- Page 1 U-BRACKET UB-DXRDHR10 Owner’s Manual Benutzerhandbuch Mode d’emploi Manual de instrucciones Manual do Proprietário Manuale di istruzioni Руководство пользователя SPEAKER BRACKET...
-
Page 2: Table Of Contents
Thank you for purchasing the Yamaha UB-DXRDHR10 U-BRACKET. This product is a bracket designed for use in installation of the Yamaha DXR10, DHR10 and CHR10 speakers. This manual explains how to attach the bracket to a speaker when installation personnel use this bracket to install the speaker to a wall or ceiling. -
Page 3: Package Contents
If the wire is too long, and the speaker happens to fall, the wire may snap as a result of too much strain. Yamaha cannot be held responsible for damage or injury caused by insufficient strength of the support structure or improper installation. -
Page 4: Installation Instructions
Installation Instructions CAUTION Use the included hexagon bolts (M8×25 for DXR10, Make sure that you do not pinch your fingers M8×55 for DHR10 and CHR10), M8 spring washers, and between the U-bracket and speaker. M8 flat washers to attach the speaker to the U-bracket. The mounting position of the speaker is sealed before shipment, so remove the seal for DXR10, and remove the NOTE... - Page 5 Installation Instructions Horizontal Installation Make sure that the width of the U-bracket matches the speaker width. Attach the bottom plate to the bottom of the speaker using the included M5 × 16 screws for the DXR10, and Affix the U-bracket on the wall or ceiling using appropri- use the M8 ×...
-
Page 6: Specifications
Net Weight 4.2 kg * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. * Der Inhalt dieser Bedienungsanleitung gilt für die neuesten technischen Daten zum Zeitpunkt der Veröffentlichung. Um die neueste Version der Anleitung zu erhalten, rufen Sie die Website von Yamaha auf und laden Sie dann die Datei mit der Bedie-nungsanleitung herunter. -
Page 7: Optional Brackets (Sold Separately)
Optional Brackets (sold separately) 可选支架（另售） Wall Bracket Baton Bracket Ceiling Bracket BWS251-400 BBS251 BCS251 BWS251-300 Examples * These illustrations are of the DHR10. * 这些插图来自DHR10。... -
Page 8: Dimensions
Dimensions 外形尺寸 222.5 327.5 50.8 213.8 213.8 Unit: mm 213.8 単位：mm... - Page 9 Dimensions DXR10 B S251-400 B S251-300 BBS251 BCS251 ±1 0° ±1 0° ±1 0° ±90° ±90° ±90° B S251-400 B S251-300 BBS251 BCS251 ±1 0° ±1 0° ±1 0° ±90° ±90° ±90°...
- Page 10 DHR10, CHR10 B S251-400 B S251-300 BBS251 BCS251 ±1 0° ±1 0° ±1 0° ±90° ±90° ±90° B S251-400 B S251-300 BBS251 BCS251 ±1 0° ±1 0° ±1 0° ±90° ±90° ±90°...
