  • Page 1 OWNER'S MANUAL BEDIENUNGSANLEITUNG MODE D'EMPLOLI MANUAL DE INSTRUCCIONES 取扱説明書...
  • Page 2 Compliance with FCC regulations does not guarantee that interference will not occur in all * This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Yamaha Pro Audio web site at: http://www.yamahaproaudio.com/ • Do not install the MY16-CII card in any Yamaha products not specified by Yamaha for use with the MY16-CII to avoid possible electrical shock, fire, or equipment damage.

  • Page 4: Table Of Contents

    The MY16-CII System ........

  • Page 5: Package Contents

    Package Contents • MY16-CII card • This manual • CD-ROM (CobraNet Manager) The CobraNet Manager software license agreement can be found at the end of this document (on page 15). Please be sure to read the software license agreement before installing the software.

  • Page 6: About Cobranet

    The MY16-CII can use up to 4 output bundles and up to 8 input bundles. Bundle numbers can be assigned via the CobraNet Manager application.
  • Page 7 4 receiving devices may be able to simultaneously receive the same bundle. This situation is known as “multi-unicast.” The MY16-CII is capable of handling multi-unicast bundles. Different number ranges are used for multicast and unicast bundles: multicast bundles are numbered 1 through 255, while unicast bundles are numbered 256 through 65,279.
  • Page 8 The conductor for the network is automatically assigned and need not be specified by the operator. When an MY16-CII is assigned to be the conductor for the network, the LED indicator to the left of the connector that is connected to the network will flash orange. If the conductor fails for some reason, conductor status is automatically switched to another device on the network.

  • Page 9: The My16-Cii System

    The MY16-CII System The MY16-CII handles 16 channels of audio input and output that are assigned to bundles that will be transmitted and received to and from the appropriate network devices. The MY16-CII can use up to 4 output bundles and up to 8 input bundles.

  • Page 10: Controls & Functions

    If the indicator continues flashing orange even after the cable is disconnected, there may be a fault in the MY16-CII card itself. In this case please refer the problem to qualified Yamaha service personnel.
  • Page 11 Slide Switch The slide switch on the MY16-CII circuit board is set to MODE5. Please do not change this setting, otherwise the unit will not operate properly. MY16-Cll Owner’s Manual...

  • Page 12: Connection Examples

    Connection Examples Connecting Two Devices YAMAHA Digital mixier Connecting via Hub EXT. NETWORK CLOCK PEAK 96kHz 88.2kHz MASTER SIGNAL 48kHz 44.1kHz PEAK SCENE NUMBER SIGNAL MY16-CII DME24N MY16-CII MY16-CII MY16-CII MY16-CII DME64N MY16-Cll Owner’s Manual MY16-CII DME64N MY16-CII MY16-CII DME64N...
  • Page 13 PEAK SCENE NUMBER SIGNAL MY16-C DME24N Switching Hub MY16-CII MY16-CII DME64N CobraNet Redundancy Network n Redundancy Networks Redundancy networks employ dual (primary and secondary) circuits. Communication usually occurs over the primary circuit, but if a failure occurs on the primary circuit – cable failure, accidental disconnection, switch failure, etc.

  • Page 14: Cobranet Manager Installation

    3. Follow the on-screen instructions to complete the setup procedure. For instructions on using the CobraNet Manager to set up the MY16-CII, refer to the ‘‘CobraNet Manager Lite for Yamaha’’ owner’s manual that is provided in pdf format the CD-ROM ‘‘Manual’’...

  • Page 15: Software License Agreement

    Agreement ( Agreement ). It is an agreement between you (as individual or a legal entity) and Yamaha Corporation (‘‘Yamaha’’). The Yamaha software program(s) enclosed is/are licensed by Yamaha and Yamaha’s licensor(s) to you for use that is compliant with the terms set forth therein. Please read this Agreement carefully.

  • Page 16: Specifications

    10–35 (Operating Temperature Range) Temperature Range (˚C) -20–60 (Storage Temperature Range) Accessories Owner's Manual, CD-ROM * Jitter is measured with DME64N (MASTER CLOCK : MY16-CII) DIGITAL INPUT/OUTPUT CHARACTERISTICS Terminal PRIMARY, SECONDARY * Double Channel format and Single format are supported at 96kHz.
  • Page 17 Connection TxD+ TxD– RxD+ Unused Unused RxD– Unused Unused Cross Cables Pins 1 —— 3 2 —— 6 3 —— 1 4 —— 4 5 —— 5 6 —— 2 7 —— 7 8 —— 8 Pins MY16-CII Owner’s Manual...
  • Page 18 * Les caractéristiques techniques et les descriptions du mode d’emploi ne sont données que pour information. Yamaha Corp. se réserve le droit de changer ou modifier les produits et leurs caractéristiques techniques à tout moment sans aucun avis. Du fait que les caractéristiques techniques, les équipements et les options peuvent différer d’un pays à...
  • Page 19 For details of products, please contact your nearest Yamaha representative or the authorized distributor listed below. Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou au distributeur le plus proche de vous figurant dans la liste suivante. NORTH AMERICA CANADA Yamaha Canada Music Ltd.
  • Page 20 PT. Nusantik Gedung Yamaha Music Center, Jalan Jend. Gatot Subroto Kav. 4, Jakarta 12930, Indonesia Tel: 21-520-2577 HEAD OFFICE Yamaha Corporation, Pro Audio & Digital Musical Instrument Division PA13 KOREA Yamaha Music Korea Ltd. Tong-Yang Securities Bldg. 16F 23-8 Yoido-dong,...
  • Page 21 Yamaha Pro Audio global web site: http://www.yamahaproaudio.com/ Yamaha Manual Library http://www.yamaha.co.jp/manual/ U.R.G., Pro Audio & Digital Musical Instrument Division, Yamaha Corporation © 2006 Yamaha Corporation WG96060 606MWCP5.2-01A0 This document is printed on chlorine free (ECF) paper with soy ink. Printed in JAPAN...
