D-Link DCS-2000 Quick Installation Manual

D-Link DCS-2000 Quick Installation Manual

Home security internet camera
Hide thumbs Also See for DCS-2000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
This product can be set up
using Internet Explorer 5.x
or above

Before You Begin

You must have at least the following:
Windows XP/2000/Me/98SE
•
Ethernet Adapter
•
CD-ROM Drive
•
Check Your Package Contents
These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their
respective holders. Software and specifications subject to change without notice. DCS-2000.04262004
DCS-2000 Internet Camera
Installation CD (containing Drivers,
Software, Quick Installation Guide
and Manual)
Camera Stand and Bracket
Category 5 Ethernet Cable
AC Power Adapter
DCS-2000
Internet Camera
Using a power supply
with a different voltage
rating will damage this
product and void the warranty.
Home Security

Advertisement

Table of Contents
loading

Related Manuals for D-Link DCS-2000

Summary of Contents for D-Link DCS-2000

  • Page 1: Before You Begin

    These are the items included with your purchase: If any of the below items are missing, please contact your reseller. ©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DCS-2000.04262004...

  • Page 2: System Requirements

    System Requirements • Internet Explorer 5.x or above • CPU: Pentium III, 800MHz or above (Required for use with IP Surveillance software) • Memory Size: 128MB (256MB recommended) • VGA card resolution: 800x600 or above Hardware Installation Connect the Ethernet Cable Connect an Ethernet cable to the Ethernet connector located on the Internet Camera’s back panel and attach it to the network.
  • Page 3 Configuring your camera with IP Installer Insert the DCS-2000 CD into the CD-ROM drive. Click on Install Software Click on IP Installer This is the first screen that will appear. If the IP installer does not display any devices, lightly insert a paper clip into the reset opening on the unit’s rear panel until...
  • Page 4 Configuring your camera with IP Installer (continued) The IP Installer will now show a MAC address of the DCS-2000 and an IP Address (which may or may not be correct depending on what you have your DCS-2000 connected to.) If you have a DHCP* server on your network, a valid IP Address will be displayed here.
  • Page 5 After you click on the Link but- ton, IP Installer will automati- cally open your Internet browser to the IP Address of the DCS- 2000, in this example it is: http:/ /192.168.0.100. Your DCS-2000 may have a different IP Address.

  • Page 6: Enabling Upnp For Windows Xp/Me

    Enabling UPnP for Windows XP/Me UPnP is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals. The DCS-2000 is a UPnP enabled internet camera. If your operating system is UPnP enabled, the device will be easier to configure.
  • Page 7 Enabling UPnP for Windows XP/Me (continued) Click Add/Remove Windows Components The following screen will appear: Select Networking Services (Communications in Windows Me) Click Details Select Universal Plug and Play Click...
  • Page 8 Enabling UPnP for Windows XP/Me (continued) Click Next Please wait while Setup configures the components. Click Finish...
  • Page 9 The last three digits (100), represent the fourth octet of your Internet Camera’s IP address (in this example, 198.168.0.100). After you click on the DCS-2000- 100 icon, your Internet browser will automatically be opened to the IP Address of the DCS-2000, in this example it is: http:// 192.168.0.100.

  • Page 10: Setting A Password

    Click Configuration There are five tabs across the top of the Configuration screen. Each tab displays different configuration elements of the DCS-2000. The Advanced tab is the default screen in Configuration and Network is the default selection under Advanced. Uncheck...
  • Page 11 Go to the Tools tab and put in a password for security purposes. Select Tools Enter the adminstrative password and confirm it. Click Save then “X” at top right-hand corner of your browser to close the page. The installation and configuration of the DCS-2000 Internet Camera is now complete.
  • Page 12 You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link Technical Support through our website, or by phone.
