- Page 1 LDK 4629/00 LDK 4629/00 LDK 4629/00 LDK 4629/00 LDK 4629/00 Operational Control Panel Series 9000 Cam pwr Pan lock OCP pwr Gen lock Camera Triax Base St Non standard Exposure Gamma Monitoring Preset 60 Hz 50 Hz 1/200 1/500 CVBS...
- Page 2 Declaration of Conformity We, Thomson Broadcast Solutions Nederland B.V., Kapittelweg 10, 4827 HG Breda, The Netherlands declare under our sole responsibility that this product is in compliance with the following standards: EN60065 : Safety EN55103-1 : EMC (Emission) EN55103-2 : EMC (Immunity) following the provisions of: a.
-
Page 3: Table Of Contents
Two-wire Data Control Bus ........14 Opening the Operational Control Panel ...... 5 Connectors and Cables ..........15 Mounting in a Desk ............6 Dimensions ..............17 Mounting in a 19 inch Rack .......... 8 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel... -
Page 4: Safety Summary
0.2A in other cable shields. It is strickly prohibited to short circuit the inner and outer shields of a triax cable used to connect a camera to a base station. Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2... -
Page 5: Earthing
• The wire coloured BLUE must be connected to the terminal marked with the letter N or coloured BLACK. Ensure that your equipment is connected correctly - if you are in any doubt consult a qualified electrician. 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel... -
Page 6: Packing/Unpacking
Thomson Multimedia Broadcast Solutions service and should also be protected from high levels of dust. centre. Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2... -
Page 7: Opening The Operational Control Panel
Opening the Operational Control Panel 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel... -
Page 8: Mounting In A Desk
Hole in desk required: 350.7 mm x 106.3 mm. 1. Remove upper panel by loosening screws and 2. Remove mounting plates by loosening the two disconnecting the flat cable. screws securing each plate. Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2... - Page 9 1 15 Scene file Standard Store Preview Call Free Master black 4. Secure operational control box to mounting plates and return upper panel to its original position. 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel...
-
Page 10: Mounting In A 19 Inch Rack
1. Remove upper panel by loosening screws and 2. Remove mounting plates by loosening the two disconnecting the flat cable. screws securing each plate. The mounting plates are not needed for rack mounting. Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2... - Page 11 3. Use four screws to mount operational control into 4. Secure operational control box to 19" rack and the rack using a 19" module rail with mounting return upper panel to its original position. strip. 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel...
-
Page 12: Internally Selectable Functions
Dip Switches position AB. The Dip Switches S2 and S3 have factory settings. Never change these settings. For correct settings of these dip switches see the Series 9000 Application Guide. Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2... -
Page 13: Replacing The Fuses
Replacing the fuses 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel... -
Page 14: Interconnections
Data Cable (2-wire) LDK 20 Base Station LDK 4501 Prod Triax Cable Prog THOMSON Cam +Floor Maximum Camera Base Station Length 2,400 m (7,875 ft) with 14 mm cable Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2... - Page 15 SDTV cameras of the Thomson Multimedia Broadcast Solutions family such as the LDK 20, LDK 100, LDK200, and the LDK 23HS mkII can also be included in this configuration. 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel...
-
Page 16: Two-Wire Data Control Bus
A maximum of 15 looped-through standard camera systems in one chain can be handeld, however, in a multiple system the load of a LDK 23 HS (mkII) is twice the load of a standard camera. Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2... -
Page 17: Connectors And Cables
Mains input voltage: Between 230 Vac and 115 Vac + 15% Mains frequency: 47 to 63 Hz Fuses: 1 A slow, 250 Vac X 1 - Mains Input Connector - Panel view 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel... - Page 18 Shield of cable to the pin marked shield Note: Data cable order nr.: LDK 8113/01 = 1 meter LDK 8113/10 = 10 meters LDK 8113/99 = 100 meters X 891/892 - Data Connector - Panel view Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2...
-
Page 19: Dimensions
3200 K 8/Cap Gain Black Iris Extender Centre Auto iris F-Number Range On air Cam select 1 15 Scene file Standard Store Preview Call Free Master black 119.05 mm 105.93 mm 02.34.2 Technical Manual LDK 4629/00 - Operational Control Panel... - Page 20 Technical Manual LDK 4629/00 - Operational Control Panel 02.34.2...
