Quick Start Guide
The company names and product names appearing in this manual are
trademarks or registered trademarks of their respective holders.
For exemptions, refer to "Notes on Usage" available on the au homepage.
March 2020, 1st Edition
Sold by: KDDI CORPORATION,
OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: SHARP CORPORATION

Advertisement

Table of Contents
loading

Related Manuals for Sharp Au Speed Wi-Fi 5G X01

Summary of Contents for Sharp Au Speed Wi-Fi 5G X01

  • Page 1 Quick Start Guide The company names and product names appearing in this manual are trademarks or registered trademarks of their respective holders. For exemptions, refer to “Notes on Usage” available on the au homepage. March 2020, 1st Edition Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY Manufactured by: SHARP CORPORATION...

  • Page 2: Packaged Items

    Preface Thank you for buying the “Speed Wi-Fi 5G X01” (simply called “the product” from here on). Before using the product, read the “Quick Start Guide” (this manual), and “Notes on Usage”, carefully for proper use. Packaged Items Before using the product, make sure that you have all the following packaged items with the product.

  • Page 3: About Descriptions

    ◎ The battery is built into the product. ◎ Illustrations in this manual are shown as examples. They may differ from the actual product. About Descriptions • Symbols representing keys in this manual are as below. Power key • The following operations are abbreviated in this manual. Description Meaning Swipe left on home screen...

  • Page 4: What You Can Do With This Product

    ◎ In this manual, “au Nano IC Card 04 LE” is abbreviated to “au IC Card”. ◎ Company names and product names described in this manual are trademarks or registered trademarks of their respective companies. This manual may also omit marks such as ™ and ®. What You Can Do with This Product ®...
  • Page 5 Connecting with USB Cable (sample) You can connect this product to a PC with a USB cable (sample) for data communication. Additionally, you can also use the USB connection at the ® same time as Wi-Fi connections. Wi-Fi ® Wireless base station Wi-Fi ®...
  • Page 6 Connecting with a LAN Cable (Commercially Available) You can perform data communication by connecting the product to a PC or other device using a LAN cable (commercially available). You can also use the ® wired LAN connection at the same time as wireless LAN (Wi-Fi ) connections.
  • Page 7 ◎ The wired LAN function of the product will be stopped if the communication with connected devices using a LAN cable (commercially available) is not be performed for a set period of time. If you reconnect the product to the Internet after the wired LAN function is stopped, press f to turn the screen on.
  • Page 8 ◎ Various discount services as well as data communication charges/ discount services available within Japan cannot be used overseas. ◎ Consumption tax is not added to usage fees for international services. Setting Communication Mode/ Performance Communication Mode You can use the product to perform data communication with wireless base station via 5G, LTE or UMTS systems.
  • Page 9 Performance Setting You can make settings for the balance of the product's communication speed and the electric power consumption. Swipe left on home screen → [Settings] → [Performance Settings] Performance Set a performance to use. 4x4MIMO Setting If you set it to “ON”, the antenna setting is changed and communication speed is increased.

  • Page 10: About The Manuals

    About the Manuals ■ “Quick Start Guide” (this manual) and “Notes on Usage” The “Quick Start Guide” (this manual) and “Notes on Usage” available on the au homepage describe information and precautions required for the first time use. ttps://www.au.com/english/support/manual/) ■ “Full Instruction Manual” (Japanese) You can check “取扱説明書...

  • Page 11: Part Names And Functions

    Part Names and Functions Left side Right side Front A Heat exhaust vent B RESET button The product settings can be restored to the factory default settings by pressing this button with the SIM eject pin (sample) when the power to the product is on.
  • Page 12 F External connection jack Use when connecting with the TypeC Common AC Adapter 01/02 (sold separately), a USB cable (sample), and USB cable (commercially available) for connection with peripheral devices. G Display (Touch panel) H Charging lamp I 5G/4G antenna J 5G antenna ®...
  • Page 13 Pulling out the IMEI plate A Turn the display side down, pull out the au IC Card tray, and remove the au IC Card. (For details on pulling out the au IC Card tray, refer to the step of “Inserting the au IC Card” (zP. 15).) B Turn the display side down, hook the tab on the rear of the au IC Card tray (side without text), and pull out the IMEI plate.
  • Page 14 Main Unit Keys and Buttons Use keys and buttons on the main unit to carry out the following operations. ■ Power key Power on f (hold down for at least 2 seconds). f (hold down for at least 2 seconds) → [Power Power off Off].
  • Page 15 au IC Card (SIM Card) Your phone number etc. is recorded in the au IC Card. The product is compatible with au Nano IC Card 04 LE. au Nano IC Card 04 LE IC (metal) part Front Back ◎ Note the following points, otherwise handling the au IC Card may cause malfunction or damage.
  • Page 16 Inserting/Removing the au IC Card Before inserting/removing the au IC Card, ensure you turn off the product. Insert/remove the card with the display side of the product turned down. Inserting the au IC Card Insert the tip of the SIM eject pin (sample) into the au IC Card tray hole.
  • Page 17 Pull out the au IC Card tray. Put the au IC Card into the au IC Card tray with the IC (metal) side facing down. Check the direction of the au IC Card, and place it securely in the au IC Card tray.
  • Page 18 Insert the au IC Card tray fully into the product straight and horizontally with the display side facing down. ○ Push the areas indicated with securely and make sure there is no space between the product and the au IC Card tray. Inserting/removing the au IC Card tray ◎...
  • Page 19 Removing the au IC Card Using the SIM eject pin (sample), pull out the au IC Card tray. When pulling this out, take care that the au IC Card does not come out of the IC Card tray and get lost. Remove the au IC Card from the au IC Card tray.
  • Page 20 ◎ The product may become warm during charging, but this is not a malfunction. ◎ The interior of the product may get warm or hot depending on operation methods and the environment in which it is used. If this happens, charging may stop for safety reasons.
  • Page 21 Charging with the Specified AC Adapter This explains connecting the TypeC Common AC Adapter 02 (sold separately) and charging the product. For details on the specified AC adapter (sold separately), refer to the “取扱説明書 詳細版” (Full Instruction Manual) (Japanese). Insert the TypeC Common AC Adapter 02 (sold separately) power plug into an 100V AC outlet.
  • Page 22 When charging is completed, pull out the USB Type-C plug of the TypeC Common AC Adapter 02 (sold separately) straight from the external connection jack of the product. Remove the power plug of the TypeC Common AC Adapter 02 from the outlet. ◎...

  • Page 23: Turning The Power On/Off

    ◎ Charging over USB may take longer than when using the specified AC adapter (sold separately). ◎ If the USB cable (sample) is disconnected from the PC during data communications, data communications will be interrupted which may cause a malfunction or loss of data. Ensure care is taken. ◎...

  • Page 24: Configuring Initial Settings

    ◎ Note that settings and other content may be deleted if the power is turned off forcibly. Do not use this except when the product cannot be operated. Locking/Unlocking the Screen The product will turn off if you either press f, or do not operate the product for a set period of time.
  • Page 25 最大通信量 (Max Data Set for the data usage limit that you use this Usage) month. • Tap “TB”/“GB”/“MB” to set a unit. 自動リセット日 Set the date when data usage is reset （毎月） (Auto Reset automatically. Date) 強制通信停止を許可 Stop performing communication when you (Allow Communication set it to “ON”...

  • Page 26: Switching The Display Language To English

    スリープ設定 (Sleep Set whether to use the sleep mode. Mode) オフまでの時間 ® Set the time until the Wi-Fi function turns (Timeout) “OFF” automatically while “スリープ設定” (Sleep Mode) is set to “ON”. at the top left of the screen. [次へ] (Next) ■...

  • Page 27: Resetting To Factory Defaults

    Resetting to Factory Defaults You can restore the product to its factory default settings. ■ Resetting the Product to Factory Defaults With the product powered on, insert the tip of the SIM eject pin (sample) into the RESET button hole. Hold down the RESET button for at least 2 seconds.

  • Page 28: Using The Touch Panel

    Using the Touch Panel The product uses a touch panel, operated with your finger. • In the following cases, the touch panel may not work even if you touch it. These may also cause a malfunction. ･ Operation with a gloved finger ･...

  • Page 29: Screen Display

    Screen Display The following information is shown on the home screen. A Status icon display area B Wi-Fi Guide ® Connect devices supporting wireless LAN (Wi-Fi ) to the product by following the instructions on the screen. • For details, refer to “Connecting via Wireless LAN (Wi-Fi ®...
  • Page 30 G Settings Configure settings for each function of the product. H Power Saving Setting Configure settings for saving the power. I About Device Check information about the product. ◎ Data usage amounts are counted by the product main unit, and are to be used as a guide.
  • Page 31 Icons The status icon display area displays status icons to show product status, including signal status and remaining battery capacity. ■ Main Status Icons Icon Overview Signal strength (received signal) : Level : Searching • A small “R” is displayed at the upper left of the signal mark during international roaming.
  • Page 32 Message Display In this product, communication status and information regarding failures are notified using messages. Label Description Please insert the SIM card. Displayed when there is no au IC Card inserted. Enter PUK code. Displayed when the PIN code is locked. Reach to max PUK retry.

  • Page 33: Basic Operation

    Basic Operation ■ To Return to the Previous Screen at the top left of the screen. ■ To Return to the Home Screen at the top right of the screen.
  • Page 34 ■ To Select Items Tap the items to select. are displayed, tap to select.
  • Page 35 are displayed, tap to turn this “OFF”, and tap turn this “ON”. ■ Enter Numbers The number keyboard is displayed depending on the entry field. A Entry field Numbers can be entered B Keyboard Keyboard for entering numbers. C Delete key Delete the number.

  • Page 36: Connecting Via Wireless Lan

    ® Connecting via Wireless LAN (Wi-Fi ® Using Wireless LAN (Wi-Fi ® This product is compliant with IEEE802.11a/b/g/n/ac/ax wireless LAN (Wi-Fi ® ® and supports wireless LAN (Wi-Fi ) connection with wireless LAN (Wi-Fi devices (PCs, smartphones, tablets, etc.) for data communications. ®...
  • Page 37 Using 5 GHz This product is legally required by the Radio Law to include DFS functionality ® in order to prevent radio interference in the wireless LAN (Wi-Fi ) 5-GHz band. ® The wireless LAN (Wi-Fi ) 5-GHz frequency band used by the product is also used by weather radars and other radio equipment, therefore depending where it is used, the product may interfere with these.
  • Page 38 ■ Use on this product On the home screen → [Wi-Fi Guide] → [WPS]. [Start WPS].
  • Page 39 ■ Use on wireless devices supporting wireless LAN (Wi-Fi ® Push the WPS button. • Operating methods will differ depending on the device supporting ® wireless LAN (Wi-Fi ). For details, refer to the instruction manual for your ® device supporting wireless LAN (Wi-Fi •...
  • Page 40 [Manual Connection] . • The SSID, password, and security (encryption mode) of the product will be displayed. ■ Use on wireless devices supporting wireless LAN (Wi-Fi ® Open the connection settings screen and search for the access point. • If you turn “ON” the Wi-Fi ®...
  • Page 41 ■ 無線LAN初期設定 (Wireless LAN Initialization) sticker (Japanese) To connect the product to devices (PCs, smartphones, tablets, etc.) ® ® supporting wireless LAN (Wi-Fi ) (below: Wi-Fi devices) via wireless LAN ® (Wi-Fi ), entry of the network name (SSID) and the security key (password) is required.
  • Page 42 Connecting by Using QR Code ® You can automatically connect devices supporting wireless LAN (Wi-Fi ) to this product by reading the QR code displayed on this product with the camera on the connecting device. Supported operating systems are Android™ 10 or later, and iOS 11 or later. This example describes the procedure for Android 10.
  • Page 43 ◎ As for the model of Android 9 Pie and earlier, the QR code reader installed on your Android™ smartphone may not be able to automatically ® perform Wi-Fi settings. Install the QR code reader from the link below. ttp://k-tai.sharp.co.jp/support/a/x01/peripherals/qrapl.html) (Japanese)
  • Page 44 Communicating via a connected LAN cable (commercially available) You can use the product as a wired router (compatible with 2.5GBASE-T). You can connect it to the Internet via wired LAN connection by connecting the product and an Ethernet port installed device such as your PC with a LAN cable (commercially available).

  • Page 45: Setting Tool

    ◎ The wired LAN function of the product will be stopped if the communication with connected devices using a LAN cable (commercially available) is not be performed for a set period of time. If you reconnect the cable after the wired LAN function is stopped, press f to turn the screen on.

  • Page 46: About Device

    • When you use the last 6 digits of the IMEI information (international mobile equipment identity number) for the password, you need to change the password before logging in. Follow the instructions on the screen to change the password, and keep the password secret. 8 to 32 single-byte upper- and lower-case alphanumeric characters/symbols (except “,”...

  • Page 47: Updating Software

    Updating Software This product supports updates to its software. To start update, use one of the following methods. ■ Updating the Software Automatically The product will update its software automatically when it receives update information. Swipe left on home screen → [Settings] → [Software Update] →...
  • Page 48 • When software update is required, you will be notified of this on the au website and through other means. For details, contact an au shop or Customer Center (call toll-free 157). • You are recommended to back up your setting contents before performing an update.

  • Page 49: Troubleshooting

    Troubleshooting If this happens Check this • Is the Wi-Fi ® ® Wi-Fi doesn't connect signal strong enough? • Has Wi-Fi ® been set up? • Check the product and the wireless LAN ® (Wi-Fi )-supported device to determine that their Wi-Fi functionality have been turned “ON”.
  • Page 50 If this happens Check this • Is the power plug of the specified charger (sold Cannot charge separately) properly inserted into the outlet? • When using a USB cable (sample), is the PC powered on? • If communications or other functions are performed for a long time while charging, the product may become warm and charging may stop.

  • Page 51: After Sales Service

    After-Sales Service ■ To Request Repairs To request repairs, contact the Repair and Delivery Support Center. During the Repairs are covered in accordance with the stipulations warranty period for free repair detailed in the Warranty. Outside the If the product can be repaired, charged repairs will be warranty period carried out upon request.
  • Page 52 ■ Replacement Parts We guarantee availability of replacement parts for our Speed Wi-Fi 5G X01 main unit and its peripheral devices for a period of 4 years after the end of production. Replacement parts are those required to maintain the functionality of the product.
  • Page 53 ■ au IC Card The au IC Card is lent to you by au. In case of loss or damage, the card will be replaced at your expense. When malfunction is suspected, or in case of theft or loss, contact an au shop or Toyota store. Main specifications and peripheral devices For details of main specifications and the peripheral devices, please refer to...

  • Page 54: Regulatory Information

    Regulatory information Hereby, SHARP CORPORATION declares that the radio equipment type SHR01 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: (Japanese) ttps://jp.sharp/k-tai/) Manufacturer's Address: SHARP CORPORATION, 1 Takumi-cho, Sakai-ku, Sakai-shi, Osaka 590-8522, Japan •...
  • Page 55 • Frequency range of supported bands in EU Tx 1922.4 to 1977.6 MHz WCDMA FDD Ⅰ Rx 2112.4 to 2167.6 MHz Tx 882.4 to 912.6 MHz WCDMA FDD Ⅷ Rx 927.4 to 957.6 MHz Tx 1922.5 to 1977.5 MHz LTE Band 1 Rx 2112.5 to 2167.5 MHz Tx 1710.7 to 1784.3 MHz LTE Band 3...
  • Page 56 • Maximum transmit power WCDMA FDD Ⅰ +24 dBm (Power Class3) WCDMA FDD Ⅷ +24 dBm (Power Class3) LTE Band 1 +23 dBm (Power Class3) LTE Band 3 +23 dBm (Power Class3) LTE Band 7 +23 dBm (Power Class3) LTE Band 8 +23 dBm (Power Class3) LTE Band 20 +23 dBm (Power Class3)

  • Page 57: Fcc Notice

    The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR.The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when worn on the body is 1.90 W/kg*. For body-worn operation, this mobile device has been tested and meets the RF exposure guidelines when used with an accessory containing no metal and positioning the device a minimum of 5 mm from the body.
  • Page 58 ■ Information to User This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 59 ■ FCC RF Exposure Information Your device is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies.
  • Page 60 For inquiries, call: Customer Center For general information  (7 days a week / toll free) Business hours: 9:00 to 20:00 From au mobile phones: From non-au mobile phones / general subscriber phones: 0077-7-111  area code not required In case above numbers are not available, call toll-free: 0120‑977‑033  0120‑977‑699  (except Okinawa) (Okinawa)   In case of theft, loss, or malfunction (7 days a week / toll free) Business hours: 24 hours  From au mobile phones: From non-au mobile phones / general subscriber phones: 0077-7-113  area code not required In case above numbers are not available, call toll-free: 0120‑925‑314 Corporate Customer Center  (For corporate contractors) For general information  (toll free) Business hours: 9:00 to 19:00 (Weekday), 9:00 to 18:00 (Saturday, Sunday, Holiday)  *Except during the year change period From au mobile phones: From non-au mobile phones / general subscriber phones: 0077-7041 0120-925-041 Repair and Delivery Support Center For theft, loss, or malfunction  (toll free) Business hours: 9:00 to 20:00 (7 days a week) From au mobile phones / non-au mobile phones / general subscriber phones: 0120-925-919 Cell phone and PHS operators collect and recycle unused ...
