Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or minor)
and the occurrence of injury (definitely occurs or has the potential to occur) when the warning is
ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.
Basic safety precautions should be followed, including the following:
Ensure all local, state, and federal laws and codes including health and safety guidelines are met when
installing Waterlogic Equipment. Only qualified service technicians should attempt installation and
service of Waterlogic Equipment. Always read the entire operating instructions before using the
appliance and save these instructions for future use.
DANGER! ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly grounded outlet. Unit
should be protected by ground‐fault circuit interrupter (GFCI) or residual current device (RCD) having
a rated residual operating current not exceeding 30mA. Use only Waterlogic supplied power cord.
Never use extension cords or power strips to connect unit. Do not use if the power supply cord is
damaged. Always unplug from power supply prior to servicing.
WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual and untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can't be used by children and persons
with reduced physical, sensory or mental capabilities or lack of experience.
WARNING! UV‐C EMITTER (UV LAMP). This appliance contains a UV‐C emitter (UV Lamp).
UV‐C radiation may, even in little doses, cause harm to the eyes and skin. Unintended use or damage
to the housing may result in the escape of dangerous UV‐C radiation. Never operate the UV‐C
emitter if damaged or removed from enclosure. Do not touch or look directly into the faucet.
WARNING! DO NOT OPERATE IF DAMAGED. Unplug and isolate water supply if abnormal conditions
exist. Contact Waterlogic or authorized dealer for repair, service, and installation to avoid hazards.
CUBE Manual
SAFETY ALERT SYMBOLS
SAFETY PRECAUTIONS
Page 4 – Revision 10‐8‐2018
Advertisement
Related Manuals for WaterLogic CUBE
Summary of Contents for WaterLogic CUBE
- Page 1 WARNING! Indicates a situation which, when not avoided, has the potential to result in death or severe injury; and/or severe property damage. CAUTION! Indicates a situation which, when not avoided, results or has the potential to result in minor injury; and/or minor property damage. SAFETY PRECAUTIONS Basic safety precautions should be followed, including the following: Ensure all local, state, and federal laws and codes including health and safety guidelines are met when installing Waterlogic Equipment. Only qualified service technicians should attempt installation and service of Waterlogic Equipment. Always read the entire operating instructions before using the appliance and save these instructions for future use. DANGER! ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly grounded outlet. Unit should be protected by ground‐fault circuit interrupter (GFCI) or residual current device (RCD) having a rated residual operating current not exceeding 30mA. Use only Waterlogic supplied power cord. Never use extension cords or power strips to connect unit. Do not use if the power supply cord is damaged. Always unplug from power supply prior to servicing. WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as described in this manual and untrained individuals who use this manual assume the risk of any resulting property damage or personal injury. This appliance can’t be used by children and persons with reduced physical, sensory or mental capabilities or lack of experience. WARNING! UV‐C EMITTER (UV LAMP). This appliance contains a UV‐C emitter (UV Lamp). UV‐C radiation may, even in little doses, cause harm to the eyes and skin. Unintended use or damage to the housing may result in the escape of dangerous UV‐C radiation. Never operate the UV‐C emitter if damaged or removed from enclosure. Do not touch or look directly into the faucet. WARNING! DO NOT OPERATE IF DAMAGED. Unplug and isolate water supply if abnormal conditions exist. Contact Waterlogic or authorized dealer for repair, service, and installation to avoid hazards. CUBE Manual Page 4 – Revision 10‐8‐2018 ...
- Page 2 WARNING! CONNECT TO POTABLE WATER SUPPLY. This system is to be used for water only and is not intended for use where water is microbiologically unsafe or with water of unknown quality without adequate disinfection before or after the system. WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITIZE BEFORE USE. The unit must be completely drained and sealed before storing to avoid stagnation and reduce microbiological contamination (potential bacterial growth). Sanitize before use to eliminate any potential microbiological contaminates CAUTION! INDOOR USE ONLY. Intended for household use only. Never expose to direct sunlight, heat sources, or ambient air temperature above 37°C (100°F) or below 2°C (35°F). Install indoors and keep unit away from excessive humidity. Never expose to freezing temperatures. Ensure there is adequate clearance around the unit to allow refrigeration system condenser to dissipate heat. Warmer environments require more clearance around the unit. Minimum clearance around all surfaces of the machine is 2‐inches. Installs where the ambient temperature exceeds 27°C (80°F), require a minimum of 4‐inches clearance for proper heat dissipation and efficient operation. CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or damage caused by excessive water pressure. Input or feed pressure must be 40 psi to 60 psi. Be aware of any potential pressure surges caused by building/municipal pumping stations. CAUTION! USE UV STABILIZED SUPPLY LINES. Feed the unit with a potable ambient or cold water supply only. Feed water over 37°C (100°F) can damage the treatment components. Water block devices and external leak detectors are strongly recommended. Locate the unit as close to the water supply and the electrical connections as possible. Locate the unit as close to the water supply and the electrical connections as possible. Immediately isolate or close water supply valve and contact service representative if leak is noticed. Contact Waterlogic for assistance or help finding an Authorized Service Representative. CUBE Manual Page 5 – Revision 10‐8‐2018 ...
- Page 3 CUBE FEATURES AND BENEFITS Firewall™ UV Purification Firewall™ proprietary technology purifies outgoing water at the point‐of‐ dispense. Firewall™ keeps the dispense nozzle free from external contamination as well as purifying the outgoing water, making the safest water possible every single dispense. Cold, Ambient, Hot, and Extra Hot Water Pressure Fed Ambient, Cold, Hot, and Extra Hot Selections to meet a wide range of customer demands. Volume Storage and Water Capacity 1.4 liters of Cold, 1.3 liters of Hot Water Storage. BioCote®Anti‐Microbial Protection Certain plastic, silicon, and painted surfaces surrounding the dispensing areas and drip tray are infused with an exclusive additive called BioCote®. BioCote® provides an effective barrier against microbes like bacteria and mold, which may cause odors or staining. Large Dispense Area with Recessed Faucet 6.4 inch dispense height with BioCote® recessed faucet to protect from cross‐contamination. Leak Sensor and Alarm Leak Sensor and Alarm Full Fault Mode that halts supply to prevent overflow and sounds alarm to reduce accident potential. Digital Display The CUBE has an innovative user interface utilizing a LCD display for easy use Water Treatment System and programming. Advanced Programming Customizable settings for optimizing each CUBE including; Cold Temp Set Point, Water Treatment System Hot Temp Set Point, UV Timer, Filter Timer Setting, Filter Life Monitor, , and ...
- Page 4 CUBE CERTIFICATIONS Waterlogic Water Treatment Systems have been tested, and certified to rigorous NSF and UL Standards. We believe that performance testing and certifications validate Waterlogic as a world‐ leader in water treatment systems. CUBE Water Treatment System Certifications Include UL399 – Certified Drinking Water Cooler Intertek Labs (ETL) Certified the CUBE to ANSI/UL 399 Standard for Water Treatment System Drinking Water Coolers. CSA C22.2 No. 120 CSA Standard for Refrigeration. NSF/ANSI‐55 Class A –Ultraviolet Microbiological Water Treatment Systems Water Quality Association is an international standards organization. Firewall™ Technology contains our latest, most innovative and patented breakthrough, “The Firewall™”, the most comprehensive UV purification system for point‐of‐use water treatment systems ever developed. The Waterlogic Firewall™ components has been tested and certified by the Water Quality Association (WQA) to NSF/ANSI‐55 Class A – Ultraviolet Microbiological Water Treatment Systems, and to NSF/P231 and the USEPA Standard for Microbiological Water Purifiers. NSF P231 –Protocol for Microbiological Purifiers The Public Health and Safety Organization establishes minimum requirements for health and sanitation characteristics of microbiological water purifiers. The requirements are based on the recommendations of the U.S. Environmental Protection Agency's Task Force Report. NSF/ANSI‐42 – Chlorine, Taste and Odor Reduction NSF/ANSI‐53 – Lead and Cyst Reduction The Public Health and Safety Organization establishes minimum requirements for materials, design, construction, and performance of drinking water treatment units that are designed to reduce specific aesthetic‐related contaminants in public or private water supplies. BPA Free ‐ Waterlogic tests for BPA and declares that all of its products are Bisphenol‐A FREE and contain no harmful BPA plastics. ...
-
Page 5: Specification
MODEL/PART DESIGNATIONS BRAND NAME DESCRIPTION Waterlogic CUBE – Ambient, Cold, Hot, and Extra Hot Model F‐FWCU1‐M‐HCA‐TT‐SB‐IN1 CUBE Water Treatment System Serial Number Prefix: 81 or TC2H316SB SPECIFICATIONS SPECIFICATION ITEM Water ¼” Quick Connect Cold Water Temperature – Factory Set Point 5°C (41°F) Cold Water Temperature (Adjustable) 10°C or 15°C (50°F or 60°F) Cold Water Capacity 1.4 Liter (0.37 Gallons) Cold Tank Factory Set Point 86°C (187°F) Hot Water Temperature Programmable 70° ‐ 95°C (158° ‐ 203°F) Hot Water Capacity 1.3 Liter (0.34 Gallons) Hot Tank Extra Hot Water Temperature Factory Set Point 95°C (203°F) Hot Tank Manual Reset Overload 105°C (221°F) Recommended Incoming Feed 40‐60 psi (275‐414 kPa) – Use Pressure Regulator Pressure Maximum Working Pressure 60 psi (414 kPa) – Use Pressure Regulator Rated Service Flow Out 0.42 gallons per minute (1.6 Lpm) ‐ Firewall™ Purification ... -
Page 6: Shipping Specifications
SHIPPING SPECIFICATIONS SPECIFICATION ITEM Width/Depth/Height 356 mm (14 inches) x 483 mm (19 inches) x 432mm (17 inches) Weight – Dry (w/o 15 kg (30 pounds) packaging) Shipping Information 508 mm (20 inches) x 560 mm (22 inches) x 560 mm (22 inches) Width/Depth/Height 8 units per pallet Shipping Weight – Dry 19 kg. (41 pounds) #CUBE is 17 inches tall and may not fit between countertops and cabinets ‐ Check installation to ensure adequate clearance. ELECTRICAL SPECIFICATIONS ELECTRICAL SUPPLY 120V/60Hz 15 Amp Service COMPONENT POWER (approximate) AMP DRAW (approximate) Heater 500 Watts 4.2 Amps Compressor 210 Watts 1.75 Amps UV Lamp System 13 Watts 0.11 Amps CUBE TOTAL 723 Watts 6.06 Amps ... - Page 7 OPERATING INSTRUCTIONS The above picture shows front LCD display and control panel for the Waterlogic CUBE Water Treatment System. Button Operational Use Select Cold Water Selection + Press and Hold Dispensing Button to start dispensing until desired fill. Select Ambient Water Selection + Press and Hold Dispensing Button to start dispensing until desired fill. Press and Hold Hot Water Selection for 3 seconds, until the Hot Water Icon is illuminated. Press + Press and Hold Dispensing Button until desired fill. The delay is a safety feature that prevents hot water from ...
- Page 8 1. Place your cup centrally in the dispense area which is 163 mm (6.4 inch) dispense height. The Drip Tray can be removed for filling bottles or other containers larger than the dispense area. 2. Select the type of water you wish to be dispensed by press/touching the Cold, Ambient or Hot water select icon until it illuminates. 3. Select the Dispense Button in the middle of the panel to dispense water. 4. Water Selection is dispensed via a Push‐To‐Dispense method. Press and hold the dispense button until your cup has reached the desired level. WARNING! Unit produces Very Hot Water up to 95°C (203°F). Water above 52°C (125°F) can cause severe burns or scalding. Keep unauthorized people and children away from the unit to avoid accidental dispensing of hot water. Children should not use without supervision. WARNING! Always use a ceramic cup or a cup suitable for use with hot water. WARNING! Do not hold cup or place hands in dispensing area while dispensing hot water. WARNING! Never try to fill more than one cup at a time. CUBE Manual Page 11 – Revision 10‐8‐2018 ...
- Page 9 Waterlogic and its affiliated companies hereby limit the duration of any and all implied warranties to a maximum period of three (3) years from the date of purchase including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Consequential and incidental damages are not recoverable under this warranty. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights which may vary from state to state. New Warranty Policy issued by Waterlogic Commercial Products LLC, USA ‐ January 10, 2014 Waterlogic Commercials Products LLC Tel: (800) 288‐1891 11710 Stonegate Circle Website: waterlogic.us Omaha, NE 68164 CUBE Manual Page 12 – Revision 10‐8‐2018 ...
