OWNER'S MANUAL: 600mm Wall-Mount Rack
THIS MANUAL APPLIES TO THE FOLLOWING SKUs: 00301461, 00301462, 00301463, 00301464
Keep this information for further reference.
Thank you for purchasing a NavePoint product. If you have any questions regarding the installation or use of your
product, please call us at 888.505.1363.
Please examine the product for any damaged parts. If any part is damaged or missing, contact NavePoint for assistance. Do not
attempt to install or use product if it has been damaged.
During installation, lay product contents on cardboard or other protective surface to avoid any damage.
Improper installation or use of this product could result in damage to the product, other equipment, or personal injury. It is
recommended that installation be performed by a qualified installer. NavePoint cannot be held responsible for damage to
equipment or personal injury resulting from improper use or installation of product. If product is intended to store/mount
equipment, please ensure the equipment stored/mounted does not exceed the specified weight capacity.
Limitations of Liability: In no event will Infinite Electronics International, Inc. be liable for any damages, whether direct or indirect,
special, punitive, incidental or consequential damages (including, but not limited to, lost profits or revenue, loss of use, lost
business opportunities or loss of goodwill) or for the costs of procuring substitute products, arising out of or in connection with
the use of the product, whether such liability arises from any claim based upon contract, warranty, tort (including negligence),
product liability or otherwise, whether or not seller has been advised of the possibility of such loss or damage. In no event will
seller's total cumulative liability, from all causes of action and all theories of liability, exceed the total amounts actually paid to
seller by customer under the order that gives rise to any liability hereunder.
Copyright © 2021 Infinite Electronics International, Inc. All Rights Reserved.
20211004
Advertisement
Related Manuals for NavePoint 00301461
Summary of Contents for NavePoint 00301461
- Page 1 Thank you for purchasing a NavePoint product. If you have any questions regarding the installation or use of your product, please call us at 888.505.1363. Please examine the product for any damaged parts. If any part is damaged or missing, contact NavePoint for assistance. Do not attempt to install or use product if it has been damaged.
-
Page 2: Parts Identification
B Vertical Mounting Rail (2x) C Depth Mounting Beam (2x) D Depth Mounting Beam (2x) E Wall Mounting Beam (2x) F Angle Support Beam (2x for 6U & 9U) (4x for 12U & 15U) 12-24 Mounting Screws 6U/9U (32x) 12U/15U (36x) www.NavePoint.com customerservice@navepoint.com... -
Page 3: Rack Assembly
For 12U or 15U, attach the 2x Angle Support Beams (F) to the 2x Depth Mounting Beams (C & D) and the Wall Mounting Beam (E) using 4x 12-24 Screws (G). [Repeat the steps above for the second side] www.NavePoint.com customerservice@navepoint.com... - Page 4 Assemble the rack mount frame to the side frames using 8x 12-24 screws (G) 6U and 9U final assembly should look like the photo to the right. 12U and 15U final assembly should look like the photo to the left. www.NavePoint.com customerservice@navepoint.com...
-
Page 5: Equipment Installation
Mounting holes are spaced 17" (432mm) as reflected in the diagram. Warning: Do not attempt to mount to wall when equipment is mounted inside rack. Make sure wall surface can hold weight of the cabinet and equipment. 4. Equipment Installation 1 Rack Unit www.NavePoint.com customerservice@navepoint.com... - Page 6 2 After installing the required cage nuts, use the included 12-24 threaded Mounting Screws to secure your equipment into the installed 12-24 threaded Cage Nuts. Tapped Hole Mounting Use the included 12-24 threaded Mounting Screws to secure your equipment to the Vertical Mounting Rails (B). www.NavePoint.com customerservice@navepoint.com...
