- Page 1 PVWIN-T30 / PV-T30 instructions manual < Support documentation> Nov. 24, 2015...
-
Page 2: Timing Chart
1.1 Timing Chart Typical Operations in Inspections Common Trigger In serial processing mode Tf: 400µs (fixed), Tp (1-1000ms): Data output guarantee time (default: 10 ms) * Out signal turns off this timing when setting "Parallel I/O Output Reset Condition" to “Reset”. Make sure that REDY signal is ON and then turn on STRT signal for more than 1 ms. - Page 3 Capture Delay PV-T30 : “main menu” from the select menu > [Camera] > [Capture Delay] [Camera] from the Navigation View PVWIN-T30 : > [Capture Delay] (Settable range: 0.0 to 999.9 ms) After image capturing is completed, PV turns on REND signal and executes checkers.
- Page 4 Setting “Image Output” to “Async.(inspection first)” turns on REND signal and allows capturing the third image after the second image capturing or the first synchronous result output (general output through I/O and synchronously) whichever completed later, before outputting the general result and the image of the first inspection is completed.
-
Page 5: Outputting All Results (Output = All)
Outputting All Results (Output = All) When the Handshake Function Is Set to “No” Inspection data are output at intervals of set “Output signal guarantee time (Tp)”. STRB signal turns on each time outputting the data.Receive data with the external device after rising edge of STRB ON signal and before the next STRB signal turns on. - Page 6 When the Handshake Function Is Set to “Yes” Use STRB signal (PV-T30 -> the external device) and ACK signal (The external device -> PV-T30) in pairs. Tf: 400µs (fixed)、Tp: Data output guarantee time, 1-1000ms (default: 10 ms) To: Timeout period, 4 - 20000 ms (default: 5000 ms) Exceeding this time causes a timeout error, terminates output processing, and outputs ERR signal.
-
Page 7: Setting Judgement Conditions
Setting Judgement Conditions In PVWIN-T30 (PV-T30), the logical product of the checker of a inspection item that has been set is automatically referred to JDC000 and output as the total judgment result. In addition, the reversed value of judgment of JDC001 is automatically referred to JDC001. - Page 8 Select the numerical calculation input field and press the ENTER key again. The list of items that can be registered in a calculation is displayed. Checker: Select this to input judgements of checkers including Position Adjustment and Area Size Adjustment. Judgement Select this to input a judgement of JRC (Internal).
-
Page 9: Selecting An Image Output Condition
Selecting Total Judgement Expression Select "Condition" in judgement output setting window. “Condition” setting window is displayed. Select “Condition” column of Total Judge. Select a judgement type to register as a Total Judgement. [NO]: No Total Judgement [JRC]: Use a JRC(Internal) as a Total Judgement [JDC]: Use a JDC(External) as a Total Judgement Select “Checker No.”... - Page 10 A folder named as date and time (YYMMDDHHMMSS= year, month, day, hour, minute, second) is created in the following path of a SD memory card and image files are saved in it.（100 files can be saved in per folder） ¥Panasonic-ID SUNX Vision¥PV-T30¥image¥Output¥ Select “SDcard” from the selectmenu [Environment Setting]-[Input/Output]-[Image Output] -[Destination].
- Page 11 Specifying a Camera Image to Output Select “Yes” in "Camera No.0 Output" of “Image Output”. Doing so makes setting that an inspection image of camera No.0 is output. Selecting Output Condition Other than outputting by an inspection, images can be output when the specified conditions are fulfilled. Select a condition to output images in “Output Condition”.
- Page 12 As the file size is small and the time for saving is shortened, you should use Bayer Image to save many images. Files saved in this format (.byr) cannot be confirmed with general applications such as a PC. Bayer images can be confirmed on PV-T30, PVWIN-T30 or PVImageConverter. Its files size is smaller than that of RGB image (.bmp).
