AX PRO Quick Guide
Alan.Liu

Advertisement

loading

Related Manuals for HIKVISION AX PRO

Summary of Contents for HIKVISION AX PRO

  • Page 1 AX PRO Quick Guide Alan.Liu...
  • Page 2 CONTENTS AX PRO Unboxing AX PRO Adding Peripherals Adding (Involved products: Keypad, Tag, Keyfob, PIRCAM, Siren, Magnetic Contact, PIR and Emergency Button) Operation Via Hik-Connect (Area setting, how to arm/disarm, device share, system operation, SMS&Call, and video verification)
  • Page 3 Product Showcase...
  • Page 4 Product Showcase Keyfob Emergency Button Magnetic Indoor siren Outdoor siren Keypad PIRCAM AX PRO HUB Contact...
  • Page 5 Unboxing...
  • Page 6 Unboxing Model: DS-PWA96-M-WE Accessories Power Adapter Tags AX PRO HUB...
  • Page 7 Unboxing System Status LAN Interface Power Switch Indicators (RJ45) Power Power Supply LED Supply SIM card Tamper Slots (2) Switch Reset RS232 Port Built-in Tag Reader Button • • Front of AX PRO Rear of AX PRO...
  • Page 8 AX PRO Adding...
  • Page 9 Three ways to connect Hub to cloud Use Hik-Connect to connect Hub by Wi-Fi Use LAN port to connect Hub with LAN Use SIM Card...
  • Page 10 Adding via Hik-Connect by Wi-Fi Connect your phone to Wi-Fi first Press Add Device Scan QR code backboard Press Next Choose type of connection (we select wireless here)
  • Page 11 Adding via Hik-Connect Choose ‘The device is started’ Configure your Wi-Fi Press ‘Connect to a Network’ Wait until it connected then click Next...
  • Page 12 Operation Video Add by Wi-Fi...
  • Page 13 Connect to Cloud via SIM Card Cloud status indicator Work available with CMCC CUCC in China mainland Nano Card with card holder Prepare one SIM card Insert SIM card backboard Wait until the status light turns green...
  • Page 14 Adding to Hik-Connect Press Add Device Scan QR code Add device Operation video...
  • Page 15 Connect to Cloud with Router Cloud status indicator Connect the Hub with router, wait until the status light turns green...
  • Page 16 Adding to Hik-Connect Same as SIM Card’s Method Adding video...
  • Page 17 Reset Reset Button Power on the hub, when hear the first voice, press and hold on the reset button Reset Video...
  • Page 18 Peripherals Adding...
  • Page 19 In this part, you may need Wireless Keypad DS-PK1-E-WE Wireless Keyfob DS-PKF1-WE DS-PTS-MF PIRCAM DS-PDPC12P-EG2-WE DS-PDC15-EG2-WE Wireless Magnetic Contact DS-PDMC-EG2-WE Wireless Outdoor Siren DS-PS1-E-WE Wireless Emergency Button DS-PDEB2-EG2-WE...
  • Page 20 Keypad Adding Keypad Accessories Unboxing...
  • Page 21 Keypad Adding Power Switch Open the keypad with screwdriver...
  • Page 22 Keypad Adding You’d better open the keypad before adding Press AX PRO interface Power up keypad and finish Press ‘+’ to add Scan QR code of the keypad to configuration site...
  • Page 23 Keypad Setting Press ‘>’ to check status Press Setting Button to configure Keypad Setting interface...
  • Page 24 Password Setting Press Setting Button to configure Press ‘>’ to User interface Press User interface to User management site...
  • Page 25 Password Setting Press ‘>’ to set password Set a password and press OK Finished...
  • Page 26 Operation Video for Keypad Adding Setting...
  • Page 27 Tag Adding Press Setting Button to configure Press ‘>’ to Tag interface Press ‘+’ to add Tag Swipe tag on the tag reader of the hub...
  • Page 28 Tag Setting Press ‘>’ to Tag interface Press Tag interface to configuration site Tag Setting interface Operation video...
  • Page 29 Keyfob Adding You’d better open the keypad before adding Keyfob User Manual Unboxing...
  • Page 30 Keyfob Adding Open the keyfob with screwdriver...
  • Page 31 Keyfob Adding Press ‘+’ to add Scan the QR code of Keyfob Press Arm button to add Set and finish...
  • Page 32 Keyfob Setting Press ‘>’ to set Choose the key that you want Select the function you want...
  • Page 33 PIRCAM Adding PIRCAM User Manual Accessories Unboxing...
  • Page 34 PIRCAM Adding Easy-change battery Tamper Switch Power Switch Open the PIRCAM with screwdriver...
  • Page 35 PIRCAM Adding You’d better open the PIRCAM before adding Power up PIRCAM and finish Press ‘+’ to add Scan the QR code of PIRCAM...
  • Page 36 PIRCAM Setting Press ‘>’ to check status Press Setting Button to configure PIRCAM Setting interface...
  • Page 37 Operation Video PIRCAM...
  • Page 38 PIR Adding User Manual Accessories Unboxing...
  • Page 39 PIR Adding Easy-change battery Tamper Switch Power Switch Open the PIR with screwdriver...
  • Page 40 PIR Adding You’d better open the keypad before adding Press ‘+’ to add Scan the QR code of PIR Power up and add Set and finish...
  • Page 41 Magnetic Contact Adding Magnetic User Manual Contact Accessories Unboxing...
  • Page 42 Magnetic Contact Adding Press ‘+’ to add Power up and add Set and finish Scan the QR code of MC...
  • Page 43 Siren Adding Tamper Switch Power Switch Open the Siren with screwdriver...
  • Page 44 Siren Adding Press ‘+’ to add Power up and add Set and finish Scan the QR code of Siren...
  • Page 45 Emergency Button Adding Emergency Sticker Button Unboxing...
  • Page 46 Emergency Button Adding Press ‘+’ to add Press button to add Set and finish Scan the QR code...
  • Page 47 Operation Via Hik-Connect...
  • Page 48 Area Adding Press Setting Button to configure Press ‘>’ to Area interface Choose the Area you want Press to enable...
  • Page 49 Area Setting Press to link zones...
  • Page 50 Operation Video...
  • Page 51 Something you should know These four buttons are used for the whole system, not for a single area. Away Alarm Stay Disarm Clear...
  • Page 52 Arming Arm successfully System Fault Check, press OK to continue Press Area 1 icon to arm Area 1...
  • Page 53 Disarming Press Area1 icon to disarm the system System disarmed...
  • Page 54 Alarm Clear Trigger the detector somehow Press Area2 icon to clear alarm Alarm clear...
  • Page 55 Operation Video Arming Alarm clear...
  • Page 56 Device Share Press to share Choose the way you want Use phone number or email to share...
  • Page 57 Device Share Scan QR code and share Choose the way you want Choose the device and share (other’s Hik-Connect)
  • Page 58 Device Share Receive notification Accept and finish...
  • Page 59 System Configuration Press Setting Button to configure Press ‘>’ to Configuration interface You can set Language and Time Zone here...
  • Page 60 System Configuration Press ‘>’ to System Options Option Management Fault Check...
  • Page 61 SMS & Call Press ‘>’ to add phone numbers Press to continue Add and configure Add and configure...
  • Page 62 SMS & Call Notification SMS Call...
  • Page 63 Video Verification Camera Adding Press ‘>’ to add camera Refresh and finish Press to add Input parameters and save...
  • Page 64 Video Verification Zone linkage Select one detector you want to link Press ‘>’ to link Press to configure Select one camera and finish...
  • Page 65 Video Verification Operation Video...
  • Page 66 Thanks...
