- Page 1 INSTRUCTION MANUAL Shear Wrench 6924N DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model 6924N Bolt size M22, M24 Max. normal torque 1,100 N•m No load speed (min Dimensions (L×W×H) 330 mm × 104 mm × 257 mm Net weight 7.5 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change without notice. • Specifications may differ from country to country. • Weight according to EPTA-Procedure 01/2014... - Page 3 Before using power tool, make sure that the outer sleeve smoothly turns by hand. When it does not smoothly turn, never use it and ask MAKITA It is an employer's responsibility to enforce Authorized Service Center for check and repair.
-
Page 4: Functional Description
Use care and common sense when disposing Removing the outer and inner sleeves of sheared bolt tips. Falling tips from high loca- tions or scattered tips can cause severe injury. SAVE THESE INSTRUCTIONS. WARNING: DO NOT let comfort or famil- iarity with product (gained from repeated use) replace strict adherence to shear wrench safety rules for the subject product. -
Page 5: Operation
Installing the outer and inner OPERATION sleeves Bolt installation Hold the inner sleeve with the pin facing upward. Place the outer sleeve over the inner sleeve. Press the pin to Slip the tool onto the bolt so that the inner sleeve com- allow inserting the inner sleeve, then release the pin to pletely covers the bolt tip. - Page 6 Pull the switch trigger. The outer sleeve turns to begin tightening the nut. When the specified torque is attained, the bolt tip will be sheared at its notched portion. The bolt tip will remain inside the inner sleeve. ► 1 . Tip ejector (Tip lever) CAUTION: • Washer and nut have head and tail. Head has identification mark for nut and chamfer for ► 1 .
-
Page 7: Maintenance
Only use accessory or attachment for may result. its stated purpose. Replacing carbon brushes If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. Sleeve Bolt size Length (mm) Outer sleeve... - Page 8 Makita Corporation 884567D4 20180110 www.makita.com...
