MARINE DIGITAL MEDIA RECEIVER
RÉCEPTEUR MEDIA AUDIO MARIN
RECEPTOR DE MEDIOS DIGITALES MARINO
MVH-MS310BT
Important (Serial number)
The serial number is located on the bottom of this unit. For your own security and convenience, be sure to
record this number on the enclosed warranty card.
Important (Numéro de série)
Le numéro de série se trouve au bas de cet appareil. Pour votre sécurité et votre commodité, veillez à noter ce
numéro sur la carte de garantie fournie.
Importante (Número de serie)
El número de serie se encuentra en la parte inferior de esta unidad. Por su propia seguridad y comodidad,
asegúrese de anotar este número en la tarjeta de garantía que se adjunta.
Operation Manual
Mode d'emploi
Manual de operación
Advertisement
Table of Contents
Related Manuals for Pioneer MVH-MS310BT
Summary of Contents for Pioneer MVH-MS310BT
- Page 1 MARINE DIGITAL MEDIA RECEIVER RÉCEPTEUR MEDIA AUDIO MARIN RECEPTOR DE MEDIOS DIGITALES MARINO MVH-MS310BT Operation Manual Mode d’emploi Manual de operación Important (Serial number) The serial number is located on the bottom of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card.
-
Page 2: Table Of Contents
Getting Started ..................3 Radio ......................7 USB/iPhone®/AUX..................8 Bluetooth ....................10 Pandora® ....................14 Spotify® ....................16 Using Pioneer Smart Sync/APP............17 Audio Adjustments ................21 Settings ....................21 FUNCTION settings ................22 AUDIO settings ..................23 SYSTEM settings ..................25 ILLUMINATION settings................ -
Page 3: Getting Started
Getting Started Basic operation MVH-MS310BT (navigation)/LIST USB port M.C. (multi-control) dial SRC (source)/OFF DISP (display) Detach button BASS Display window BAND/ AUX input jack (3.5 mm stereo jack) Optional remote control The marine wired remote control CD-ME300 is sold separately. - Page 4 Appears when a Bluetooth connection is made (page 10). Appears when a Pioneer Smart Sync connection is made (page 17). Detaching the front panel Detach the front panel to prevent theft. Remove any cables and devices attached to the front panel and turn off the unit before detaching it.
- Page 5 Resetting the microprocessor The microprocessor must be reset in the following situations: – Before using this unit for the first time after installation – If the unit fails to operate properly – When strange or incorrect messages appear on the display Remove the front panel (page 4).
- Page 6 [QUIT :YES] appears. To return to the first item of the setup menu, turn the M.C. dial to select [QUIT :NO], then press to confirm. Press the M.C. dial to confirm the settings. NOTE These settings can be made at any time from the SYSTEM settings (page 25). Canceling the demonstration display (DEMO OFF) Press the M.C.
-
Page 7: Radio
Menu Item Description SYSTEM UPDATE Select [SYSTEM INFO] to confirm the latest system information on the unit. [SYSTEM INFO], [S/ Select [S/W UPDATE] to update the unit to the latest software W UPDATE] and initialize the unit settings. For details on the latest software and updating, visit our website. -
Page 8: Usb/Iphone®/Aux
NOTE [SEEK] needs to be set to [MAN] in the FUNCTION settings (page 22). To store stations manually While receiving the station you want to store, press and hold one of the number buttons (1/ to 6/ ) until it stops flashing. USB/iPhone®/AUX (iPhone source is not available when [USB MTP] is set to [ON] in the SYSTEM settings (page 27).) - Page 9 MTP connection A device installed with Android OS 4.0 or most of later versions can be connected to the unit via MTP, using the cable supplied with the device. However, depending on the connected device, OS version or the numbers of the files in the device, audio files/songs may not be able to be played back via MTP. Note that MTP connection is not compatible with WAV file formats and FLAC file formats, and cannot be used with the MIXTRAX function.
-
Page 10: Bluetooth
MIXTRAX settings, see page 28. NOTES • iPhone needs to be connected with Pioneer Smart Sync via USB for using this function (page 17). • Depending on the file/song, sound effects may not be available. Press 3/MIX to turn MIXTRAX on/off. - Page 11 Select the unit name shown in the device display. Make sure the same 6-digit number appears on this unit and the device, then select [YES] if the 6-digit numbers displayed on this unit and the device are the same. Bluetooth telephone First, make a Bluetooth connection with the Bluetooth telephone (page 10).
- Page 12 For details on the voice recognition features, refer to the manual supplied with your device. When a Pioneer Smart Sync connection is made (page 17), you can also use the voice recognition function from Pioneer Smart Sync installed on your iPhone/Android device by pressing and holding .
- Page 13 Menu Item Description PHONE BOOK Display the contacts in your phone. PRESET 1-6 Recall the preset phone numbers. You can also recall the preset phone numbers by pressing one of the number buttons (1/ to 6/ A.ANSR* Select [ON] to answer an incoming call automatically. [ON], [OFF] PB INVT Invert the order of names in the phone book (name view).
-
Page 14: Pandora
Pandora® (Not available when [USB MTP] is set to [ON] in the SYSTEM settings (page 27).) Pandora music is a music service not affiliated with Pioneer. More information is available at http://www.pandora.com. The Pandora mobile application is available for iPhone and Android phones. Please visit www.pandora.com/everywhere/mobile for the latest compatibility information. - Page 15 Press SRC/OFF to select [PANDORA]. Press and hold 1/ to display [APP CONTROL]. Turn the M.C. dial to select one of the below. • Select [WIRED] for the USB connection. • Select [BLUETOOTH] for the Bluetooth connection. Press SRC/OFF to select [PANDORA]. Launch the Pandora application on the mobile device and start playback.
-
Page 16: Spotify
Spotify® (Not available when [USB MTP] is set to [ON] in the SYSTEM settings (page 27).) Spotify is a music streaming distribution service not affiliated with Pioneer. More information is available at http://www.spotify.com. The Spotify application is available for compatible smartphones, please visit https:// support.spotify.com/ for the latest compatibility information. -
Page 17: Using Pioneer Smart Sync/App
Pioneer Smart Sync is the application that intelligently brings your favorite marine application, messages, and music together in the boat. You can operate the unit from Pioneer Smart Sync installed on an iPhone/Android device. In some cases, you can control aspects of the application, such as source selection, pause, etc., by using the unit. - Page 18 For details on what operations are available on the application, see the application’s help section. NOTE The APP source is not available when a Pioneer Smart Sync connection is not made or [USB MTP] is set to [ON] in the SYSTEM settings (page 27). WARNING Do not attempt to operate the application while driving.
- Page 19 • The 31 Band EQ setting is converted into 13 bands when a music source from this product is engaged. It is recommended to enter the search term "Pioneer Smart Sync" in the search field to search for the application.
- Page 20 • When you connect a mobile device other than an iPhone/Android device, it may not operate correctly depending on your mobile device. • If Pioneer Smart Sync has not been installed on your iPhone/Android device yet, a message that prompts you to install the application will appear on your iPhone/Android device (except for the Android device connected via Bluetooth).
-
Page 21: Audio Adjustments
Audio Adjustments You can also make various adjustments in the AUDIO settings (page 23). Adjusting the cut-off frequency value and the slope value You can adjust the cut-off frequency value and the slope value of each speaker. The following speakers can be adjusted. [FRONT], [REAR], [SUBWOOFER] NOTE [SUBWOOFER] can only be selected when [ON] is selected in [SUBWOOFER] (page 23). -
Page 22: Function Settings
• FUNCTION settings (page 22) • AUDIO settings (page 23) • SYSTEM settings (page 25) • ILLUMINATION settings (page 28) • MIXTRAX settings (page 28) Turn the M.C. dial to select the options, then press to confirm. FUNCTION settings The menu items vary according to the source. Menu Item Description Store the six strongest stations on the number... -
Page 23: Audio Settings
PLAY Start playback. STOP Stop playback. AUDIO settings NOTE [CHK APP SETTG.] may be displayed when the setting is performed from Pioneer Smart Sync. Menu Item Description EQ SETTING [SUPER BASS], [POWERFUL], Select or customize the equalizer curve. [DYNAMIC], [NATURAL], [VOCAL], •... - Page 24 [CROSSOVER], [SPEAKER LEVEL], [EQ SETTING], [POSITION], [TIME ALGNMNT], [D.BASS], [SUBWOOFER]. • The settings that can be saved differ when a Pioneer Smart Sync connection is made. LOAD SETTINGS Load the sound settings, when you have already performed [SAVE SETTINGS].
-
Page 25: System Settings
CLOCK SET [12H], [24H] Set the clock (page 5). • This setting is not available when a Pioneer Smart Sync connection is made. BEEP TONE [ON], [OFF] A beep can be heard when any button is pushed. - Page 26 Menu Item Description INFO DISPLAY [SOURCE/SPEANA], [CLOCK/ Display the item on the sub information display. SPEANA], [SRC/LIVE FX], [CLOCK/ • When [SOURCE/SPEANA] or [CLOCK/SPEANA] is LIVE FX], [SOURCE], [SPEANA], selected, display the antenna instead of the [OFF] speana on the radio source. [ON], [OFF] Set to [ON] when using an auxiliary device connected to the unit.
- Page 27 The available sources differ depending on the setting value. Please set [APP CONTROL] according to the table for the source you want to use. For details on Pioneer Smart Sync connection, see page 17. When Pioneer Smart Sync connection is NOT performed...
-
Page 28: Illumination Settings
ILLUMINATION settings Menu Item Description DIM SETTING [SYNC CLOCK], [MANUAL] Select the way to change the display brightness. BRIGHTNESS [1] to [10] Change the display brightness. The available setting ranges differ depending on [DIM SETTING]. MIXTRAX settings Menu Item Description SHORT PLAYBCK [1.0 MIN], [1.5 MIN], [2.0 MIN], Select the length of the playback time. -
Page 29: Additional Information
ON again. If the message remains, – Select the repeat play range again. contact your dealer or an authorized Pioneer Service Station for assistance. A subfolder is not played back. → Subfolders cannot be played when NO XXXX (NO TITLE, for example) [FLD] (folder repeat) is selected. - Page 30 SKIPPED ERROR-23 → The connected USB device contains → USB device was not formatted properly. DRM protected files. – Format the USB device with FAT12, – The protected files are skipped. FAT16 or FAT32. PROTECT ERROR-16 → All the files on the connected USB →...
- Page 31 Pandora – Wait until Pandora allows you to skip again. ERROR-19 UPDATE APP → Communication failed. → This version of the Pandora application – Disconnect the cable from the device. is not supported. Once the device’s main menu is – Connect a device that has a displayed, reconnect the device and compatible version of the Pandora reset it.
- Page 32 USB storage device • Connections via USB hubs are not CONNECT APP supported. → Pioneer Smart Sync connection is not • Firmly secure the USB storage device made. before driving. – Make a connection with Pioneer Smart • Depending on the USB storage device, Sync (page 17).
- Page 33 File extension .wav CAUTION Quantization bits 8 and 16 (LPCM) • Pioneer cannot guarantee compatibility Sampling frequency 16 kHz to 48 kHz (LPCM) with all USB mass storage devices, and assumes no responsibility for any loss of AAC files data on media players, smartphones, or other devices while using this product.
- Page 34 Quantization bit rate 8/16/24 bit CAUTION Channel mode 1/2 ch Pioneer accepts no responsibility for data USB device lost on the iPhone, even if that data is lost while this unit is used. • There may be a slight delay when starting...
- Page 35 Inc. and any use of such marks by PIONEER NOT LIMITED TO, THE IMPLIED CORPORATION is under license. Other WARRANTIES OF MERCHANTABILITY AND trademarks and trade names are those of their FITNESS FOR A PARTICULAR PURPOSE ARE respective owners. DISCLAIMED. IN NO EVENT SHALL THE...
- Page 36 Chassis: 178 mm × 50 mm × 97 mm (7 MIXTRAX in. × 2 in. × 3-7/8 in.) MIXTRAX is a trademark of the PIONEER Nose: 188 mm × 58 mm × 17 mm (7- CORPORATION. 3/8 in. × 2-1/4 in. × 5/8 in.) Spotify®...
- Page 37 Time alignment: Bluetooth profiles: 0 Inch to 140 Inch (1 inch/Step) GAP (Generic Access Profile) SDAP (Service Discovery Application Profile) USB standard specification: USB 2.0 full HFP (Hands Free Profile) 1.6 speed PBAP (Phone Book Access Profile) Maximum current supply: 1.5 A A2DP (Advanced Audio Distribution USB Protocol: Profile)
- Page 38 © 2019 PIONEER CORPORATION. All rights reserved. © 2019 PIONEER CORPORATION. Tous droits de reproduction et de traduction réservés. <QRI3211-B> UC...
- Page 39 Installation Manual Manuel d’installation Manual de instalación...
- Page 40 TWO 6-1/2” MARINE FULL RANGE SPEAKERS DEUX HAUT-PARLEURS MARINS DE 6.5” DOS BOCINAS 6-1/2 MARINAS DE RANGO COMPLETO TS-MR1600 - 1 -...
- Page 41 © 2019 PIONEER CORPORATION. All rights reserved. © 2019 PIONEER CORPORATION. Tous droits de reproduction et de traduction réservés. - 2 -...
- Page 42 Consult your dealer on method of Determine the location of the speaker as Install the speakers as illustrated. English installation. illustrated. Speaker installation WARNING This product contains chemicals known to the State of California and other governmental entities to cause cancer and birth defects or other reproductive harm.
- Page 43 NOTE This product does not contain connecting cords and terminals. Specifications Reproduction system: Dual-cone Speaker specifications Size: ф 168 mm (6-1/2 in. Dia.) Water-resistant Injection-molded polypropylene cone Weatherproof & high-compliance, rolled edge Heat-resistant voice coil Gold-plated terminal Strontium magnet: 180 g (6.3 oz) Nominal impedance: 4 Ω...
