Specifications
Physical
Electrical
(The HP AdvanceStack hubs automatically adjust to any voltage between 100
and 240 volts and any frequency between 50 and 60 Hz.)
The maximum current ratings represent the current that could be drawn with a
fully loaded expansion slot and external MAU's.
Environmental
Maximum altitude:
Connectors
The 50-pin and RJ-45 twisted-pair ports are compatible with the
IEEE 802.3 Type 10Base-T standard.
The ThinLAN port is compatible with the IEEE 802.3 Type 10Base2
standard.
The RS-232-C console port conforms to V.22 bis. (Modem use
requires HP J2603A or B Ethernet SNMP Module.)
B-2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
HP J2600A 12-Port Hub
HP J2601B 24-Port Hub
44.2 cm (17.4 in)
Width:
29.8 cm (11.7 in)
Depth:
6.6 cm (2.6 in)
Height:
4.1 kg (9.0 lb)
Weight:
100-127 volts
ac voltage:
Voltage tolerance of +/- 10%
0.6 A (HP J2600A, J2601B)
Typical current:
0.8 A (HP J2602B)
1.0 A
Maximum current:
50/60 Hz
Frequency range:
Operating
Temperature:
0°C to 55°C
(32°F to 131°F)
15% to 95%
Relative humidity:
(non-condensing)
at 40°C (104°F)
4.6 km (15,000 ft)
HP J2602B 48-Port Hub
44.2 cm (17.4 in)
29.8 cm (11.7 in)
11.0 cm (4.3 in)
5.0 kg (11.0 lb)
200-240 volts
Voltage tolerance of +/- 10%
0.3 A (HP J2600A, J2601B)
0.4 A (HP J2602B)
0.6 A
50/60 Hz
Non-Operating
-40°C to 70°C
(-40°F to 158°F)
15% to 90%
at 65°C (149°F)
4.6 km (15,000 ft)
