Owner's Manual
Thunderbolt 3 Dual-Monitor Docking
Station with 8K DisplayPort, 4K HDMI,
USB-A Hub Ports, 3.5 mm Audio, Gigabit
Ethernet and 60W PD 3.0 Charging
Este manual esta disponible en español en la página de Tripp Lite: tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar:
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Model: MTB3-DOCK-04
tripplite.com
surge protector in our monthly drawing!
®
tripplite.com/warranty
1
Advertisement
Table of Contents
Related Manuals for Tripp Lite MTB3-DOCK-04
Summary of Contents for Tripp Lite MTB3-DOCK-04
- Page 1 Model: MTB3-DOCK-04 Este manual esta disponible en español en la página de Tripp Lite: tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: tripplite.com Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar:...
-
Page 2: Package Contents
Package Contents • MTB3-DOCK-04 • Owner’s Manual Optional Accessories • P568-Series High-Speed HDMI Cables • U428-Series USB 3.1 A/C Cables • N201-Series High-Speed Cat6 Gigabit Ethernet Cables • P580-Series DisplayPort Cables Product Features • Thunderbolt 3 input supports data transfer rates up to 40 Gbps... -
Page 3: System Requirements
Product Features • Transmits video from both ports simultaneously to two displays Note: See Multi-Monitor Requirements for exact product features • RJ45 port supports 10/100/1000 Mbps Gigabit Ethernet speeds to connect to a wired network • Dual USB 3.2 Gen 2 ports individually support 10 Gbps data transfer speeds for connecting USB-A peripherals •... -
Page 4: Product Overview
Product Overview Front DisplayPort output USB 3.2 USB 3.2 HDMI output RJ45 Gigabit Ethernet jack Rear USB 3.2 USB 3.2 PD CHARGE 3.5 mm audio jack USB 3.2 Gen 2 Type-A ports PD CHARGE... - Page 5 USB 3.2 USB 3.2 Product Overview Side PD CHARGE 60W (20V 3A) PD 3.0 Charging port...
-
Page 6: Installation
Installation Notes: • Docking station must be connected to a dedicated Thunderbolt 3 port to function. It will not function with a standard USB-C port. • Supports the connection of two monitors at the same time: one via DisplayPort and a second via HDMI. See Multi-Monitor Requirements section for details. - Page 7 Installation 4. Connect an external speaker, microphone, headset or other audio device to the 3.5 mm audio jack. 5. Connect up to two USB peripherals to the USB-A ports. 6. Connect the RJ45 jack to a wired Gigabit Ethernet network with a user-supplied UTP patch cable.
- Page 8 Does the Source Computer Support a Thunderbolt 3 Connection? The MTB3-DOCK-04 can be used to transmit video from source computers that have a Thunderbolt 3 port. The docking station will not work with a standard USB-C port. Be sure your computer...
-
Page 9: Specifications
Specifications Input Connector Thunderbolt Thunderbolt 3 Type-C (Male) Output Connectors DisplayPort DisplayPort (Female) HDMI HDMI (Female) (x2) USB 3.2 Gen 2 Type-A (Female) PD Charging USB-C PD 3.0 Charging (Female) Audio 3.5 mm (Female) Display Specifications DisplayPort 8K (7680 x 4320) @ 30 Hz HDMI 4K (3840 x 2160) @ 60 Hz Network Specifications... - Page 10 Specifications Electrical Specifications PD Charging PD 3.0 Charging up to 60W (20V 3A) Environmental Specifications Operating Temperature 32° to 95°F / 0° to 35°C Range Storage Temperature -4° to 158°F / -20° to 70°C Range Relative Humidity 0 to 90% Range...
-
Page 11: Warranty And Product Registration
Warranty and Product Registration 3-Year Limited Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 3 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, at its sole discretion. - Page 12 Warranty and Product Registration Product Registration Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply.
