PREDATOR
Portable Air Scrubber
PRED750
Instruction Manual
Covered by one of more of the following:
U.S. PATENT No. 9,868,082
U.S. PATENT No. D742,495
ABATEMENT TECHNOLOGIES, INC.
Patent Pending CANADIAN PATENT No. 2,852,880
Abatement Technologies, Inc.
Abatement Technologies, Inc.
Abatement Technologies Limited
Georgia, USA
Ontario, Canada
800-634-9091
905-871-4720
www.abatement.com
PRED750_MN-AC
2018.04.18
Advertisement
Table of Contents
Related Manuals for Abatement Technologies PREDATOR PRED750
Summary of Contents for Abatement Technologies PREDATOR PRED750
- Page 1 Portable Air Scrubber PRED750 Instruction Manual Covered by one of more of the following: U.S. PATENT No. 9,868,082 U.S. PATENT No. D742,495 ABATEMENT TECHNOLOGIES, INC. Patent Pending CANADIAN PATENT No. 2,852,880 Abatement Technologies, Inc. Abatement Technologies, Inc. Abatement Technologies Limited Georgia, USA...
-
Page 2: Table Of Contents
© Abatement Technologies 2015 All Rights Reserved. No reproduction of any portion of this work is permitted without the express written permission of Abatement Technologies, Inc. READ AND SAVE THESE INSTRUCTIONS! Note: 1. Read and understand all operating instructions before using the Portable Air Scrubber. -
Page 3: Safety Instructions
Warning: To reduce the risk of fire, electric shock, or injury to person observe the following: Use this unit only in the manner intended by Abatement Technologies. If you have questions, contact Abatement Technologies at +1 800-634-9091 (U.S.) or +1 905-871-4720 (Canada). -
Page 4: General Information
Warning: Do not connect the unit’s power cord to a supply receptacle unless the inlet and power modules are in their proper position and latched together. Warning: Abatement Technologies air filtration systems are not intrinsically safe for use in hazardous environments. Always consult a certified industrial hygienist before using them. Do NOT use this... -
Page 5: Alternate Filter (Purchased Separately)
OVG can occur when the adsorption capacity of the filter is reached, replace the carbon filter as soon as odor breakthrough is sensed. More detailed information on carbon adsorption can be found in an article titled: “Activated Carbon: How Is It Used? How Does It Work?” which can be found on the Abatement Technologies website, www.abatement.com. -
Page 6: Electrical Requirements
ELECTRICAL REQUIREMENTS 1. The PRED750s require a minimum of 110 volts AC, 60 Hz to operate properly; however, maximum air flow performance requires 120 volts AC, 60 Hz. 2. Due to momentary start-up current surge, the unit requires a 15 amp circuit that is free of other loads. 3. -
Page 7: Key Component Descriptions
KEY COMPONENT DESCRIPTIONS 1. First Stage Filter. 1” Coarse/Particulate Pre-filter (P/N: F621). 5. Motorized Impeller. 2. Second Stage Filter. 2” Pleated Particulate Pre-filter (P/N: H502). 6. Filter Access Door. 7. Control Panel. Alternate Second Stage Filter. • 2” High Capacity Carbon Filter (P/N: VL1002). 8. -
Page 8: Control Panel
If the room air filtration units are being used to create and maintain a negative/positive pressure condition, the pressure differential between the negative/positive room and the environment outside the room should be monitored with a calibrated instrument as per OSHA/CDC requirements. The Abatement Technologies Portable Pressure Monitors are recommended to ensure that requirements are being met. -
Page 9: Stacking The Units
2. Turn Speed Control switch clockwise past the click at the “HIGH” setting to turn power “ON”. 3. Set Speed Control switch to desired setting. Note: Refer to the chart in this instruction manual entitled PRED750 SPECIFICATIONS that lists the airflows for the PRED750. -
Page 10: User Servicing Instructions
USER SERVICING INSTRUCTIONS Abatement Technologies’ portable air scrubbers are designed to be low maintenance devices and basic maintenance should be performed as follows: Filters should be changed as needed based on the filter change indicator light. Follow the FILTER •... -
Page 11: Component Replacement And Care Of The Unit
5. Close the pre-filter access door and lock it in position. Warning: Use only Abatement Technologies pre-filters, HEPA filters, and replacement parts. Substitute parts void the warranty, jeopardize worker and environmental safety, and adversely affect engineered performance levels. - Page 12 filter and before cleaning or servicing the unit. This unit is equipped with an automatic restart motorized impeller that will restart without warning after a temporary power interruption or recovery from a thermal overload (over-heating) condition. Keep clear of the motorized impeller at all times to reduce the risk of injury.
-
Page 13: Pred750 Specifications
PRED750 SPECIFICATIONS FEATURE SPECIFICATIONS Net weight with filters: 35 lbs. Shipping weight: 43 lbs. Unit dimensions: 22.5” L x 19.5” W x 20.5” H Power supply requirements: 120 VAC, 60 Hz, single phase, 15 A. Normal operating amps: 1.9 amps or less Integrated circuit breaker: 12 amps 258 watt motorized impeller with thermal overload protection, auto... -
Page 14: Troubleshooting Guide
Remove carbon filter from polybag. removed from polybag. Note: If the unit does not start or malfunctions after carefully following the TROUBLESHOOTING GUIDE, call Abatement Technologies service department at +1 800-634-9091 (U.S.) or +1 905-871-4720 (Canada) for assistance. -
Page 15: Certification Of Room Air Filtration Units
Nationally Recognized Testing Laboratory (NRTL). LIMITED WARRANTY Abatement Technologies, Inc (ATI) warrants that goods sold to the original user shall be free from defects in material and workmanship for a period of 1 year, except such as are commercially acceptable. This warranty does not include useful filter life. -
Page 16: Pred750 Diagrams
PRED750 DIAGRAMS...
