1. ON/Off switch
2. SmartSelect
Button
3. Removable
Water Tank
4. Handle Tube
5. Steam Head
6. Micro-Fiber
Cleaning Pad
7. Lift and Reach
Head Cleaning Pad
NOTICE:
Each steam mop is 100% tested in the factory to ensure product
performance and safety. When assembling your new steam mop for the first time you
may notice water residue inside of the unit.
WARNING:
appliance is switched off and unplugged and that the
appliance is cold and contains minimal or no water.
ATTACHING THE HANDLE - Fig. B & K
• With the cord hooks (21 & 22) toward the back of the
appliance, slide the bottom end of the handle tube (4)
into the top end of the steam mop body (11) until it is
firmly seated and clicks into place.
ATTACHING THE STEAM HEAD - Fig. C
• Slide the bottom end of the steam mop body (11)
onto the steam head (5) until it clicks into place.
• The steam head can be removed from the steam
mop body by pressing the steam head release
button (13) and pulling the steam mop body off the
steam head.
ATTACHING THE WATER TANK
• Clip the water tank (3) onto the handle (4).
• Slide the water tank down into the steam mop body
(11), ensure that the water tank is firmly seated.
FUNCTIONAL DESCRIPTION
A
TM
Before attempting any of the following operations, make sure that the
ASSEMBLY
4
B
C
