Panasonic RB-M700B Basic Operating Instructions

Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
GE
Manufactured by: Panasonic Corporation
Kadoma, Osaka, Japan
Authorized Representative in Europe: Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Panasonic Corporation
http://www.panasonic.com
© Panasonic Corporation 2020
More detailed operating instructions
are available in "Owner's Manual
(PDF format)".
To read it, download it from the
website.
https://panasonic.jp/support/global/
cs/accessories/oi/rb_m700b/
• Click the desired language.
Expressions used in this document
• The product illustrations may differ from the actual product.
until
2020/2/10
Basic Operating Instructions
Digital Wireless Stereo Headphones
RB-M700B
Model No.
TQBM0661
F0220MH0
Accessories
Please check and identify the supplied accessories.
To order accessories, contact the dealer from whom you
have made your purchase.
1 x USB charging cord
1 x Detachable cord
Maintenance
Clean this unit with a dry and soft cloth.
• Do not use solvents including benzine, thinner, alcohol, kitchen
detergent, a chemical wiper, etc. This might cause the exterior
case to be deformed or the coating to come off.
Keeping the battery performance.
• During the long period of disuse, full charge this unit once every
6 months to keep the battery performance.
Safety precautions
∫ Unit
WARNING:
To reduce the risk of fire, electric shock or product damage,
• Do not expose this unit to rain, moisture, dripping or
splashing.
• Do not place objects filled with liquids, such as vases, on
this unit.
• Use the recommended accessories.
• Do not remove covers.
• Do not repair this unit by yourself. Refer servicing to
qualified service personnel.
Avoid the use in the following conditions
• High or low extreme temperatures during use, storage or
transportation.
• Disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion.
• Extremely high temperature and/or extremely low air pressure
that can result in an explosion or the leakage of flammable liquid
or gas.
• Avoid using or placing this unit near sources of heat.
• Do not listen with this unit at high volume in places where you
need to hear sounds from the surrounding environment for safety,
such as at railroad crossings, and construction sites.
• Wide band characteristic voltage equal or larger than 75 mV.
• Keep this unit away from something susceptible to the magnetism.
Such devices as a clock may not operate correctly.
• When using this unit in an airplane, heed the instructions given by
the airline company. Some airlines may forbid your using the unit.
For further details, contact the airline you will be flying with.
∫ Allergies
• Discontinue use if you experience discomfort with the ear pads or
any other parts that directly contact your skin.
• Continued use may cause rashes or other allergic reactions.
∫ Precautions for listening with the Headphones
• Excessive sound pressure from earphones and headphones can
cause hearing loss.
• Do not use your headphones at a high volume. Hearing experts
advise against continuous extended play.
• If you experience a ringing in your ears, reduce volume or
discontinue use.
• Do not use while operating a motorised vehicle. It may create a
traffic hazard and is illegal in many areas.
• You should use extreme caution or temporarily discontinue use in
potentially hazardous situations.
This unit may receive radio interference caused by mobile
telephones during use. If such interference occurs, please
increase separation between this unit and the mobile telephone.
Use only the supplied USB charging cord when connecting to a
computer.
This unit is intended for use in moderate and tropical climates.
1 Remove the right ear pad to view certification information.
2 Certification information (a) is indicated on the speaker plate
EU
portion (b), which becomes visible when the right ear pad (R
side) is removed.
3 To attach the ear pad, fit the part d of the ear pad into the part
c.
If you pull the ear pad too much, the ear pad can tear.
1 2
3


Copyright notice
This product uses open source software based on the Free Software
Foundation's GPL and other conditions. The relevant conditions apply to
the software. The license information for the GPL shown on this product
and information about open source software are published on our
website. The source code licensed under the conditions of the GPL is
available publicly. Please note that these types of software are not
covered by warranty. At least 3 years from sale of this product,
Panasonic Corporation will give to any individual or group who contacts
us, for a charge of no more than the cost of physically distributing source
code, a complete machine-readable copy of the source code and the list
of copyright notices corresponding to the GPL software covered under
the conditions of the GPL usage agreement.
Refer to the following URL to make enquiries regarding the above
mentioned content and for information on how to obtain the relevant
source code:
https://panasonic.jp/support/global/cs/audio/download/index.html
Troubleshooting
Before requesting service, make the following checks. If you are in doubt
about some of the check points, or if the remedies indicated in the chart
do not solve the problem, consult your dealer for instructions.
No sound.
®
• Make sure that the unit and the Bluetooth device are connected
l
correctly. ( Rear page, )
D
®
• Check if music is playing on the Bluetooth device.
• Make sure that the unit is turned on and the volume is not set too low.
®
• Pair and connect the Bluetooth device and the unit again. (
page, D )
®
• Check if the Bluetooth compatible device supports "A2DP" profile. For
details on profiles, see "Listening to music" in "Owner's Manual (PDF
format)". Also refer to the operating manual for the Bluetooth
compatible device.
Cannot adjust the volume.
• The control button does not work when the detachable cord (supplied) is
used.
Low volume.
l
E
• Increase the volume of the unit. ( Rear page, )
®
• Increase the volume on the Bluetooth device.
Sound from the device is cut off. / Too much noise. / Sound quality is
bad.
• Sound may be disrupted if signals are blocked. Do not fully cover this
unit with the palm of your hand, etc.
• The device may be out of the 10 m communication range. Move the
device closer to this unit.
• Remove any obstacle between this unit and the device.
• Switch off any wireless LAN device when not in use.
The device cannot be connected.
• Delete the pairing information for this unit from the Bluetooth
l
then pair them again. ( Rear page, D )
You cannot hear the person on the other end of the call.
®
• Make sure that the unit and the Bluetooth enabled phone are turned
on.
®
• Check if the unit and the Bluetooth enabled phone are connected.
l
( Rear page, D )
®
• Check the audio settings of the Bluetooth enabled phone. Switch the
®
calling device to the unit if it is set to the Bluetooth enabled phone.
l
( Rear page, )
D
• If the volume of the other person's voice is too low, increase the volume
®
of both the unit and the Bluetooth enabled phone.
Cannot make a phone call.
®
• Check if the Bluetooth compatible device supports "HSP" or "HFP"
profile. For details on profiles, see "Listening to music" and "Making a
phone call" in "Owner's manual (PDF format)". Also refer to the
®
operating manual for the Bluetooth enabled phone.
The unit does not respond.
• This unit can be reset when all operations are rejected. To reset the unit,
connect the unit to a computer using the USB charging cord. (The
pairing device information will not be deleted.)
Cannot charge the unit.
• Is the USB port you are currently using working properly? If your
computer has other USB ports, unplug the connector from its current
port and plug it into one of the other ports.
• If the measures mentioned above are not applicable, unplug the USB
charging cord and plug it in again.
• If the charge time and operating time become shortened, the battery
may have run down. (Number of charging times of the installed battery:
Approximately 300)
The power/pairing LED does not light during charging. / Charging
takes longer.
• Is the USB charging cord connected firmly to the USB terminal of the
l
computer? ( Rear page, )
B
• Make sure to charge in a room temperature between 10 oC and 35 oC
(50 oF to 95 oF).
The power does not turn on.
• Is the unit being charged? The power cannot be turned ON during
l
charging. ( Rear page, B )
The audio guidance language has changed.

• The audio guidance language can be switched.
(Press and hold [ ] and [j] at the same time for at least 5 seconds.)
Specifications

∫ General
Power supply DC 5 V, 300 mA
(Internal battery: 3.7 V
(Li-polymer))
*1
Operating time Approx. 20 hours
(Bass reactor: Off, Noise
cancelling: ON, SBC)
*2
Charging time Approx. 4 hours
Charging temperature range 10 oC to 35 oC
Operating temperature range 0 oC to 40 oC
Operating humidity range 35 %RH to 80 %RH
(no condensation)
Mass Approx. 317 g (without cord)
®
∫ Bluetooth section
Frequency band 2402 MHz to 2480 MHz
Supported profiles A2DP, AVRCP, HSP, HFP
Supported codec SBC, AAC
∫ Headphone section
Impedance XX Ω (Power off, with cord)
∫ Speaker section
Power handling capacity 1000 mW (IEC)
*1 It may be shorter depending on the operating conditions.
*2 The time required to charge the battery from empty to full.
• Specifications are subject to change without notice.
®
The Bluetooth word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation
is under license.
Other trademarks and trade names are those of their respective owners.
Siri is a trademarks of Apple Inc., registered in the U.S. and other
countries.
QR Code is a registered trademark of DENSO WAVE INCORPORATED.
Other system names and product names appearing in this document are
in general the registered trademarks or trademarks of the respective
developer companies.
TM ®
Note that the mark and mark do not appear in this document.
