INSTALLATION INSTRUCTIONS
2017-2018 FORD
STEALTH GRILLE MOUNT
*THIS MOUNT FITS THE FOLLOWING LIGHTS:
THANK YOU FOR PURCHASING RIGID INDUSTRIES' PRODUCTS FOR YOUR VEHICLE.
Please read through all of these Instructions and tips before proceeding with the installation.
We do our best to provide a simple installation process for all applications however
Always disconnect any power sources connected to your vehicle
(Excludes PLATINUM Edition)
(2) 6" SR-Series
IMPORTANT
a professional installation is always recommended.
before servicing fuses or electrical systems.
SUPER DUTY
®
PRODUCT INCLUDES:
(1) Stealth Grille Mount
* LIGHTS SOLD SEPARATELY
®
®
Advertisement
Summary of Contents for RIDGID STEALTH
- Page 1 SUPER DUTY ® ® STEALTH GRILLE MOUNT (Excludes PLATINUM Edition) PRODUCT INCLUDES: (1) Stealth Grille Mount * LIGHTS SOLD SEPARATELY *THIS MOUNT FITS THE FOLLOWING LIGHTS: (2) 6” SR-Series ® IMPORTANT THANK YOU FOR PURCHASING RIGID INDUSTRIES’ PRODUCTS FOR YOUR VEHICLE.
- Page 2 STEP 1 FIGURE 1 Open hood and remove the plastic push pins that attach the plastic radiator shield. Use push pin pliers, non-marring prybar or equivalent. See Figures 1, 1.1 FIGURE 1.1 STEP 2 FIGURE 2 Reove the (8) 10mm bolts towards the front of the truck and set aside to install later.
- Page 3 STEP 3 FIGURE 3 Remove grille by pulling away from the truck on the top and using a pick or a flat head screw driver, push pins down on the bottom of the grille and pull the grille out. NOTE - BE SURE NOT TO DROP ANY CLIPS WHEN REMOVING THE GRILLE See Figures 3, 3.1...
