- Page 1 Patent(s) Pending Dell OptiPlex SFF and Monitor Wall Mount Installation Instructions Kit P/N: 104-2324...
- Page 2 Kit Contents Wall Mount Hardware Package: Assembly Components: (4) Pan Head Screw (1) Main Bracket (4) Anchors (1) Cover (1) Pivot Assembly Monitor Hardware Package: (8) Nylon Spacers (5) M4 x 10mm Pan Head Screws (5) M4 x 18mm Pan Head Screws (5) M4 x 25mm Pan Head Screws (5) 8-32 Flat Head Screws PC Wall Mount Installation Instructions...
- Page 3 Installation Instructions Step 4. VESA Monitor Bracket Attachment: surface. Locate the four VESA mounting holes on the rear of the monitor. a. Determine if spacers are required: Some monitors have a "recess" on the rear length options. b. Determine Screw Length: Only use the metric M4 screws provided. Screw length is determined by the spacers used (see Table A).
- Page 4 Installation Instructions Step 6. Computer and Cover Attachment: Slide the computer into the Main Bracket. Main Bracket Cover Captive Screw Dell OptiPlex SFF Step 7. Attach Mount Base: Attach the base to the wall using the 4 screws that were installed in 3b.
