Operating Instructions
Operation Manual
Intelligent Adhesive Tape Feeder
Thank you very much for purchasing the intelligent adhesive tape feeder for the CM402 series.
Before placing the machine in service, be sure to read the instruction manual for proper
usage.
After that, store it carefully and read it if necessary.
IATF-E-OMAA-0003
Advertisement
Related Manuals for Panasonic CM402 Series
Summary of Contents for Panasonic CM402 Series
- Page 1 Operating Instructions Operation Manual Intelligent Adhesive Tape Feeder Thank you very much for purchasing the intelligent adhesive tape feeder for the CM402 series. Before placing the machine in service, be sure to read the instruction manual for proper usage. After that, store it carefully and read it if necessary.
- Page 3 This machine shall be operated by professional, specially trained operators. It shall not be operated by non-professional, not specially trained operators. Regarding the training course, please contact Panasonic Factory Solutions Co., Ltd. or PFSE.” Machine was manufactured by: Panasonic Factory Solutions Co., Ltd.
- Page 4 Introduction This manual describes how to handle the intelligent adhesive tape feeder for the placement machine CM402, and how to supply components. Product code : KXFW1KSGA00 NOTICE 1. When the intelligent adhesive tape feeder is unpacked, its reel mount is detached. Attach the reel mount to the main body before use.
- Page 5 = MEMO = IATF-E-OMA00-A01-00...
- Page 6 TABLE OF CONTENTS Safety precautions ............7 About storage management and handling........10 1. GENERAL DESCRIPTION......1-1 1.1 Preparation before Production................1-2 1.2 Exterior Features ....................1-3 1.3 Switch and LED Features..................1-5 1.4 Model and Its Target Components ............... 1-6 2.
-
Page 7: Safety Precautions
SAFETY PRECAUTIONS Be sure to observe The precautions that shall be observed in order to prevent an injury to the user or the other persons, and damage to property, are described as follows. The degrees of danger or injury, resulting from incorrect usage owing to failure to read an indication, are classified and described as follows. - Page 8 WARNING IATF-E-OMA00-A03-00...
- Page 9 CAUTION IATF-E-OMA00-A03-00...
-
Page 10: Storage Precautions
About storage management and handling This describes the precautions in the storage of adhesive tape feeders. NOTICE In handling adhesive tape feeders, be sure to observe the following matters. The matters are the same as those for intelligent tape feeders. 1 Storage Precautions Use a feeder stand for storage. - Page 11 Avoid storing them in a magnetized place. If the area around the pickup section becomes magnetized, some chips will be susceptible to damage. IATF-003E Avoid storing them in the place where oil or an organic solvent is splashed. Otherwise, rubber and resin parts may potentially be deteriorated and broken. IATF-003E Avoid bumping or dropping them.
- Page 12 2 Handling Precautions A) Handling of adhesive tape feeders In handling the adhesive tape feeder, use both hands. If you handle it with one hand, you may potentially drop it and be injured. IATF-024P In setting the adhesive tape feeder onto the collectively changing truck, use both hands.
- Page 13 B) Handling of screws and covers NOTICE Some screws and covers mounted on the adhesive tape feeder are important for insuring accuracy. Be careful enough in handling. These are eccentric pins for adjusting the pickup position and are adjusted to the optimum position in advance;...
- Page 14 = MEMO = IATF-E-OMA00-A04-00...
