Asus ROG STRIX B365-F GAMING Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

ROG STRIX
B365-F
GAMING

Advertisement

Table of Contents
loading

Related Manuals for Asus ROG STRIX B365-F GAMING

Summary of Contents for Asus ROG STRIX B365-F GAMING

  • Page 1 ROG STRIX B365-F GAMING...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... vi About this guide ......................vii ROG STRIX B365-F GAMING specifications summary ........... ix Package contents ..................... xiii Installation tools and components ................. xiv Chapter 1: Product Introduction Motherboard overview ................1-1 1.1.1 Before you proceed ..............1-1 1.1.2...
  • Page 4 3.6.11 HDD/SSD SMART Information ..........3-17 Monitor menu ................... 3-18 Boot menu ....................3-18 Tool menu ....................3-20 3.9.1 ASUS EZ Flash 3 Utility ............3-20 3.9.2 Secure Erase ................3-20 3.9.3 ASUS User Profile..............3-21 3.9.4 ASUS SPD Information ............. 3-21 3.9.5...
  • Page 5 Chapter 4: RAID Support RAID configurations .................. 4-1 4.1.1 RAID definitions ................4-1 Appendix Q-Code table ......................A-1 Notices ........................A-5 ASUS contact information ..................A-9...

  • Page 6: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 7: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.
  • Page 8 Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task.

  • Page 9: Rog Strix B365-F Gaming Specifications Summary

    Memory * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). ** DDR4 2666MHz will run at max. 2666MHz on Intel 9th / 8th Gen 6-core or higher ®...
  • Page 10 ROG STRIX B365-F GAMING specifications summary Intel I219V Gigabit LAN ® Anti-surge LANGuard ROG GameFirst technology ROG SupremeFX S1220A 8-Channel High Definition Audio CODEC - Supports up to 32-Bit/192kHz playback* - Impedance sense for front and rear headphone outputs - High quality 120 dB SNR stereo playback output and 113 dB SNR stereo...
  • Page 11 GPU Boost ASUS Exclusive Features: - AI Suite 3 - ASUS EPU Special Features - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface - ARMOURY CRATE ASUS EZ DIY: - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3...
  • Page 12 ASUS Utilities Anti-virus software (OEM version) Operating Windows 10 64-bit ® system support ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm) Form factor Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications.

  • Page 13: Package Contents

    Package contents Check your motherboard package for the following items. Motherboard 1 x ROG STRIX B365-F GAMING motherboard 1 x 4-in-1 SATA 6Gb/s cable Cables 1 x Extension Cable for RGB Strips (80cm) 1 x Cable Ties set 1 x ROG Strix Series sticker...

  • Page 14: Installation Tools And Components

    Installation tools and components Intel 1151 CPU ® Intel 1151 compatible CPU Fan ® Phillips (cross) screwdriver SATA hard disk drive PC chassis 1 bag of screws DIMM Power supply unit SATA optical disc drive (optional) Graphics card The tools and components listed above are not included in the motherboard package.

  • Page 15: Chapter 1: Product Introduction

    • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component. • Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. ROG STRIX B365-F GAMING...

  • Page 16: Motherboard Layout

    1.1.2 Motherboard layout Refer to Internal connectors and Rear panel features section for more information. Chapter 1: Product Introduction...
  • Page 17 1-11 System Panel connector 1-20 Thermal sensor connector 1-18 10. Fan Extension Card connector 1-18 11. USB 2.0 connector 1-13 12. Clear RTC RAM jumper 13. TPM connector 1-12 14. AURA RGB LED connector 1-16 15. Serial port connector 1-12 16. Front Panel Audio connector 1-21 17. M.2 Wi-Fi slot 1-15 18. Rear I/O Cover LED connector 1-15 ROG STRIX B365-F GAMING...

  • Page 18: Central Processing Unit (Cpu)

    • Ensure that you install the correct CPU designed for LGA1151 socket only. DO NOT install a CPU designed for other sockets on the LGA1151 socket. • The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU. • Ensure that all power cables are unplugged before installing the CPU. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1151 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. Chapter 1: Product Introduction...

  • Page 19: System Memory

    1.1.4 System memory The motherboard comes with Dual Inline Memory Modules (DIMM) slots designed for DDR4 (Double Data Rate 4) memory modules. A DDR4 memory module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot. Recommended memory configurations ROG STRIX B365-F GAMING...
  • Page 20 Memory configurations You may install 2 GB, 4 GB, 8 GB, 16 GB unbuffered and non-ECC DDR4 DIMMs into the DIMM sockets. You may install varying memory sizes in Channel A, and Channel B. The system maps the total size of the lower-sized channel for the quad-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation. • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. • For system stability, use a more efficient memory cooling system to support a full memory load or overclocking condition. • Always install the DIMMS with the same CAS Latency. For an optimum compatibility, we recommend that you install memory modules of the same version or data code (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • Visit the ASUS website for the latest QVL. Chapter 1: Product Introduction...

  • Page 21: Expansion Slots

    1.1.5 Expansion slots Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. ROG STRIX B365-F GAMING...
  • Page 22 Recommended VGA configuration Slot Description Single VGA PCIE 3.0 x1_1 PCIE 3.0/2.0 x16_1 PCIE 3.0 x1_2 PCIE 3.0/2.0 x16_2 PCIE 3.0 x1_3 • We recommend that you provide sufficient power when running CrossFireX™ mode. • Ensure to connect the 8-pin power plug when running CrossFireX™ mode. • Connect a chassis fan to the chassis fan connectors when using multiple graphics cards for better thermal environment. Chapter 1: Product Introduction...

  • Page 23: Onboard Jumpers

    1.1.6 Onboard jumpers Clear RTC RAM jumper The Clear RTC RAM jumper allows you to clear the Real Time Clock (RTC) RAM in the CMOS, which contains the date, time, system passwords, and system setup parameters. To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Short-circuit pin 1-2 with a metal object or jumper cap for about 5-10 seconds. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data. DO NOT short-circuit the pins except when clearing the RTC RAM. Short-circuiting or placing a jumper cap will cause system boot failure! If the steps above do not help, remove the onboard button cell battery and move the jumper again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the button cell battery. ROG STRIX B365-F GAMING...

  • Page 24: Onboard Leds

    1.1.7 Onboard LEDs Q LEDs The Q LEDs check key components (CPU, DRAM, VGA, and booting devices) during the motherboard booting process. If an error is found, the critical component’s LED stays lit up until the problem is solved. The Q LEDs provide the most probable cause of an error code as a starting point for troubleshooting. The actual cause may vary from case to case. Standby Power LED The Standby Power LED lights up to indicate that the system is ON, in sleep mode, in soft-off mode, or connected to a power source. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. Chapter 1: Product Introduction 1-10...

  • Page 25: Internal Connectors

    SATA 6Gb/s connector The SATA 6Gb/s connector allows you to connect SATA devices such as optical disc drives and hard disk drives via a SATA cable. If you installed SATA storage devices, you can create a RAID 0, 1, 5, and 10 configuration with the Intel Rapid Storage Technology through the onboard Intel B365 chipset. ® ® • The connectors are set to [AHCI Mode] by default. If you intend to create a SATA RAID set using these connectors, set the SATA Mode item in the BIOS to [Intel RST Premium With Intel Optane System Acceleration(RAID)]. • The SATA6G_1 port shares bandwidth with M.2_1 slot when using M.2 SATA mode device. • Before creating a RAID set, refer to the RAID Configuration Guide. You can download the RAID Configuration Guide from the ASUS website. ROG STRIX B365-F GAMING 1-11...
  • Page 26 Serial Port connector The Serial (COM) Port connector allows you to connect a serial port module. Connect the serial port module cable to this connector, then install the module to a slot opening on the system chassis. The serial port module is purchased separately. TPM connector The TPM connector allows you to connect a Trusted Platform Module (TPM). A TPM securely stores keys, digital certificates, passwords, data, and also helps enhance network security, protect digital identities, and ensures platform integrity. The TPM is purchased separately. Chapter 1: Product Introduction 1-12...
  • Page 27 USB 3.1 Gen 1 connector The USB 3.1 Gen 1 connector allows you to connect a USB 3.1 Gen 1 module for additional USB 3.1 Gen 1 ports. The USB 3.1 Gen 1 connector provides data transfer speeds of up to 5 Gb/s. The USB 3.1 Gen 1 module is purchased separately. USB 2.0 connector The USB 2.0 connector allows you to connect a USB module for additional USB 2.0 ports. The USB 2.0 connector provides data transfer speeds of up to 480 MB/s connection speed. DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. ROG STRIX B365-F GAMING 1-13...
  • Page 28 M.2 slot The M.2 slot allows you to install M.2 devices such as M.2 SSD modules. • M.2_1 socket supports PCIe 3.0 x4 and SATA mode M Key design and type 2242 / 2260 / 2280 PCIe and SATA storage devices. • M.2_2 socket supports PCIe 3.0 x4 M Key design and type 2242 / 2260 / 2280 PCIe storage devices. • The M.2_1 socket shares bandwidth with SATA6G_1 port when using M.2 SATA mode device. The M.2 SSD module is purchased separately. Chapter 1: Product Introduction 1-14...
  • Page 29 M.2 Wi-Fi slot The M.2 Wi-Fi slot allows you to install an M.2 Wi-Fi module (E-key, type 2230). The M.2 Wi-Fi module is purchased separately. Rear I/O Cover LED connector The Rear I/O Cover LED connector is for connecting the LED strips on your rear I/O cover. ROG STRIX B365-F GAMING 1-15...
  • Page 30 AURA RGB LED connector The AURA RGB LED connector allows you to connect RGB LED strips. The AURA RGB LED connector supports 5050 RGB multi-color LED strips (12V/G/R/B), with a maximum power rating of 3A (12V), and no longer than 3m. Before you install or remove any component, ensure that the power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. • Actual lighting and color will vary with LED strip. • If your LED strip does not light up, check if the RGB LED extension cable and the RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up when the system is powered on. • The LED strip is purchased separately. Chapter 1: Product Introduction 1-16...
  • Page 31 Do not place jumper caps on the fan connectors! • Ensure the cable is fully inserted into the connector. Connect the fan of your water cooling kit to the AIO_PUMP connector. Header Max. Current Max. Power Default Speed Shared Control CPU_FAN Q-Fan Controlled CPU_OPT Q-Fan Controlled CHA_FAN1 Q-Fan Controlled CHA_FAN2 Q-Fan Controlled AIO_PUMP Full-Speed M.2_FAN Q-Fan Controlled ROG STRIX B365-F GAMING 1-17...
  • Page 32 Fan Extension Card connector The Fan Extension Card connector allows you to install an fan extension card. For more details on the fan extension card, please refer to the To install Fan Extension Card section in this guide. The fan extension card is purchased separately. Thermal Sensor connector The Thermal Sensor connector allows you to connect a sensor to monitor the temperature of the devices and the critical components inside the motherboard. Connect the thermal sensor and place it on the device or the motherboard’s component to detect its temperature.
  • Page 33 These Power connectors allow you to connect your motherboard to a power supply. The power supply plugs are designed to fit in only one orientation, find the proper orientation and push down firmly until the power supply plugs are fully inserted. Ensure to connect the 8-pin power plug. • For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12V Specification 2.0 (or later version) and provides a minimum power of 350 W. • We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. • If you want to use two or more high-end PCI Express x16 cards, use a PSU with 1000W power or above to ensure the system stability. ROG STRIX B365-F GAMING 1-19...
  • Page 34 System Panel connector The System Panel connector supports several chassis-mounted functions. • System Power LED connector (PLED) The 2-pin and/or 3-1 pin connectors allow you to connect the System Power LED. The System Power LED lights up when the system is connected to a power source, or when you turn on the system power, and blinks when the system is in sleep mode. • Storage Device Activity LED connector (HDD_LED) The 2-pin connector allows you to connect the Storage Device Activity LED. The Storage Device Activity LED lights up or blinks when data is read from or written to the storage device or storage device add-on card. • System Warning Speaker connector (SPEAKER) The 4-pin connector allows you to connect the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings. • Power Button/Soft-off Button connector (PWRSW) The 3-1 pin connector allows you to connect the system power button.
  • Page 35 Front Panel Audio connector The front panel audio connector is for a chassis-mounted front panel audio I/O module that supports HD Audio. Connect one end of the front panel audio I/O module cable to this connector. We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. ROG STRIX B365-F GAMING 1-21...
  • Page 36 Chapter 1: Product Introduction 1-22...

  • Page 37: Building Your Pc System

    2.1.1 CPU installation Ensure that you install the correct CPU designed for LGA1151 socket only. DO NOT install a CPU designed for LGA1155 and LGA1156 sockets on the LGA1151 socket. ROG STRIX B365-F GAMING...
  • Page 38 Chapter 2: Basic Installation...

  • Page 39: Cooling System Installation

    2.1.2 Cooling system installation Apply the Thermal Interface Material to the CPU cooling system and CPU before you install the cooling system, if necessary. To install a CPU heatsink and fan assembly ROG STRIX B365-F GAMING...
  • Page 40 To install an AIO cooler AIO_PUMP CPU_FAN CPU_OPT Chapter 2: Basic Installation...

  • Page 41: Motherboard Installation

    Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to the chassis’ rear I/O panel. Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT overtighten the screws! Doing so can damage the motherboard. ROG STRIX B365-F GAMING...

  • Page 42: Dimm Installation

    2.1.4 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 43: Atx Power Connection

    2.1.5 ATX power connection Ensure to connect the 8-pin power plug. 2.1.6 SATA device connection ROG STRIX B365-F GAMING...

  • Page 44: Front I/O Connector

    2.1.7 Front I/O connector To install front panel connector To install front panel audio connector AAFP To install USB 3.1 Gen 1 connector To install USB 2.0 connector USB 3.1 Gen 1 USB 2.0 Chapter 2: Basic Installation...

  • Page 45: Expansion Card Installation

    2.1.8 Expansion card installation To install PCIe x16 cards To install PCIe x1 cards ROG STRIX B365-F GAMING...
  • Page 46 To install FAN EXTENSION CARD • The illustrations in this section are for reference only. The motherboard layout may vary with models, but the installation steps are the same for all models. • The FAN Extension card is purchased separately. Chapter 2: Basic Installation 2-10...
  • Page 47 To install Hyper M.2 x4 card The SSD card is purchased separately. ROG STRIX B365-F GAMING 2-11...

  • Page 48: M.2 Installation

    2.1.9 M.2 installation For type 2280 M.2 For type 2260 / 2242 M.2 The M.2 is purchased separately. Chapter 2: Basic Installation 2-12...

  • Page 49: Motherboard Rear And Audio Connections

    * and ** : Refer to the tables on the next page for LAN port LEDs and audio port definitions. • USB 3.1 Gen 1/Gen 2 devices can only be used as data storage only. • We strongly recommend that you connect your devices to ports with matching data transfer rate. Please connect your USB 3.1 Gen 2 devices to USB 3.1 Gen 2 ports for faster and better performance for your devices. ROG STRIX B365-F GAMING 2-13...
  • Page 50 * LAN ports LED indications Activity Link LED Speed LED Status Description Status Description ACT/LINK SPEED No link 10 Mbps connection Orange Linked Orange 100 Mbps connection Orange (Blinking) Data activity Green 1 Gbps connection Orange (Blinking Ready to wake up LAN port then steady) from S5 mode...

  • Page 51: Audio I/O Connections

    2.2.2 Audio I/O connections Audio I/O ports Connect to Headphone and Mic Connect to Stereo Speakers Connect to 2-channel Speakers ROG STRIX B365-F GAMING 2-15...
  • Page 52 Connect to 4-channel Speakers Connect to 5.1-channel Speakers Connect to 7.1-channel Speakers Chapter 2: Basic Installation 2-16...

  • Page 53: Starting Up For The First Time

    Turning off the computer While the system is ON, press the power button for less than four seconds to put the system on sleep mode or soft-off mode, depending on the BIOS setting. Press the power switch for more than four seconds to let the system enter the soft-off mode regardless of the BIOS setting. ROG STRIX B365-F GAMING 2-17...
  • Page 54 Chapter 2: Basic Installation 2-18...

  • Page 55: Chapter 3: Bios Setup

    BIOS Setup Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 56: Bios Setup Program

    RTC RAM via the Clear CMOS jumper. • The BIOS setup program does not support the Bluetooth devices. Please visit ASUS website for the detailed BIOS content manual. BIOS menu screen The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode.

  • Page 57: Advanced Mode

    Pop-up Menu Scroll bar Menu bar Language MyFavorite(F3) Qfan Control(F6) Hot Keys Menu items General help Go back to EZ Mode Last modified settings Search on the FAQ Displays a quick overview of the system status ROG STRIX B365-F GAMING...
  • Page 58 Menu bar The menu bar on top of the screen has the following main items: For saving the frequently-used system settings and configuration. My Favorites For changing the basic system configuration Main For changing the overclocking settings Ai Tweaker For changing the advanced system settings Advanced For displaying the system temperature, power status, and changing Monitor...
  • Page 59 Move your mouse over this button to show a QR code, scan this QR code on your mobile device to connect to the BIOS FAQ web page of the ASUS support website. You can also scan the following QR code:...

  • Page 60: Ez Mode

    3.2.2 EZ Mode The EZ Mode provides you an overview of the basic system information, and allows you to select the display language, system performance, mode and boot device priority. To access the Advanced Mode, select Advanced Mode or press the <F7> hotkey for the advanced BIOS settings.

  • Page 61: Qfan Control

    PWM Mode DC Mode Select a profile to Click to apply the fan setting apply to your fans Click to undo the Click to go back to main menu changes Select to manually configure your fans ROG STRIX B365-F GAMING...
  • Page 62 Configuring fans manually Select Manual from the list of profiles to manually configure your fans’ operating speed. Speed points Select to manually configure your fans To configure your fans: Select the fan that you want to configure and to view its current status. Click and drag the speed points to adjust the fans’...

  • Page 63: Ez Tuning Wizard

    Ensure that your HDDs have no existing RAID volumes. • Ensure to connect your HDDs to Intel SATA connectors. ® Select the port that you want to set to [RAID] mode, PCIE or SATA, then click Next. ROG STRIX B365-F GAMING...
  • Page 64 Select the type of storage for your RAID, Easy Backup or Super Speed, then click Next. For Easy Backup, click Next then select from Easy Backup (RAID 1) or Easy Backup (RAID 10). You can only select Easy Backup (RAID 10) if you connect four (4) HDDs. For Super Speed, click Next then select from Super Speed (RAID 0) or Super Speed (RAID 5).

  • Page 65: My Favorites

    My Favorites is your personal space where you can easily save and access your favorite BIOS items. My Favorites comes with several performance, power saving, and fast boot related items by default. You can personalize this screen by adding or removing items. ROG STRIX B365-F GAMING 3-11...
  • Page 66 Adding items to My Favorites To add BIOS items: Press <F3> on your keyboard or click MyFavorite(F3) from the BIOS screen to open Setup Tree Map screen. On the Setup Tree Map screen, select the BIOS items that you want to save in My Favorites screen.

  • Page 67: Main Menu

    This item allows you to set the memory operating frequency. The configurable options vary with the BCLK (base clock) frequency setting. Select the auto mode to apply the optimized setting. Configuration options: [Auto] [DDR4-800MHz] - [DDR4-4266MHz] ROG STRIX B365-F GAMING 3-13...

  • Page 68: Advanced Menu

    Internal CPU Power Management The subitems in this menu allow you to set the CPU ratio and features. Intel(R) SpeedStep(tm) Allows the operating system to dynamically adjust the processor voltage and cores frequency to decrease the average power consumption and decrease average heat production.

  • Page 69: Pch Configuration

    POST (Power-on Self Test) when an error occurs in the hard disks. Configuration options: [On] [Off] SATA6G_1(Black) - SATA6G_6(Black) SATA6G_1(Black) - SATA6G_6(Black) This item allows you to enable or disable the selected SATA port. Configuration options: [Disabled] [Enabled] ROG STRIX B365-F GAMING 3-15...

  • Page 70: Pch-Fw Configuration

    Hot Plug These items appears only when the SATA Mode Selection is set to [AHCI] and allows you to enable or disable SATA Hot Plug Support. Configuration options: [Disabled] [Enabled] 3.6.6 PCH-FW Configuration This item allows you to configure the firmware TPM. 3.6.7 Onboard Devices Configuration The items in this menu allow you to switch between PCIe Lanes and configure onboard...

  • Page 71: Apm Configuration

    The items in this menu allow you to configure Ipv4 / Ipv6 PXE support. 3.6.11 HDD/SSD SMART Information The items in this menu display the SMART information of the connected devices. NVM Express devices do not support SMART information. ROG STRIX B365-F GAMING 3-17...

  • Page 72: Monitor Menu

    Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. Qfan Configuration Qfan Tuning Click this item to automatically detect the lowest speed and configure the minimum duty cycle for each fan. AIO PUMP Control [Disabled] Disable the Water Pump control feature.
  • Page 73 OS in Safe Mode, press <F8> after POST (Windows 8 not supported). • To select the boot device during system startup, press <F8> when the ASUS Logo appears. Boot Override These items displays the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system.

  • Page 74: Tool Menu

    To launch Secure Erase, click Tool > Secure Erase on the Advanced mode menu. Check the ASUS support site for a full list of SSDs tested with Secure Erase. The drive may become unstable if you run Secure Erase on an incompatible SSD.

  • Page 75: Asus User Profile

    Locked. SSDs might be locked if the Secure Erase process is either incomplete • or was stopped. This may be due to a third party software that uses a different password defined by ASUS. You have to unlock the SSD in the software before proceeding with Secure Erase. 3.9.3 ASUS User Profile This item allows you to store or load multiple BIOS settings.

  • Page 76: Graphics Card Information

    3.9.6 Download & Install ARMOURY CRATE app This item allows you to enable or disable the ASUS Armoury Crate. The ASUS Armoury Crate is a fixed Advanced Configuration and Power Interface (ACPI) table that provides Windows with a platform binary that the operating system can execute.

  • Page 77: Updating Bios

    3.11 Updating BIOS The ASUS website publishes the latest BIOS versions to provide enhancements on system stability, compatibility,and performance. However, BIOS updating is potentially risky. If there is no problem using the current version of BIOS, DO NOT manually update the BIOS.

  • Page 78: Asus Ez Flash 3

    3.11.2 ASUS EZ Flash 3 ASUS EZ Flash 3 allows you to download and update to the latest BIOS through the Internet without having to use a bootable floppy disk or an OS-based utility. Updating through the Internet varies per region and Internet conditions. Check your local Internet connection before updating through the Internet.
  • Page 79 To update the BIOS by Internet: Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select ASUS EZ Flash Utility and press <Enter>. Select via Internet. Press the Left/Right arrow keys to select an Internet connection method, and then press <Enter>.

  • Page 80: Asus Crashfree Bios 3

    The BIOS file in the motherboard support DVD may be older than the BIOS file published on the ASUS official website. If you want to use the newer BIOS file, download the file at https://www.asus.com/support/ and save it to a USB flash drive.

  • Page 81: Chapter 4: Raid Support

    ® RAID 1, RAID 5 and RAID 10 configuration. For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support. 4.1.1 RAID definitions RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks.
  • Page 82 Chapter 4: RAID Support...

  • Page 83: Appendix

    CPU self test failed or possible CPU cache error CPU micro-code is not found or micro-code update is failed Internal CPU error Reset PPI is not available Reserved for future AMI error codes 5C – 5F ROG STRIX B365-F GAMING...

  • Page 84: Q-Code Table

    Q-Code table Code Description S3 Resume is stared (S3 Resume PPI is called by the DXE IPL) S3 Boot Script execution Video repost OS S3 wake vector call Reserved for future AMI progress codes E4 – E7 S3 Resume Failed S3 Resume PPI not Found S3 Resume Boot Script Error S3 OS Wake Error...
  • Page 85 Reserved for ASL (see ASL Status Codes section below) Ready To Boot event Legacy Boot event Exit Boot Services event Runtime Set Virtual Address MAP Begin Runtime Set Virtual Address MAP End Legacy Option ROM Initialization System Reset (continued on the next page) ROG STRIX B365-F GAMING...
  • Page 86 Q-Code table Code Description USB hot plug PCI bus hot plug Clean-up of NVRAM Configuration Reset (reset of NVRAM settings) Reserved for future AMI codes B8– BF CPU initialization error System Agent initialization error PCH initialization error Some of the Architectural Protocols are not available PCI resource allocation error.
