Dear RX-Z11/DSP-Z11 owner,
Follow the procedures below to properly update your Z11's firmware. After the update, you will be
able to confirm that the update was done successfully.
Requirements:
1) USB flash drive (empty), with enough free space to hold 8.4 MB.
2) New firmware file provided by YAMAHA,
Procedure:
1. Copy or Drag & Drop the firmware file "
drive on PC.
(Note: We recommend that you DO NOT store any other files or documents on your thumb drive
during this firmware update)
This is an example after copy or Drag & Drop onto USB
drive.
.
RXZ11-0142.bin
RXZ11-0142.bin
" onto the root folder of your USB flash
Drag & Drop the file onto USB drive.
RXZ11-0142.bin
BIN File
8,382KB
RXZ11-0142.bin
BIN File
8,382KB
Advertisement
Related Manuals for Yamaha RX-Z11
Summary of Contents for Yamaha RX-Z11
- Page 1 Requirements: 1) USB flash drive (empty), with enough free space to hold 8.4 MB. 2) New firmware file provided by YAMAHA, RXZ11-0142.bin Procedure: 1. Copy or Drag & Drop the firmware file “...
- Page 2 2. Set the ON/OFF button on the front panel to OFF, MASTER and confirm that the AC plug is properly connected to an outlet. 3. While pressing the PROGRAM knob, press (and release) the MASTER ON/OFF button and then keep depressing the PROGRAM knob until “ADVANCED SETUP” appears on the front panel display.
- Page 3 7. When “UPDATE OK” appears on the display, firmware update is completed. 8. Power OFF the unit by pressing MASTER ON/OFF button on the front panel. 9. Unplug the USB thumb drive. Confirmation of Firmware Update 10. While pressing the PROGRAM knob, press (and release) the MASTER ON/OFF button and then keep depressing the PROGRAM knob until “ADVANCED SETUP”...
- Page 4 Recovery TIPS in case your update has not been successful: Case#1 Instead of “UPDATE OK”, “FirmUpdate, push MENU key” appeared on the display. This occurs when the program area of the update data inside the USB thumb drive is partially corrupted. To recover, 1.
