- Page 1 LANCIA MULTIMEDIA SYSTEM USER MANUAL Model number: D721AL Date of release: Version number: v1...
-
Page 2: Tips, Controls And General Information
TIPS, CONTROLS AND GENERAL INFORMATION ROAD SAFETY Learn how to use the various system functions before setting off. Read the instructions for the system carefully before setting off. WARNING It can be dangerous if the volume is too high. Adjust the volume so it can still be heard background noises (e.g. -
Page 3: Front Panel Controls
Video Codec Name Profile Level Limitation Simple Profile For Advanced Simple profile, only MPEG4 one point GMC is supported. Advanced Simple Profile For Baseline profile with SGM, Baseline profile the width limitation is 1280. H264 L 4.1 Main profile For Baseline profile without SGM, the width limitation is 4096. - Page 4 Button Function Description Press the button to turn on the device, press and hold for 2 Switching On/Off, seconds to turn it off. Increase or decrease the volume via turning Volume Adjustment & the knob clockwise or anti-clockwise respectively. Press the Back to Main Menu button to go back to main menu in any selected menu.
-
Page 5: Steering Wheel Controls
STEERING WHEEL CONTROLS Button Function Description Press the button for the activation/deactivation of the volume. To cut off the microphone device during BT (Bluetooth®) call, press the button to activate Mute Button mute function. This allows to hear the interlocutor but not being heard from it. Press the mute button again to deactivate the function. - Page 6 Radio Mode Selection In radio main screen, press “ ” button on the front panel or “FM/AM, AM/DAB, DAB/FM” to switch to the bands AM,FM and DAB. Each tuning mode can have a specific preselection set. Radio Station Selection In radio main screen turn button/knob or press button on screen to search for the desired radio station.
- Page 7 AM/FM/DAB Radio Station Tuning Press the icon to enter Direct Tune menu. The graphic keyboard on the display is used to enter the frequency of the station. In this mode, use buttons + and – to fine-tune the frequency. Press button to delete a wrong number (and enter the correct station frequency).
-
Page 8: Media Mode
All stations Press “all stations”, to see all the DAB broadcasts. Genres Press “Genres”, to choose various types of DAB radio programs, such as weather, finance, children, religion, etc. Ensembles Press “Ensembles”, to scroll through the DAB ensembles groups MEDIA MODE Press “... -
Page 9: Song Information
To play audio/photo files via USB, the corresponding device must be connected to the USB port on the radio, if needed via a required cable. When a USB / iPod device is plugged in while the system is on, tracks stored on USB/iPod are available to play. - Page 10 Shuffle Press button to play the tracks in a random order. Press again to deactivate this function. Shuffle function can be available only if the USB or Bluetooth® device supports this function. Repeat Song Press button repeatedly to cycle between Repeat One, Repeat All and Repeat OFF in loop. Repeat function can be available if the USB or Bluetooth®...
-
Page 11: Phone Mode
PHONE MODE Activating Phone Mode Press “ ” button on the front panel or on the main screen to activate phone mode. Key Features: ➢ Dialing the number of the person wanted to be called. ➢ Contacts on the phone book of the cell phone can be viewed and called. ➢... - Page 12 ➢ Activate Bluetooth® function of the mobile phone. ➢ Press button of the radio in front panel in Home Page. ➢ Press Button if any cell phone device is not paired previously yet. ➢ Search for “LANCIA_XXXX” on mobile phone after button is pressed to start pairing.
- Page 13 After the first phone data transmission, the procedure for transmitting and updating the phonebook (if supported) starts as soon as a Bluetooth® connection is established between mobile phone and system. This downloaded phonebook cannot be edited on the multimedia system. It can only be edited on the mobile phone.
- Page 14 Deleting A Phone or Audio Device To delete a mobile phone or Bluetooth® audio device from a list, proceed as follows: ➢ Press the button on the front panel. ➢ Select button on the display. ➢ Select the specific device from the "Paired Devices List”. ➢...
- Page 15 PHONE CALL FEATURES The following features can be accessed through the Multimedia system if the feature(s) are available and supported by Bluetooth® on your mobile service plan. For example, if your mobile service plan provides three-way calling, this feature can be accessed through the Multimedia system. Check with your mobile service provider for the features that you have.
- Page 16 Dialing the phone number using the "keypad" button Enter the phone number using the graphic keyboard displayed. Proceed as follows: ➢ Press the button on the touchscreen in Phone Main Menu; ➢ Use the numbered buttons to enter the number; ➢...
- Page 17 Answering an incoming call during an active conversation To answer an incoming call while another phone conversation is in progress, press the "Hold” button to put the ongoing call on hold and answer the new incoming call. Press “Reject” button to close the ongoing call and answer the new incoming call. Press “Ignore”...
- Page 18 Managing two Phone Calls If two calls are in progress (one active and one on hold), it is possible to switch between them pressing the "Switch”" button or to merge the two calls in a conference pressing the "Join" button. Note Check whether the telephone in use supports the management of a second call and the "Conference"...
-
Page 19: Activation/Deactivation Of The Microphone
Continuing a Phone Call After the engine is switched off, if in the power off delay setting it is selected the 20 minutes option it is still possible to continue a phone call. The call continues until it is ended manually or for a maximum period of about 20 minutes. - Page 20 WARNING! When Apple Car play/Android Auto apps are enabled by the user, the scrolling function via rotary knob is not available. Android Auto APP Setup Before use, download the Android Auto application to your smartphone from Google Play Store. The application is compatible with Android 5.0 (Lollipop) and later versions.
- Page 21 Apple CarPlay is compatible with the iPhone 5 or more recent models, with the iOS 7.1 operating system or latter versions. Before using Apple CarPlay, enable Siri from "Settings" General Siri on the smartphone. To use Apple CarPlay, the smartphone must be connected to the car with a USB cable. Note: ➢...
- Page 22 Settings Press button to enter the Settings menu. The menu includes the following items: Audio Audio related settings are located under this function. (Touch sound, Loudness, Equalizer, Balance & Fader, Volume, Speed Volume Control) Touch Sound Press the relevant button to activate/deactivate the acoustic signal when the buttons on the display are pressed. Loudness To activate/deactivate the "Loudness"...
- Page 23 Equalizer Select "Equalizer" on the display to adjust the bass, middle and treble tones. Use the "+" or "–" buttons to carry out the settings desired. Tapping on the bass middle or treble bar also is possible to change the value. Then press button to return to the "Audio"...
- Page 24 Speed Volume Control "Off" and "1, 2 or 3". The option selected is displayed. Choose "1, 2 or 3" to increase the volume proportionally to vehicle speed. Then press button to return to the "Audio" menu. Press button to cancel and exit this screen. Radio Alternative Frequency and Traffic Announcement functions can be activated/deactivated under Radio settings.
- Page 25 AF Setting Press the “AF Setting” button for activation/deactivation of the automatic tuning of the strongest signal for the currently broadcasted station. TA Setting Press the “TA Setting” button for activation/deactivation of the automatic tuning of the traffic announcements. DAB Announcements Press the "DAB announcements"...
-
Page 26: Android Auto
Luminance Press the "Luminance" button to set the display brightness according to "Day", "Night" condition. AutoPlay AutoPlay is a feature of the multimedia system that automatically begins playing music of the USB device, as soon as it is connected. This feature can be turned on or off in this menu. Its default setting is on. Power Off Delay To keep the radio on for 20 minutes after the ignition key is turned to STOP. - Page 27 Restore Settings Reset the radio to the factory settings will erase all the settings previously defined by the user. Confirm to reset the device to the factory settings. Wait for a short time for the factory settings to be restored. Notes: ➢...
- Page 28 .daiichi.com/about/ https://w w w .daiichi.com/about/ Daiichi Elektronik San. ve Tic. A.S. igazolja, hogy a D721AL típusú Hér, Daiichi Elektronik San. ve Tic. A.S. lýsir yfir að radíóbúnaður gerð D721AL er í Magyar Islenska rádióberendezés megfelel a 2014/53/EU irányelvnek.
