Départ. Technical support- CM640
PHILIPS Consumer
Communications
Centre du Mans
© PHILIPS ELECTRONICS N.V. 1999
All rights reserved. Reproduction in whole
or in part is prohibited without the written
consent of the copyright owner.
PROCEDURE
Service Repair Support
SERVICE MANUAL
Repair for Cellular Telephone
Fisio 311
LEVEL 1 / LEVEL 2
COMPANY RESTRICTED
VY-V-640-204
Page : 1 of 42
Langue : EN
Date : 09/21/01
by Toko (toko@gsm-free.org)

Advertisement

Table of Contents
loading

Related Manuals for Philips Fisio 311

Summary of Contents for Philips Fisio 311

  • Page 1 SERVICE MANUAL Repair for Cellular Telephone Fisio 311 LEVEL 1 / LEVEL 2 © PHILIPS ELECTRONICS N.V. 1999 by Toko (toko@gsm-free.org) All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 2 Code Nomenclature suppressed REVISION 2 : 21/09/01 Page : 39 N° 4311 256 03841 : Sticker Process © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 3: Table Of Contents

    Removing The Battery ................................... 10 Charging The Battery ..................................10 W@P Introduction..................................11 TEST PROCEDURES ..................................13 Initial Functional Check for Fisio 311............................13 RF Test......................................16 Battery Charging (IGN : Ignition) / Current Consumption...................... 20 W@P Test Procedure ..................................22 ASSEMBLY / DISMANTLEMENT PROCEDURES......................28...

  • Page 4: Purpose

    This document establishes the functional test and inspection procedures for the first level service repair of the FISIO 311 transceiver. SCOPE The test plan is applicable to all levels of service repair of the FISIO 311 transceiver. REFERENCE None. GLOSSARY/ACRONYM LIST...

  • Page 5: Test And Inpection Plan

    Centre du Mans Date : 09/21/01 TEST AND INPECTION PLAN The test plan is derived from the Product Test Reference of FISIO 311. User Interface Test Use the Test SIM Card « SP »/ Production to test the transceivers as follows : •...

  • Page 6: Before Starting

    Langue : EN Centre du Mans Date : 09/21/01 BEFORE STARTING Description Of The Transceiver © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 7: Description Of The Display

    Page : 7 of 42 Langue : EN Centre du Mans Date : 09/21/01 Description Of The Display © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 8: Using The Carousel

    The carousel is a circular loop of icons displayed on the screen. These icons provide access to the different menus and sub menus used to operate your phone. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 9: Inserting The Micro-Card

    Centre du Mans Date : 09/21/01 Inserting The MICRO-Card Inserting The Battery Attach The Battery Cover © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 10: Removing The Battery

    Langue : EN Centre du Mans Date : 09/21/01 Removing The Battery Charging The Battery © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 11: W@P Introduction

    The customer has to contact his Network Operator to inquire about his subscription and the options he can subscribe to. Generally the customer just have to request his W@P access to his provider and he will not be charged for that. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 12 Please note that it is important to respect small and capital letters according to your operator instructions. It is also possible that your provider does not require the Login and/or Password. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 13: Test Procedures

    Langue : EN Centre du Mans Date : 09/21/01 TEST PROCEDURES Initial Functional Check for Fisio 311 8.1.1 Insert the Test Production Card into the SIM Reader at the back of the cellular phone and clip a charged battery on the phone.
  • Page 14 FA GOOD (Must be good) X XXXXXXXXXXX (12NC) Press # again Left corner displays # © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 15 8.1.1 If the product is good, it is considered as a NFF (No Fault Found) product. All the NFF products must be directly returned to the customer. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...

  • Page 16: Rf Test

    Generally the test sequences built inside the testers will be used to check the mobile. You must assess that the test sequences limits comply with the standard specifications and defined test plan. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 17 (powermeter recommended). It is the only way to ensure good contact between antenna and main board. This warning doesn't apply when using an antenna coupler. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 18 1, 62, 124 -102 dBm If a phone is out of the specifications, it must be sent to the Repair Center. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...
  • Page 19 512, 700, 885 -102dbm If a phone is out of the specifications, it must be sent to the Repair Center. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...

  • Page 20: Battery Charging (Ign : Ignition) / Current Consumption

    Current consumption a) Check current_OFF : When the mobile is OFF the current measured must be : 0.05 < I (mA) < 0.23 © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...
  • Page 21 270 < I (mA) < 370 - Remove the battery. - Gently slide the card out away from the Product © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...

  • Page 22: W@P Test Procedure

    Change menu settings and press OK stored. Select one and press OK © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 23 This parameter is provided by the operator and is set as follows: Press OK to Enter the login and set the login press OK © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 24 Press the OK to set the and press OK And press OK gateway (IP parameter) © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 25 Clip the battery again Ø Turn on the mobile Ø Check that the parameters still present. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 26 Note: The phone can not be switched off with ON/OFF key when W@P application is used. It has not to be considered as a bug. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...
  • Page 27 * Impossible to display W@P pages èA W@P page may be displayed on the mobile phone screen of a competitor and not by the Philips transceiver. The help desk /ASC/NSC operator will have to explain that the W@P navigators are different. Sometimes, contents of particular pages can be decoded by a navigator and not by another (idem for Netscape and Internet Explorer).

  • Page 28: Assembly / Dismantlement Procedures

    Open the Front Cabinet Insert a plectrum. Make it slide so as to Separate the cabinets release the clips © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 29 Use the plectrum to separate Take the subset away the subset and the Rear Cabinet © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 30 Remove the antenna Press with a screwdriver to Pull out the antenna release the antenna © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 31 9.1.9 Remove the Keypad Detach the Keypad from the Main Board Remove the keypad with the mylar © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 32: Assembly

    Set the microphone Set the keypad 9.2.2 Set the LCD Module Ensure that both clips are fastened © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 33 On both sides to ensure that the clips are will fastened 9.2.6 Set the LCD Gasket Place the LCD Gasket © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 34 Use the ionizing gun to remove any dust form PCB. If needed, use isopropylic Alcohol to clean copper areas. Set down the subset in the Front Cabinet. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...
  • Page 35 When using an electrical screwdriver respect the Torque strength (0,2N/m +/- 0.02). Stick the Label © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 36: Exploded View Of The Transceiver

    Page : 36 of 42 Langue : EN Centre du Mans Date : 09/21/01 Exploded view of the transceiver © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 37: Solutions In Case Of Problems During The Tests

    If everything works in test configuration that means that a phone setting is disabled or does not suit well. It can be solved in the phone menu. Otherwise send the mobile for repair © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
  • Page 38 10.10 Problems to send SMS messages Check the Center number. It may be empty or wrong. © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written...

  • Page 39: Recomended Part List Ct2888 Fisio311

    9240 4311 258 74376 STD Charger EUROPE Friwo 9265 4311 254 38032 Cover Battery Spoon 0105 4311 255 50591 Label FISIO 311 SILVER 0235 4311 255 50602 Label Fisio 311 GOLD 0235 4311 256 07001 User Manual UK Z10-WAP 0260...

  • Page 40: Specific Parts - Out Of Warranty

    SPAIN REFERENCE DESIGNATION POSITION REPAIR LEVEL 4311 256 07081 User Manual SP Z10 WAP 0260 © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 41: Common Parts - In Warranty

    2403 995 20349 Earpiece 13MM + Gasket 1730 2422 549 44727 Microphone C KUF4323-01 1740 © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.

  • Page 42: Annex 1

    Page : 42 of 42 Langue : EN Centre du Mans Date : 09/21/01 ANNEX 1 © PHILIPS ELECTRONICS N.V. 1999 VY-V-640-204 All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
