTRICAL CIRCUITS .................................................................................... 21
10.USEFUL TIPS ................................................................................................................................... 42
11.SIGNAL FLOW DIAGRAMS ............................................................................................................. 43
12.BLOCK DIAGRAMS ......................................................................................................................... 46
13.SCHEMATIC DIAGRAMS ................................................................................................................ 52
14.SEMICONDUCTOR LEAD IDENTIFICATION ............................................................................... 106
15.PRINTED WIRING BOARD ASSEMBLIES .................................................................................... 108
16.REPLACEMENT PARTS LIST ....................................................................................................... 119
17.PACKING OF THE SET ................................................................................................................. 141
SERVICE MANUAL
LIQUID CRYSTAL DIGITAL CAMCORDER
MODELS
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
original condition and only parts identical to those specified
be used.
CONTENTS
SHARP CORPORATION
1
VL-AX1S/H/E/EW/EX
VL-AX1S/H
VL-AX1E/EW/EX
S12E8VL-AX1S/
PAL
Page

Advertisement

Table of Contents
loading

Related Manuals for Sharp VL-AX1S/H

Summary of Contents for Sharp VL-AX1S/H

  • Page 1: Table Of Contents

    VL-AX1S/H/E/EW/EX SERVICE MANUAL S12E8VL-AX1S/ LIQUID CRYSTAL DIGITAL CAMCORDER VL-AX1S/H VL-AX1E/EW/EX MODELS In the interests of user-safety (Required by safety regula- tions in some countries) the set should be restored to its original condition and only parts identical to those specified be used.

  • Page 2: Specifications

    VL-AX1S/H/E/EW/EX 1. SPECIFICATIONS Signal System: PAL standard Recording System: 2 rotary heads, helical scanning system Cassette: Digital VCR Mini DV video cassette Recording/Playback Time: 90 minutes (DVM60, LP mode) Tape Speed: SP mode: 18.831 mm/second LP mode: 12.568 mm/second Pickup Device: 1/3.6" 6.4mm, (effective size: 5.0 mm) CCD image sensor (with approx.

  • Page 3: Part Names

    VL-AX1S/H/E/EW/EX 2. PART NAMES For details on the use of each control. Front view FADE button RETURN button Accessory shoe GAMMA/ BRIGHTER button Stereo microphone Manual Selection FOCUS switch switch Zoom lens Remote sensor CONTROL dial Manual Focus ring MENU button...

  • Page 4: Disassembly Of The Set

    VL-AX1S/H/E/EW/EX 3. DISASSEMBLY OF THE SET Note: Before removing the cabinet, turn off the power supply, and ascertain that the battery have been removed. Hot shoe FPC Top cover ass'y Shoe fitting Open the LCD Fitting cover DV·232C unit FPC •...
  • Page 5 VL-AX1S/H/E/EW/EX • Detach the 3 main=sub FPCs (1, 2 and 3) and 1 microphone connector. Sub PWB • Remove the 1 screw ((R)XiPSN17P03000) and 2 screws ((N)XiPSF17P02000), and pull out the sub PWB in the direc- tion of the arrow.
  • Page 6 VL-AX1S/H/E/EW/EX VF unit • Remove the 1 screw ((Q)XiPSN17P02000) and 5 screws ((O)XiPSF17P03000), and pull out the VF unit in the direc- tion of the arrow. • Remove the 1 screw ((N)XiPSF17P02000) to detach the battery cover. Battery cover Tilt cover...

  • Page 7: Mechanism Adjustment Jigs And Parts

    VL-AX1S/H/E/EW/EX 4. MECHANISM ADJUSTMENT JIGS AND PARTS Configuration 1. Name 4-1. Mechanism check adjustment jigs 2. Part No. 3. Code <Note: The entries of list> * Model, Uses Remarks 1. PB-use cassette 1. Tension gauge 4N 1. Dial tension gauge 1.

  • Page 8: Inspection And Maintenance Items And Intervals

    VL-AX1S/H/E/EW/EX 5. INSPECTION AND MAINTENANCE ITEMS AND INTERVALS In order to keep the mechanical section always in good condition, perform the following inspection and maintenance at regular intervals. In addition, after repair, perform the following maintenance items regardless of how long the user has been using the unit.

  • Page 9: Mechanical Adjustments And Checks

    VL-AX1S/H/E/EW/EX 6. MECHANICAL ADJUSTMENTS AND CHECKS The items discussed here relate to general on-site servicing (field servicing). Adjustments and replacements that require sophisticated facilities, jigs and technology are omitted. In addition, in order to maintain the characteristics that the unit has when it is new, not only are inspection and maintenance necessary, but it is absolutely necessary that, for example, the tape not be damaged, and always use jigs for adjustments that require them.
  • Page 10 VL-AX1S/H/E/EW/EX 6-4. Back tension torque check and adjustment in record (playback) mode Tension roller position (S guide standard) AC adapter used, with cassette controller assembly 0 ± 0.3 (1) Checking Set the torque cassette (SD-1015), and make sure in the SP record mode that...
  • Page 11 VL-AX1S/H/E/EW/EX <REW back tension standard> (If the tension fluctuates, read its center value.) 15 ± 12mN 6-8. Checking of winding Tu reel base ratchet torque DC3V, without cassette controller assembly (Independent Mechanism) (1) Remove the cassette controller assembly, then apply DC3V to the loading motor and put the system into standby mode.

  • Page 12: Tape Running Adjustment

    VL-AX1S/H/E/EW/EX 7. TAPE RUNNING ADJUSTMENT 7-1. Adjustment locations <Replacement parts> Adjust the height of only · T roller, arm replaced parts with the · Tu guide, arm adjusting jig. · Slide chassis Adjustment procedure 7-2 Running rough Running final Running adjustm-...
  • Page 13 VL-AX1S/H/E/EW/EX 7-4. Running rough adjustment (With cassette controller) 1) Su, Tu guide roller height adjustment Entrance side Exit side <Method and description> ±1/4 shift ±1/4 shift Normal (1) Loosen the guide roller lock screw, then tighten loosely so that the roller turns easily.

  • Page 14: Mechanical Section Assembly And Parts Replacement (Disassembly And Reassenbly)

    VL-AX1S/H/E/EW/EX 8. MECHANICAL SECTION ASSEMBLY AND PARTS REPLACEMENT (DISASSEMBLY AND REASSEMBLY) Mechanical section disassembly and reassembly are explained in this section. For removal of the cabinet, etc., refer to 3. DISASSEMBLY OF THE SET. <Precautions> 1. Always replace cut washers that have been removed, for example in parts replacement, with new ones.
  • Page 15 VL-AX1S/H/E/EW/EX (6) STOP mode (5) PLAYBACK (RECORD, FF, VSF) mode The system is in the STOP (Rec Lock in CAMERA mode) The mechanism position for playback, record, FF and fast position; the S and the T pole bases are snap-fitted to the drum feed playback.
  • Page 16 VL-AX1S/H/E/EW/EX 8-3. How to operate with the circuit board without the cassette controller assembly. In this method, if the procedure is followed incorrectly there is danger of damaging the mechanism and the tape, so except in special cases, such as when measuring the VSR torque, do not perform this procedure. Normally operate this unit with the cassette controller assembly attached.
  • Page 17 VL-AX1S/H/E/EW/EX 8-5. Reassembly 8-5-1. Reassembly in side of the main chassis. Note) Numbers before part names are given as a guide to the order of assembly. As for greasing/oiling/cleaning places refer to the attached drawings (Grease/Oil application side of the main chassis).
  • Page 18 VL-AX1S/H/E/EW/EX 8-5-2. Reassembly in side of the Slide chassis. Note) Numbers before part names are given as a guide to the order of assembly. As for greasing/oiling/cleaning places refer to the attached drawings (Grease/Oil application side of the slide chassis)
  • Page 19 VL-AX1S/H/E/EW/EX 8-5-3. Main chassis assembly and slide chassis assembly assembling method (1) Enter the coupling mode. (In this position, the cam groove of the T arm operation lever in the figure is parallel to the side of the main chassis, and the poll base is slightly moved.)
  • Page 20 VL-AX1S/H/E/EW/EX GREASE/OIL APPLICATION From rear surface side Rear surface · groove side surface Front surface · rear surface · groove From rear side surface surface side Drum base assembly Main cam Loading lever Tu loading arm S loading arm Intermediate gear angle...

  • Page 21: Adjusting The Electrical Circuits

    VL-AX1S/H/E/EW/EX 9. ADJUSTING THE ELECTRICAL CIRCUITS Before starting the electric circuit adjustment • The adjustment methods described herein are used, in most cases, when the expendable mechanical parts, including the video head, have been replaced, at which time the electrical circuits need to be readjusted. Before adjusting the electrical circuits, make sure that the mechanism works properly (i.e., the mechanism is properly adjusted).
  • Page 22 VL-AX1S/H/E/EW/EX VL-AX1S/H/E/EW/EX Service jig configuration...
  • Page 23 VL-AX1S/H/E/EW/EX [TEST POINT] (Wiring board diagram: Main Side B) TL5769 TL900 TL902 TL5750 TL5766 TL5762 TL5753 TL904 TL901 SC5701 SC5702 TL5755 TL5754 TL5775 SC900 TL905 TL906 TL5763 TL5764 TL5777 TL5773 TL5765 TL5757 TL789 TL787 TL910 TL5783 C1922 C1721 TL3319 TL5751...
  • Page 24 VL-AX1S/H/E/EW/EX (Wiring board diagram: Sub Side A) TL2732 TL2731 TL2730 TL2728 TL3752 TL3742 T L3739 TL3781 TL2724 TL2722 TL2726 TL2721 TL2716 TL2720 TL3747 TL605 TL2719 TL2725 TL2715 TL3743 TL2718 TL2711 TL2717 TL2723 TL2710 C3750 TL3766 TL3745 TL2714 TL2712 EE level...
  • Page 25 VL-AX1S/H/E/EW/EX [Making adjustments] Adjusting the servo system controller and related parts 1. Setting the system codes Replacement of IC705 E PROM requires the following data to be set in this order. [Procedure] Set the unit to the VCR mode and set the data for each address.
  • Page 26 VL-AX1S/H/E/EW/EX ADJUSTING THE ELECTROMAGNETIC CONVERSION CIRCUIT SYSTEM 1. PLL VCO adjustment Mode VCR ADJ mode Procedure 1) Playback the alignment tape (or a self-recorded tape). 2) Call the adjustment mode (V-ADJ). 3) Set the address "2A" and call the data.
  • Page 27 VL-AX1S/H/E/EW/EX ADJUSTING THE VIDEO I/O CIRCUIT SYSTEM (Wiring board diagram: Main Side B) TL783 TL5756 R2589 L501 TL5789 TL5790 T L5788 TL4403 TL4404 TL4405 R2592 C224 R2590 TL908 C2548 TL5786 R2503 TL912 R205 TL5761 C2546 TL7801 R2505 C2501 C2510 C2513...
  • Page 28 VL-AX1S/H/E/EW/EX ADJUSTING THE LCD CIRCUIT * To make this adjustment, set the backlight switch to the "NORMAL" position. (Wiring board diagram: Main Side B) TL4440 IC501 C404 TL7800 R509 TL3320 TL3322 TL403 C507 TL5776 R520 R519 C513 R516 C515 TL416...
  • Page 29 VL-AX1S/H/E/EW/EX 4. COM-Bias adjustment Test point LCD panel display area Address VCR ADJ 33 Mode VCR AV input Procedure 1) Input white 40% signal into the AV input. 2) Set the illuminometer (TOPCON IM-3) on the LCD panel surface. (Shut off the external light.) 3) Minimize the ripple of output waveform of illuminometer.
  • Page 30 VL-AX1S/H/E/EW/EX (Wiring board diagram: Main Side B) C701 R1943 R1912 R1940 D1900 Q1920 C1921 TL5781 Q1938 R780 R1721 TL5770 C237 TL8843(VB) TL5780 R506 R1934 R1935 C238 R1720 VF sub-brightness R/B C451 C4702 TL3321 TL5767 C407 TL8861(BLD) R406 R411 IC202 Q1947...
  • Page 31 VL-AX1S/H/E/EW/EX 10. VF contrast adjustment Test point TL8841(VG) Address VCR ADJ E5 Mode VCR AV input Procedure 1) Input the signal of a 3-step waveform. 2) Set VCR ADJ EB/ED to FF/00. 3) Adjust the pedestal 100% range of the waveform of TL8841 to the specified adjustment value.
  • Page 32 VL-AX1S/H/E/EW/EX ADJUSTING THE MIC AMP CIRCUIT (Wiring board diagram: Sub Side A) TL6609(GND) 752 TL3742 T L3739 EE level TL3747 TL605 TL3743 Frequency character TL3745 TL2755 EE level TL602 Super-directional microphone TL2754 C635 TL3737 R610 Frequency character TL2752 TL2759 Super-directional microphone...
  • Page 33 VL-AX1S/H/E/EW/EX DV INTERFACE (IEEE1394) ID SETTING This unit has a DV interface function conforming to IEEE1394. Therefore, each individual ID number must be used for each unit. Since this ID is written on the E PROM (IC302) on the head amp PWB, the ID must be newly written when replacing this IC or the head amp PWB.
  • Page 34 VL-AX1S/H/E/EW/EX (5) Click on [Repair use]. Click (6) Input the necessary information for the application. For the indispensable input items, be sure to input them. Select the [Group/company] and [Kind name] from the list. Input the [Model name]. Input the [Serial number].
  • Page 35 VL-AX1S/H/E/EW/EX 9-2. Camera Section Adjustments 9-2-1. Camera section service (1) Camera adjustment is performed after the set has been completed. (2) Subjects, measuring instruments and jigs needed for camera section service and adjustments • Gray scale chart • Frequency counter •...
  • Page 36 VL-AX1S/H/E/EW/EX 4) Operation flow FF or REW PLAY FF or REW PLAY STOP Address is selected and specified, with the data called. Then the called data are selected and fixed. The operation flows in this sequence. 5) When the adjustment is complete: Press the "CONTINUE"...
  • Page 37 VL-AX1S/H/E/EW/EX (4) Camera signal system adjustment mode In the camera signal system adjustment mode, the automatic white balance is disabled to allow for the adjustment of the camera unit. At this time, the white balance mode is fixed at the INDOORS mode and the focus mode is switched to the manual focus mode.
  • Page 38 VL-AX1S/H/E/EW/EX 9-2-4. Adjustment procedures Item Adjustment method (1) Auto-focus adjustment Set the unit to the auto-focus function adjustment mode and write data to the address "0001" one after another. This executed the adjustments automatically. The items to be adjusted are as listed below. Every time an adjustment is made properly, the data "00FF"...
  • Page 39 VL-AX1S/H/E/EW/EX Adjustment method Item (4) Iris AE coarse adjustment (1) Video output is observed with the oscilloscope in the grey scale standard record state, • Measurement terminal: the data of address "0002" is rewritten, and the luminance signal level is adjusted white to 760 ±...
  • Page 40 VL-AX1S/H/E/EW/EX Adjustment method Item (1) White balance adjustment is performed repeatedly. (7) White balance adjustment • Measurement terminal: EE output • Address: "0128" INDOOR_W/B R "012A" INDOOR_W/B R • Measuring instrument: Vector scope • Object: Grey scale • Data variation width: "0000"...
  • Page 41 VL-AX1S/H/E/EW/EX Item Adjustment method (12) Iris AE adjustment (1) Set the unit to the normal operation mode (write the data " FF" to the address • Measurement terminal: "0000"). S terminal luminance signal output (2) Video output is observed with the oscilloscope in the grey scale standard record (75 Ω...

  • Page 42: Useful Tips

    VL-AX1S/H/E/EW/EX 10. USEFUL TIPS (PROBLEMS DIFFER FROM THOSE FOUND ON VHS OR 8MM DECKS BECAUSE THE SIGNALS ARE DIGITALLY PROCESSED.) Camera (EE mode) VCR (EE mode) Camera (REC mode) VCR (PB mode) Picture fails to appear when tape Picture fails...

  • Page 43: Signal Flow Diagrams

    VL-AX1S/H/E/EW/EX 11. SIGNAL FLOW DIAGRAMS 11-1. EE MODE FLOW (VIDEO) WAVEFORM DIAGRAM (DURING COLOR BAR RECORDING) IC4401 249pin Y/YC Output CAM ADIN CH1=500mV 20µs/d DC P*10 IC201 CAM ENGINE IC4401 170pin ZYP3 Input 5ms/d CH1=1V DC P*10 CZYP CZCP 43 41...
  • Page 44 VL-AX1S/H/E/EW/EX WAVEFORM DIAGRAM 11-3. FLOW IN PB MODE (VIDEO) (DURING COLOR BAR PLAYBACK) IC3401 32pin Output IC3401 39pin PBDATA Input HEAD AMP 5ms/d 5ms/d CH1=500mV CH1=500mV DC P*10 DC P*10 PB_DATA B TO B SC3301 PB_DATA IC3401 EQ/PLL IC3401 44pin Input...
  • Page 45 VL-AX1S/H/E/EW/EX 11-5. FLOW IN PB MODE (AUDIO) WAVEFORM DIAGRAM (1.6 kHz SINE WAVE) From IC3404 same as in Video 10µs/d CH1=1V DC P*10 PB system IC452 REC/PB ENGINE DODAT 16Bit ADC/DAC IC1602 AUD-R_DA_OUT AUD-L_DA_OUT IC601 AUDIO I/O Headphone AUDIO-R_OUT Jack...

  • Page 46: Block Diagrams

    VL-AX1S/H/E/EW/EX 12. BLOCK DIAGRAMS 12-1. SYSTEM BLOCK DIAGRAM...
  • Page 47 VL-AX1S/H/E/EW/EX 12-2. CAMERA SECTION BLOCK DIAGRAM...
  • Page 48 VL-AX1S/H/E/EW/EX 12-3. VIO ENGINE SECTION BLOCK DIAGRAM...
  • Page 49 VL-AX1S/H/E/EW/EX 12-4. REC/PB SECTION BLOCK DIAGRAM...
  • Page 50 VL-AX1S/H/E/EW/EX 12-5. AUDIO/DIGITAL OUTPUT SECTION BLOCK DIAGRAM...
  • Page 51 VL-AX1S/H/E/EW/EX 12-6. CAMERA CIRCUIT BLOCK DIAGRAM...

  • Page 52: Schematic Diagrams

    VL-AX1S/H/E/EW/EX 14. SCHEMATIC DIAGRAMS 14-1. OVERALL SCHEMATIC DIAGRAM 52~53...
  • Page 53 VL-AX1S/H/E/EW/EX 14-2. CAMERA ENGINE SCHEMATIC DIAGRAM 54~55...
  • Page 54 VL-AX1S/H/E/EW/EX 14-3. REC/PB ENGINE SCHEMATIC DIAGRAM IXA166WJ IXA166WJ 56~57...
  • Page 55 VL-AX1S/H/E/EW/EX 14-4. CMC SCHEMATIC DIAGRAM 58~59...
  • Page 56 VL-AX1S/H/E/EW/EX 14-5. MEC/SYS MiCON SCHEMATIC DIAGRAM 60~61...
  • Page 57 VL-AX1S/H/E/EW/EX 14-6. POWER2 SCHEMATIC DIAGRAM å AND SHADED COMPONENTS=SAFETY RELATED PARTS å å å å å 62~63...
  • Page 58 VL-AX1S/H/E/EW/EX 13-7. RINKAKU SCHEMATIC DIAGRAM...
  • Page 59 VL-AX1S/H/E/EW/EX - M E M O -...
  • Page 60 VL-AX1S/H/E/EW/EX 14-8. VIDEO I/O SCHEMATIC DIAGRAM 66~67...
  • Page 61 VL-AX1S/H/E/EW/EX 14-9. MOTOR DRIVER SCHEMATIC DIAGRAM 68~69...
  • Page 62 VL-AX1S/H/E/EW/EX 14-10. POWER1 SCHEMATIC DIAGRAM 70~71...
  • Page 63 VL-AX1S/H/E/EW/EX 14-11. LENS DRIVER SCHEMATIC DIAGRAM 72~73...
  • Page 64 VL-AX1S/H/E/EW/EX 14-12. LCD IF SCHEMATIC DIAGRAM 74~75...
  • Page 65 VL-AX1S/H/E/EW/EX 14-13. CONNECTION(B-B) SCHEMATIC DIAGRAM 76~77...
  • Page 66 VL-AX1S/H/E/EW/EX 14-14. EQ/PLL SCHEMATIC DIAGRAM 78~79...
  • Page 67 VL-AX1S/H/E/EW/EX 14-15. VIDEO I/O ENGINE SCHEMATIC DIAGRAM 80~81...
  • Page 68 VL-AX1S/H/E/EW/EX 14-16. DAC SCHEMATIC DIAGRAM 82~83...
  • Page 69 VL-AX1S/H/E/EW/EX 14-17. CARD CONN SCHEMATIC DIAGRAM 84~85...
  • Page 70 VL-AX1S/H/E/EW/EX 14-18. V/F SCHEMATIC DIAGRAM 86~87...
  • Page 71 VL-AX1S/H/E/EW/EX 14-19. AUDIO I/O SCHEMATIC DIAGRAM 88~89...
  • Page 72 VL-AX1S/H/E/EW/EX 14-20. CARD MICON SCHEMATIC DIAGRAM IX0950TA IXA142WJ S9041TAFW 90~91...
  • Page 73 VL-AX1S/H/E/EW/EX 14-21. MIC AMP SCHEMATIC DIAGRAM 92~93...
  • Page 74 VL-AX1S/H/E/EW/EX 14-22. CCD SCHEMATIC DIAGRAM 94~95...
  • Page 75 VL-AX1S/H/E/EW/EX 14-23. TG SCHEMATIC DIAGRAM 96~97...
  • Page 76 VL-AX1S/H/E/EW/EX 14-24. CDS SCHEMATIC DIAGRAM 98~99...
  • Page 77 VL-AX1S/H/E/EW/EX 14-25. LCONN SCHEMATIC DIAGRAM 100~101...
  • Page 78 VL-AX1S/H/E/EW/EX 14-26. LCD SCHEMATIC DIAGRAM å AND SHADED COMPONENTS=SAFETY RELATED PARTS å 102~103...
  • Page 79 VL-AX1S/H/E/EW/EX 14-27. HEAD AMP SCHEMATIC DIAGRAM 104~105...

  • Page 80: Semiconductor Lead Identification

    VL-AX1S/H/E/EW/EX 14. SEMICONDUCTOR LEAD IDENTIFICATION HN2A01FU 2SA1989R 2SC4627CD NDS355AN FC117 UN9214 3LN01S HN1B04FU 2SC4738Y RN4984 HN2C01FU FMMT717 CPH3109 RN4986 2SC5383F CPH3206 RN4990 XP05534 2SA1588Y RT1N441U MC2852 RN1704 TA75S01F 2SC4944Y TC7S08U TC7S04U TCSZ04U FMG12 NDS332P MA132WK CPH6702...
  • Page 81 VL-AX1S/H/E/EW/EX HVU359TR KV1812K EX1394CE HVU362 HVC359TR MB88344F BH7277KV BH7275KV LB11990W MB3881 LV4051AT MB8346BV NJM2538B LV4051AT NJM2904V ADC08351 NJM2902V IXA166WJ IX0707TA NJM2535V NJM2143R M24C04W6 IX0809TA SN2G53CT TLC2940 NJM2143R IX0785TA NJU7015R...
  • Page 82 VL-AX1S/H/E/EW/EX 16. PRINTED WIRING BOARD ASSEMBLIES MAIN PWB SIDE A 108~109...
  • Page 83 VL-AX1S/H/E/EW/EX SIDE B R416 R3495 R446 R1992 C405 R443 IC405 IC3405 R412 C452 R407 R442 SC2801 SC5704 C508 SC703 SC3301 R2833 R2815 C2805 R2582 R2813 R798 R2583 R2584 R2588 R2585 R2581 C1708 Q1701 C2552 IC503 C1704 R2615 R1470 R2594 L1702...
  • Page 84 VL-AX1S/H/E/EW/EX SUB PWB SIDE A TL2732 TL2731 TL2730 TL2728 TL3752 TL3742 T L3739 TL2724 TL3781 TL2722 TL2726 TL2721 TL2716 TL2720 TL3747 TL2719 TL2725 TL2715 TL3743 TL2718 TL2711 TL2717 TL2723 TL2710 C3750 TL3766 TL2714 TL3745 TL2712 TL602 TL2709 TL2708 TL2727 L603...
  • Page 85 VL-AX1S/H/E/EW/EX SIDE B SC3704 SC3705 R3802 R3805 R3806 R3807 SC3701 TL2755 TL2754 TL2752 TL2759 TL2733 TL6609 TL2753 TL2757 TL2756 TL2758 TL6601 SC3703 TL6611 TL6608 TL6610 BAT3750 SC3702 P6601...
  • Page 86 VL-AX1S/H/E/EW/EX CAMERA PWB SIDE A R1003 R1001 C1007 C1003 R1005 C1005 R1007 TL104 C1018 C1004 C1008 R1004 R1006 R1002 C1006 IC1002 R1016 TL1021 TL1013 R1017 R1018 R1012 TL1012 R1009 R1010 C1012 Q1001 Q1002 C1017 Q1003 TL1014 TL13 TL11 TL12 TL10...
  • Page 87 VL-AX1S/H/E/EW/EX CCD PWB SIDE A C116 C111 R103 C112 R115 C104 IC101 C106 C101 C103 R116 C102 C120 R120 C115 C114 C118 C1002 RMC1002...
  • Page 88 VL-AX1S/H/E/EW/EX LCD PWB SIDE A...
  • Page 89 VL-AX1S/H/E/EW/EX HEAD AMP PWB Component Side SIDE A R332 C320 C315 R330 R331 R333 R321 R308 C322 C304 R320 Q302 C331 C307 C330 R318 P306 C305 R312 C324 R323 C319 C311 R304 R325 C333 Q303 C301 C327 R324 C342 C332...
  • Page 90 VL-AX1S/H/E/EW/EX Component Side SIDE B C345 L301 C303 Wiring Side SIDE B...

  • Page 91: Printed Wiring Board Assemblies

    VL-AX1S/H/E/EW/EX 16. REPLACEMENT PARTS LIST/ Ref. No. Part No. Description Code Ref. No. Part No. Description Code EXPLODED VIEWS DUNTK3119QA02(VL-AX1S) DUNTK3119QA03(VL-AX1H) DUNTK3119QA04(VL-AX1E/EW) ELECTRICAL PARTS LIST DUNTK3119QA05(VL-AX1EX) MAIN PWB UNIT Parts marked with " å " are important for maintaining the safety of the set.
  • Page 92 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code Q906 VSCPH6702++-1 CPH6702++ COILS AND TRANSFORMER Q907 VSCPH6702++-1 CPH6702++ FL403 RFiLC0164TAZZ Filter Q908 VSCPH6702++-1 CPH6702++ FL501 RFiLZ0169TAZZY Filter Q909 VSNDS355AN/-1 NDS355AN FL3401 RCiLF0408TAZZ Coil, CiLF0408TA Q910 VSNDS355AN/-1...
  • Page 93 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code C713 VCKYCZ1HB102K 1000p 50V Ceramic C215 VCKYCZ1AF104Z 10V Ceramic C716 VCKYCZ1HB102K 1000p 50V Ceramic C222 VCKYCZ1AF104Z 10V Ceramic C718 VCKYCZ1HB102K 1000p 50V Ceramic C223 VCCCCZ1HH221J 220p 50V Ceramic...
  • Page 94 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code C959 VCKYTV1EB104K 25V Ceramic C1722 VCKYCZ1AB473K 0.047 10V Ceramic C960 RC-KZ0070TAZZ 16V Ceramic C1723 VCKYCZ1EB472K 4700p 25V Ceramic C961 VCKYCZ1HB222K 2200p 50V Ceramic C1724 VCKYCY1AF105Z 10V Ceramic...
  • Page 95 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code C3430 VCKYCZ1AF104Z 10V Ceramic C7414 VCCCCZ1HH330J 50V Ceramic C3431 VCKYCZ1CB103K 0.01 16V Ceramic C7417 VCKYCY0JB105K 6.3V Ceramic C3432 VCKYCZ1AF104Z 10V Ceramic C7800 RC-KZ0083TAZZ 10V Ceramic C3433 VCKYCZ1CB103K 0.01...
  • Page 96 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code R432 VRS-CZ1JF000J 1/16W Metal Oxide R757 VRS-CZ1JF000J 1/16W Metal Oxide R436 VRS-CZ1JF224J 220k 1/16W Metal Oxide R758 VRS-CZ1JF473J 47k 1/16W Metal Oxide R437 VRS-CZ1JF224J 220k 1/16W Metal Oxide...
  • Page 97 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code R958 VRS-CZ1JF105J 1/16W Metal Oxide R1714 VRS-CZ1JF621J 620 1/16W Metal Oxide R959 VRS-CZ1JF103D 10k 1/16W Metal Oxide R1715 VRS-CZ1JF103J 10k 1/16W Metal Oxide R960 VRS-CZ1JF392D 3.9k 1/16W Metal Oxide...
  • Page 98 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code R3421 VRS-CZ1JF183J 18k 1/16W Metal Oxide R2518 VRS-CZ1JF223J 22k 1/16W Metal Oxide R3422 VRS-CZ1JF151J 150 1/16W Metal Oxide R2519 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide R2520 VRS-CZ1JF474J 470k 1/16W Metal Oxide...
  • Page 99 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code R4442 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide R8807 VRS-CZ1JF000J 1/16W Metal Oxide R4443 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide R8808 VRS-CZ1JF000J 1/16W Metal Oxide R4444 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide...
  • Page 100 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code C3709 VCSATA0JJ106M 6.3V Tantalum Q608 VSFMG12////-1 FMG12 C3710 VCKYCZ1CB103K 0.01 16V Ceramic Q609 VSHN2C01FU/-1 HN2C01FU C3711 VCKYCZ1CB103K 0.01 16V Ceramic Q3701 VSHN2C01FU/-1 HN2C01FU C3712 VCKYCZ1HB102K 1000p 50V Ceramic...
  • Page 101 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code R621 VRS-CZ1JF682J 6.8k 1/16W Metal Oxide R3769 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide R623 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide R3770 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide R624 VRS-CZ1JF122J 1.2k 1/16W Metal Oxide...
  • Page 102 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code R6637 VRS-CZ1JF183J 18k 1/16W Metal Oxide L102 VPAWM100K1R5N Peaking, 10µH R6638 VRS-CZ1JF333J 33k 1/16W Metal Oxide L1001 VPAWM220K2R7N Peaking, 22µH R6639 VRS-CZ1JF153J 15k 1/16W Metal Oxide CAPACITORS...
  • Page 103 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code VRS-CZ1JF562J 5.6k 1/16W Metal Oxide COILS AND TRANSFORMER VRS-CZ1JF000J 1/16W Metal Oxide L1800 VPD9M470J6R6N Peaking, 47µH VRS-CZ1JF000J 1/16W Metal Oxide L9800 RCiLP0323TAZZ Coil, 4.7µH VRS-CZ1JF000J 1/16W Metal Oxide...
  • Page 104 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code MISCELLANEOUS PARTS R313 VRS-CZ1JF822J 8.2k 1/16W Metal Oxide SC1800 QSOCN1572TAZZY Socket, 15Pin R314 VRS-CZ1JF101J 100 1/16W Metal Oxide SC1801 QSOCN1571TAZZY Socket, 32Pin R315 VRS-CZ1JF102J 1/16W Metal Oxide...
  • Page 105 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code LX-WZ1071GE02 CW ø 0.7 ø 1.8t0.1 MECHANISM PARTS LX-WZ1104GE06 CW ø 0.7 ø 2.2t0.25 LX-WZ1029GE00 CW ø 1.2 ø 3t0.25 LCHSM0181GEZZ Main Chassis Ass’y LZ-WZ1105GE00 W ø 1.2 ø 2.5t0.13...
  • Page 106 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code CABINET PARTS LIST 3-1-6 MSPRP0222TAFJ VF Diopter Adjusting Spring CCABA6231TAK1 Cabinet A Ass’y 3-1-7 PLNSV0009TAN3 VF Lens 3-1-8 PSHEP0245TAZZ VF Diopter Covering Sheet AD DCOVA1798TAK2 Battery Cover Service...
  • Page 107 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code PSPAZ0421TAZZ Sound Insulation Spacer C AB LX-HZ0075TAFD M1.7 X 4.5 Special Screw AA PSPAZ0422TAZZ Sound Insulation Spacer D AC (Colored Zinc) PLNSA0147TAN1 Lens Unit XiPSC17P05000 M1.7 X 5 Small Screw...
  • Page 108 VL-AX1S/H/E/EW/EX Ref. No. Part No. Description Code Ref. No. Part No. Description Code SUPPLIED ACCESSORIES ACCESSORIES å QACCB0016TAZZ AC Cable(AX1H/EW) å QACCK0006TAZZ AC Cable(AX1S/E) å QACCL0026TAZZ AC Cable(AX1EX) å UADP-0321TA01 AC Adapter CDSKA0080TA01 SD Card(8M) GCOVA1767TASA Lens Hood GCOVH1270TASA Lens Cap...
  • Page 109 VL-AX1S/H/E/EW/EX MECHANISM CHASSIS EXPLODED VIEW Ref. No. Part No. Description Code Ref. No. Part No. Description Code 1pc. 411~ 411~ +0.5 +0.5...
  • Page 110 VL-AX1S/H/E/EW/EX CABINET EXPLODED VIEW Ref. No. Part No. Description Code Ref. No. Part No. Description Code 5-1-8 5-1-9 3-17 5-1-3 3-1-2 3-14 5-1-5 5-1-7 3-15 3-10 3-11 3-13 3-1-7 5-1-10 3-1-4 5-10 5-1-6 3-16 3-1-6 5-11 3-1-5 5-1-12 3-12 3-1-3...
  • Page 111 VL-AX1S/H/E/EW/EX CASSETTE CONTROL EXPLOOD VIEW Ref. No. Part No. Description Code Ref. No. Part No. Description Code 4±0.5 8.5±0.5 CAMERA UNIT EXPLOOD VIEW...
  • Page 112 VL-AX1S/H/E/EW/EX VL-AX1S/H/E/EW/EX SERVICE JIG SPECIFICATIONS Ref. No. Part No. Description Code Ref. No. Part No. Description Code 1-1. Adjusting jigs for checking the mechanism Name New part Type number, Application Part code Code PB-use cassette torque meter 1mN·m/1.5mN·m 9DASD-1015 Torque gauge...

  • Page 113: Packing Of The Set

    VL-AX1S/H/E/EW/EX 17. PACKING OF THE SET Ref. No. Part No. Description Code Ref. No. Part No. Description Code No.19 No.10 No.2 No.11 No.6 No.9 No.26 No.8 No.23 No.30 No.1 No.4 No.18 No.3 No.17 No.27 No.28 No.25 No.5 No.24 No.29 No.7, No.12, No.13, No.14, No.15, No.16,...
  • Page 114 Part No. Description Code © COPYRIGHT 2002 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
