Install the Shelf and Common Control Cards
This chapter explains how to install the Cisco ONS 15454 ETSI and Cisco ONS 15454 ANSI shelf
assemblies. Where procedures differ for the two shelf types, the procedure will indicate "ANSI only" or
"ETSI only." For a summary of the tools and equipment required for installation, see the
and Equipment (ETSI)" section on page 1-5
page
Note
Unless otherwise specified, "ONS 15454" refers to both ANSI and ETSI shelf assemblies.
Before You Begin
This section lists the chapter procedures (NTPs). Turn to a procedure for applicable tasks (DLPs). Read
the installation procedures and precautions before you install the ONS 15454 ANSI or ONS 15454 ETSI
and connect the power source.
1.
2.
3.
4.
5.
6.
7.
8.
78-17704-02
1-3.
NTP-G1 Unpack and Inspect the Shelf Assembly, page
continuing with the
"NTP-G2 Install the Shelf Assembly" procedure on page
NTP-G2 Install the Shelf Assembly, page
assembly in a rack.
NTP-G3 Open and Remove the Front Door, page
equipment before continuing with other procedures in this chapter.
NTP-G4 Open and Remove the FMEC Cover (ETSI Only), page
access the electrical facility connection assembly (EFCA) for the front mount electrical connections
(FMECs) before continuing with other procedures in this chapter.
NTP-G5 Remove the Backplane Covers (ANSI Only), page
access the backplane before continuing with other procedures.
NTP-G6 Install the MIC-A/P and MIC-T/C/P FMECs (ETSI Only), page
procedure to install the MIC-A/P and MIC-T/C/P FMECs, which are required for power supply as
well as alarm, timing, and LAN connections.
NTP-G7 Install the Power and Ground, page
the
"NTP-G8 Install the Fan-Tray Assembly" procedure on page
NTP-G8 Install the Fan-Tray Assembly, page
assembly in the shelf.
C H A P T E R
or the
"Required Tools and Equipment (ANSI)" section on
1-6—Complete this procedure before
1-8—Complete this procedure to install the shelf
1-21—Complete this procedure to access the
1-25—Complete this procedure to
1-28—Complete this procedure to
1-32—Complete this procedure before continuing with
1-42.
1-42—Complete this procedure to install the fan-tray
Cisco ONS 15454 DWDM Procedure Guide, R8.0
1
"Required Tools
1-8.
1-30—Complete this
1-1

Advertisement

Table of Contents
loading

Related Manuals for Cisco ONS 15454 ETSI

Summary of Contents for Cisco ONS 15454 ETSI

  • Page 1 Install the Shelf and Common Control Cards This chapter explains how to install the Cisco ONS 15454 ETSI and Cisco ONS 15454 ANSI shelf assemblies. Where procedures differ for the two shelf types, the procedure will indicate “ANSI only” or “ETSI only.”...
  • Page 2 1-81—Complete this procedure as needed. NTP-G158 Connect a Multishelf Node and Subtending Shelves to a Catalyst 2950, page 1-83—Complete this procedure as needed. NTP-G159 Configure a Cisco Catalyst 2950 for a Multishelf Node, page 1-83—Complete this procedure as needed. NTP-G16 Perform the Shelf Installation Acceptance Test, page 1-85—Complete this procedure to...
  • Page 3 Plastic fiber management guides (2) – Fan filter bracket screws (53-48-0003) (6) – User-Supplied Materials (ANSI) The following materials and tools are required but are not supplied with the ONS 15454 ANSI: Cisco ONS 15454 DWDM Procedure Guide, R8.0 78-17704-02...
  • Page 4 The following test equipment is needed to install an ONS 15454 ANSI: Voltmeter • Optical power meter (for use with fiber optics only) • • Bit error rate (BER) tester, DS-1 and DS-3 Cisco ONS 15454 DWDM Procedure Guide, R8.0 78-17704-02...
  • Page 5 • Power cable (from fuse and alarm panel to MIC-A/P and MIC-C/T/P) (2) • Only use the power cables that are designed to be used with ONS 15454 ETSI. They are sold separately. Caution User-Supplied Equipment (ETSI) The following materials and tools are required for installation but are not supplied with the ONS 15454 ETSI: Equipment rack (ETSI rack, 2200 mm [86.6 inch] H x 600 mm [23.6 inch] W...
  • Page 6 NTP- G1 Unpack and Inspect the Shelf Assembly Wire cutters • Ring runs are not provided by Cisco and can hinder side-by-side shelf installation where space is limited. Note Tools Needed (ETSI) To install the ONS 15454 ETSI, you need the following tools.
  • Page 7 The pins are not bent or broken. • The frame is not bent. • If the pins are bent or broken, or the frame is bent, call your Cisco sales engineer for a replacement. Step 3 Close the front door before installing. Step 4 Cisco ONS 15454 DWDM Procedure Guide, R8.0...
  • Page 8 To prevent the system from overheating, do not operate it in an area that exceeds the maximum recommended ambient temperature of: 45 degrees C (113 degrees F). Statement 1047 Warning Take care when connecting units to the supply circuit so that wiring is not overloaded. Statement 1018 Cisco ONS 15454 DWDM Procedure Guide, R8.0 78-17704-02...

  • Page 9: Table Of Contents

    DLP-G8 Install the Air Ramp for Standard and Deep Door ONS 15454, page 1-18 Step 4 Continue with the “NTP-G3 Open and Remove the Front Door” procedure on page 1-21. Stop. You have completed this procedure. Cisco ONS 15454 DWDM Procedure Guide, R8.0 78-17704-02...

  • Page 10: Step 1

    Align the mounting bracket screw holes against the shelf assembly screw holes. Insert the screws that were removed in Step 1 and tighten them. Step 5 Repeat the task for the mounting bracket on the opposite side. Step 6 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-10 78-17704-02...
  • Page 11 Caution Although the air filter can work with older fan trays if it is installed with either side facing up, Cisco recommends that you install it with the metal bracing facing up to preserve the surface of the filter. You must install the air filter with the metal bracing facing up with 15454-CC-FTA.
  • Page 12 Step 1 With the fan-tray assembly removed, place the ONS 15454 facedown on a flat surface. Although the air filter can work with older fan trays if it is installed with either side facing up, Cisco Caution recommends that you install it with the metal bracing facing up to preserve the surface of the filter. You must install the air filter with the metal bracing facing up with 15454-CC-FTA.

  • Page 13: Dlp-G5 Mount The Shelf Assembly In A Rack (One Person)

    Onsite Security Level None The ONS 15454 ETSI requires 616.5 mm (24.24 inch) minimum of vertical rack space and 25 mm Note (1 inch) below the installed shelf assembly to allow air flow to the fan intake. If a second ONS 15454 ETSI is installed above a shelf assembly, the air ramp between the shelves provides space for air flow.
  • Page 14 Chapter 1 Install the Shelf and Common Control Cards NTP- G5 Mount the Shelf Assembly in a Rack (One Person) Figure 1-3 shows the rack-mounting position for the ONS 15454 ETSI. Figure 1-3 Mounting an ONS 15454 ETSI in a Rack...

  • Page 15: Dlp-G6 Mount The Shelf Assembly In A Rack (Two People)

    Onsite Security Level None The ONS 15454 ETSI requires 616.5 mm (24.24 inch) minimum of vertical rack space and 25 mm Note (1 inch) below the installed shelf assembly to allow air flow to the fan intake. If a second ONS 15454 ETSI is installed above a shelf assembly, the air ramp between the shelves provides space for air flow.

  • Page 16: Dlp-G7 Mount Multiple Shelf Assemblies In A Rack

    When using third-party equipment above the ONS 15454 ETSI, provide a minimum of 25 mm (1 inch) between the third-party unit and the bottom of the ONS 15454 ETSI. The third-party equipment must not vent heat upward into the ONS 15454 ETSI.
  • Page 17 1-18. The air ramp is needed if you install more than one ONS 15454 ETSI shelf in a rack. To ensure that the air ramp is secure, use one or two M6 mounting screws for each side of the shelf assembly.

  • Page 18: Dlp-G8 Install The Air Ramp For Standard And Deep Door Ons 15454

    Step 1 Locate the rack mount unit (RMU) space specified in your site plan. Refer to the “Shelf Assembly Hardware” chapter in the Cisco ONS 15454 DWDM Reference Manual for more information about air ramp placement. Verify the rack type of your air ramp installation. The brackets are compatible with the following racks.
  • Page 19 The bracket mounting holes will align with the forward-most mounting holes on the air ramp. When Step 7 aligned properly the mounting flange will be 124 mm from the front edge of the air ramp. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-19 78-17704-02...
  • Page 20 The bracket mounting holes will align with the forward-most mounting holes on the air ramp. When Step 10 aligned properly the mounting flange will be 80 mm from the front edge of the air ramp. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-20 78-17704-02...
  • Page 21 “NTP-G4 Open and Remove the FMEC Cover (ETSI Step 3 Only)” procedure on page 1-25. If you are using an ANSI shelf, continue with the “NTP-G5 Remove the Backplane Covers (ANSI Only)” procedure on page 1-28. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-21 78-17704-02...

  • Page 22: Stop. You Have Completed This Procedure

    The ONS 15454 shelf assembly comes with a pinned hex key for locking and unlocking the front door. Turn the key counterclockwise to unlock the door and clockwise to lock it. Figure 1-9 illustrates the front door of the ANSI shelf. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-22 78-17704-02...
  • Page 23 Required/As Needed As needed Onsite/Remote Onsite Security Level None For ONS 15454 ETSI shelves: Step 1 Unscrew the nut holding the ground wire to the shelf. Remove the nut and washer. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-23 78-17704-02...
  • Page 24 Remove the ground wire from the shelf. Hold the door at the top left corner and remove the door from its hinges (Figure 1-10). Figure 1-10 Removing the ONS 15454 ETSI Front Door F A N F A IL M IN Translucent...
  • Page 25 NTP-G4 Open and Remove the FMEC Cover (ETSI Only) Purpose This procedure opens and removes the FMEC cover on the ONS 15454 ETSI. The ONS 15454 ETSI has a screw-in panel over the EFCA. The FMEC cover protects the FMEC cards. Tools/Equipment...
  • Page 26 F A N F A IL M IN Use the handles to pull the cover forward. Step 2 Return to your originating procedure (NTP). Step 3 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-26 78-17704-02...
  • Page 27 Detach the cover from the pin of the hinge. Step 4 Remove the cover carefully from the left pin of the hinge. Step 5 Return to your originating procedure (NTP). Step 6 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-27 78-17704-02...
  • Page 28 Medium slot-head screwdriver Small slot-head screwdriver Prerequisite Procedures None Required/As Needed Required Onsite/Remote Onsite Security Level None Unscrew the five retaining screws that hold the cover in place (Figure 1-14). Step 1 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-28 78-17704-02...
  • Page 29 Lift the panel by the bottom to remove it from the shelf assembly. Step 4 Store the panel for later use. Attach the backplane cover(s) whenever electrical interface assemblies (EIAs) are not installed. Return to your originating procedure (NTP). Step 5 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-29 78-17704-02...
  • Page 30 Caution wristband cable into the ESD jack located on the lower-right outside edge of the shelf assembly. The ONS 15454 ETSI EFCA has 12 FMEC slots numbered sequentially from left to right beginning with Note Slot 18. Slots 18 to 22 and 25 to 29 provide electrical connections for the corresponding slots, so they are unnecessary in DWDM applications.
  • Page 31 Chapter 1 Install the Shelf and Common Control Cards NTP- G6 Install the MIC-A/P and MIC-T/C/P FMECs (ETSI Only) Figure 1-15 Installing FMECs on the ONS 15454 ETSI Mounting screws Guide rail F A N F A IL M IN Tighten the screws.
  • Page 32 Power cable (from fuse panel to MIC-A/P and to MIC-C/T/P), shipped • with the ONS 15454 ETSI Two-hole grounding lug, shipped with the ONS 15454 ETSI • Prerequisite Procedures NTP-G4 Open and Remove the FMEC Cover (ETSI Only), page 1-25...
  • Page 33 “DLP-G16 Connect the Office Ground to the ONS 15454 ANSI” task on page 1-35. Depending on your shelf, complete the “DLP-G17 Connect Office Power to the ONS 15454 ETSI” task Step 3 on page 1-37 or the “DLP-G18 Connect Office Power to the ONS 15454 ANSI” task on page 1-38.
  • Page 34 Chapter 1 Install the Shelf and Common Control Cards NTP- G15 Connect the Office Ground to the ONS 15454 ETSI DLP-G15 Connect the Office Ground to the ONS 15454 ETSI Purpose This task connects ground to the ONS 15454 ETSI shelf.
  • Page 35 Listed pressure terminal connectors such as ring and fork types; connectors must be suitable for #10 AWG copper conductors Prerequisite Procedures DLP-G13 Remove the Lower Backplane Cover, page 1-28 Required/As Needed Required Onsite/Remote Onsite Security Level None Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-35 78-17704-02...
  • Page 36 Ground Location on the Backplane Attach #6 AWG FRAME GROUND Attach the other end of the shelf ground cable to the bay. Step 3 Return to your originating procedure (NTP). Step 4 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-36 78-17704-02...
  • Page 37 Statement 1046 Caution Do not apply power to the ONS 15454 ETSI until you complete all installation steps and check the continuity of the –48 VDC battery and battery return. Not more than 2 m (7 ft) of the power supply cable should be exposed between the equipment and the Note fiber-storage tray.
  • Page 38 Chapter 1 Install the Shelf and Common Control Cards NTP- G18 Connect Office Power to the ONS 15454 ANSI If the system loses power or if both TCC2/TCC2P cards are reset, you must reset the ONS 15454 ETSI Note clock. After powering down, the date defaults to January 1, 1970, 00:04:15. To reset the clock, see the “NTP-G24 Set Up Name, Date, Time, and Contact Information”...
  • Page 39 Remove or loosen the #8 power terminal screws on the ONS 15454. To avoid confusion, label the cables Step 4 connected to the BAT1/RET1 (A) power terminals as 1 and the cables connected to the BAT2/RET2 (B) power terminals as 2. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-39 78-17704-02...
  • Page 40 Route the cables out below the power terminals using the plastic cable clamp, as shown in Figure 1-18 on page 1-39. Step 11 Connect the return cables to earth ground at power supply side. Step 12 Return to your originating procedure (NTP). Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-40 78-17704-02...
  • Page 41 Tools/Equipment Voltmeter Prerequisite ETSI: Procedures DLP-G15 Connect the Office Ground to the ONS 15454 ETSI, page 1-34 • DLP-G17 Connect Office Power to the ONS 15454 ETSI, page 1-37 • ANSI: DLP-G16 Connect the Office Ground to the ONS 15454 ANSI, page 1-35 •...
  • Page 42 Caution 700-23193-01 and 700-23194-01 can be used in this configuration. Error messages appear on the TCC2/TCC2P card, the fan-tray LED, and in Cisco Transport Controller Note (CTC) when the fan-tray assembly is removed from the shelf or when one fan is not working.
  • Page 43 ONS 15454 ANSI. • For the ONS 15454 ETSI shelf, press and hold the locks on the outer edges as you slide the fan-tray assembly into the shelf assembly. For the ONS 15454 shelf, press and hold the locks on the outer edges as you slide the fan-tray •...
  • Page 44 Chapter 1 Install the Shelf and Common Control Cards NTP- G8 Install the Fan-Tray Assembly Figure 1-19 Installing the Fan-Tray Assembly on the ONS 15454 ETSI F A N F A IL M IN Fan tray assembly Cisco ONS 15454 DWDM Procedure Guide, R8.0...
  • Page 45 “NTP-G9 Install the Alarm Expansion Panel (ANSI Only)” procedure on page 1-46. Otherwise, continue with the “NTP-G10 Attach Wires to Alarm, Timing, LAN, and Craft Pin Connections” procedure on page 1-49. Stop. You have completed this procedure. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-45 78-17704-02...
  • Page 46 Only the AEP alarm contacts can be used. Remove the two backplane screws. Replace the two screws with standoffs. Insert the longer standoff on Step 1 the left, and the shorter standoff on the right (Figure 1-21). Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-46 78-17704-02...
  • Page 47 Replace Backplane Screws with Standoffs Longer Shorter Step 2 Attach the remaining two standoffs on either side of the backplane (Figure 1-22). Position the AEP board over the standoffs. Step 3 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-47 78-17704-02...
  • Page 48 Table 1-2 shows AEP and AIC-I signals that each wire carries. Plug the other end of the AEP cable into AEP connector port. Figure 1-23 AEP Wire-Wrap Connections to Backplane Pins Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-48 78-17704-02...
  • Page 49 Onsite Security Level None Always use the supplied ESD wristband when working with a powered ONS 15454 ETSI. Plug the Caution wristband cable into the ESD jack located on the lower-right outside edge of the shelf assembly. Cisco ONS 15454 DWDM Procedure Guide, R8.0...
  • Page 50 Stop. You have completed this procedure. DLP-G20 Install Alarm Wires on the MIC-A/P (ETSI Only) Purpose This task installs alarm cables on the MIC-A/P on the ONS 15454 ETSI so that you can provision external (environmental) alarms and controls with the AIC-I card.
  • Page 51 Extra alarm 8 EXALM8+ Extra alarm 8 EXALM9– Extra alarm 9 EXALM9+ Extra alarm 9 EXALM10– Extra alarm 10 EXALM10+ Extra alarm 10 EXALM11– Extra alarm 11 EXALM11+ Extra alarm 11 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-51 78-17704-02...
  • Page 52 Connect the DB-62 connector to the ALARM IN/OUT connector on the MIC-A/P faceplate. Tighten the screws of the connector on the alarm cable. Step 4 Return to your originating procedure (NTP). Step 5 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-52 78-17704-02...
  • Page 53 Connect the other end of the cable to the external source of the timing signal according to Table 1-4. Step 3 Repeat Step 3 for each cable that is required. Step 4 Return to your originating procedure (NTP). Step 5 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-53 78-17704-02...
  • Page 54 NTP- G22 Install LAN Wires on the MIC-C/T/P (ETSI Only) DLP-G22 Install LAN Wires on the MIC-C/T/P (ETSI Only) Purpose This task installs the LAN wires on the ONS 15454 ETSI MIC-C/T/P. Tools/Equipment Standard CAT-5 Ethernet cable (straight-through for data terminating...
  • Page 55 — PNMSTX– orange — — 1. The Cisco ONS 15454 ETSI is DCE. Step 2 Return to your originating procedure (NTP). DLP-G23 Install Alarm Wires on the Backplane (ANSI Only) Purpose This task installs alarm wires on the backplane so that you can provision external (environmental) alarms and controls with the AIC-I card.
  • Page 56 Chapter 1 Install the Shelf and Common Control Cards NTP- G23 Install Alarm Wires on the Backplane (ANSI Only) Figure 1-24 Cisco ONS 15454 Backplane Pinouts (Release 3.4 or Later) BITS ENVIRONMENTAL ALARMS MODEM CRAFT LOCAL ALARMS IN/OUT FG10 FG11...
  • Page 57 Output to external device 1 ring BITS-2 Input from BITS device 2 BITS-2 Input from BITS device 2 ring BITS-2 Output to external device 2 BITS-2 Output to external device 2 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-57 78-17704-02...
  • Page 58 NTP- G25 Install LAN Wires on the Backplane (ANSI Only) For more detailed information about timing, refer to the “Timing” chapter in the Note Cisco ONS 15454 DWDM Reference Manual. To set up system timing, see the “NTP-G53 Set Up Timing” procedure on page 6-4.
  • Page 59 You cannot use the craft backplane pins and the EIA/TIA-232 port on the TCC2/TCC2P card Note simultaneously. Using a combination prevents access to the node or causes a loss in connectivity. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-59 78-17704-02...
  • Page 60 Onsite Security Level None Position the lower cover over the AEP. Make sure that the AEP AMP Champ connectors protrude Step 1 through the cutouts in the lower cover (Figure 1-26). Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-60 78-17704-02...
  • Page 61 Table 1-9 Alarm Input Pin Assignments AMP Champ Pin Signal Name AMP Champ Pin Signal Name ALARM_IN_1– ALARM_IN_2– ALARM_IN_3– ALARM_IN_4– ALARM_IN_5– ALARM_IN_6– ALARM_IN_7– ALARM_IN_8– ALARM_IN_9– ALARM_IN_10– ALARM_IN_11– ALARM_IN_12– ALARM_IN_13– ALARM_IN_14– ALARM_IN_15– ALARM_IN_16– Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-61 78-17704-02...
  • Page 62 — NO_1 NO_2 — COM_2 COM_3 — NO_3 NO_4 — COM_4 COM_5 — NO_5 NO_6 — COM_6 COM_7 — NO_7 NO_8 — COM_8 COM_9 — NO_9 NO_10 — COM_10 COM_11 — Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-62 78-17704-02...
  • Page 63 XREF=6 XREF=6 ALARM_IN_19- ALARM_IN_18- XREF=6 XREF=6 ALARM_IN_20- ALARM_IN_21- XREF=6 XREF=6 ALARM_IN_22- ALARM_IN_23- XREF=6 XREF=6 ALARM_IN_24- ALARM_IN_25- XREF=6 XREF=6 ALARM_IN_27- ALARM_IN_26- XREF=6 XREF=6 ALARM_IN_28- ALARM_IN_29- XREF=6 XREF=6 ALARM_IN_31- ALARM_IN_30- XREF=5 ALARM_IN_+ GND2 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-63 78-17704-02...
  • Page 64 Step 4 Stop. You have completed this procedure. NTP-G12 Install and Close the FMEC Cover (ETSI Only) Purpose This procedure installs and closes the ONS 15454 ETSI FMEC cover. Tools/Equipment #2 Phillips Dynamometric screwdriver Medium slot-head screwdriver Small slot-head screwdriver...
  • Page 65 The following procedure explains how to install the rear cover on an ONS 15454 ANSI shelf. Tools/Equipment #2 Phillips Dynamometric screwdriver Medium slot-head screwdriver Small slot-head screwdriver Prerequisite Procedures NTP-G5 Remove the Backplane Covers (ANSI Only), page 1-28 Required/As Needed Required Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-65 78-17704-02...
  • Page 66 Attach the cover by hanging it from the mounting screws on the back of the mounting brackets and Step 5 pulling it down until it fits snugly into place. Figure 1-31 shows rear cover installation. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-66 78-17704-02...
  • Page 67 Complete the “DLP-G351 Install the Y-Cable Module Tray” task on page 1-71 as needed. Step 5 Complete the “DLP-G30 Install the FlexLayer Shelf” task on page 1-71 as needed. Step 6 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-67 78-17704-02...

  • Page 68: Dlp-G27 Install The Dcu Shelf Assembly" Task

    Note plan calculated for your DWDM network with Cisco MetroPlanner, Release 8.0. Cisco MetroPlanner is a DWDM planning tool that is available from your Cisco account representative. Cisco MetroPlanner prepares a shelf plan for each network node and calculates the power and attenuation levels for the DWDM cards installed in the node. For information about Cisco MetroPlanner, refer to the Cisco MetroPlanner DWDM Operations Guide, Release 8.0.

  • Page 69: Dlp-G28 Install The Fiber Patch-Panel Tray" Task

    2 RUs.) Locate the RMU space specified in your site plan. Refer to the “Shelf Assembly Hardware” chapter in the Cisco ONS 15454 DWDM Reference Manual for common site configurations. Verify that the mounting brackets attached to the unit are correct for your rack size. Complete “DLP-G3...

  • Page 70: Dlp-G371 Install The Ethernet Adapter Panel" Task

    Step 1 600 mm x 300 mm rack. Locate the RMU space specified in your site plan. Refer to the “Shelf Assembly Hardware” chapter in the Cisco ONS 15454 DWDM Reference Manual for common ANSI and ETSI site configurations. Verify that the mounting brackets attached to the unit are correct for your rack size. Complete the Step 2 “DLP-G3 Reverse the Mounting Bracket to Fit a 19-inch (482.6-mm) Rack (ANSI Only)”...

  • Page 71: Dlp-G351 Install The Y-Cable Module Tray" Task

    Locate the RMU space specified in your site plan. Refer to the “Shelf Assembly Hardware” chapter in the Cisco ONS 15454 DWDM Reference Manual for common site configurations, and use the Cisco MetroPlanner Internal Connections Report to determine how many Y-cable modules you need to install.
  • Page 72 Table 1-11 lists the two-channel FlexLayer modules and part numbers. Refer to the “Shelf Assembly Hardware” chapter in the Cisco ONS 15454 DWDM Reference Manual for more information about FlexLayer modules. Table 1-11 ONS 15xxx Two-Channel Add/Drop FlexLayer Module Hardware Part...
  • Page 73 This task installs the Y-cable protection modules in the FlexLayer shelf assembly. Tools/Equipment #2 Phillips Dynamometric screwdriver Y-cable module(s): Multi-Mode Y-Cable Protection FlexModule(s) (15216-CS-MM-Y) or Single-Mode Y-Cable Protection FlexModule(s) (15216-CS-SM-Y), as appropriate Prerequisite Procedures None Required/As Needed As needed Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-73 78-17704-02...
  • Page 74 Security Level None Step 1 According to the Cisco MetroPlanner Internal Connections Report, determine which slots you will use to install the Y-cable modules. Step 2 Open the drawer of the tray by pushing inward on the latches located at the left and right front of the tray.
  • Page 75 ESD jack located on the lower-right outside to edge of the shelf assembly. If protective clips are installed on the backplane connectors of the cards, remove the clips before Note installing the cards. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-75 78-17704-02...
  • Page 76 4, you will be instructed to watch the LED activity (sequence) on the front of the Note TCC2/TCC2P card. This activity begins immediately after you close the latches in Step Step 3 Verify that the card is inserted correctly and close the latches/ejectors on the card. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-76 78-17704-02...
  • Page 77 If you are logged into CTC, the SFTWDOWN alarm might appear as many as two times while Note the TCC2 card initializes. The alarm should clear after the card completely boots. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-77 78-17704-02...
  • Page 78 TCC2/TCC2P card and install a replacement card. Refer to the release-specific software upgrade document to replace the software. To replace the TCC2/TCC2P card, refer to the Cisco ONS 15454 DWDM Troubleshooting Guide. Repeat Steps through for the redundant TCC2/TCC2P card.
  • Page 79 If the red FAIL LED is on continuously or the LEDs act erratically, the card is not installed properly. Remove the card and repeat Steps to 4. Return to your originating procedure (NTP). Step 5 Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-79 78-17704-02...
  • Page 80 The card can be installed in any slot from Slot 1 to 6 or 12 to 17. Cisco recommends that you install the MS-ISC-100T cards in Slot 6 and Slot 12.
  • Page 81 1-34). For more information on MS-ISC-100T card port assignments, refer to the “Common Control Cards” chapter in the Cisco ONS 15454 DWDM Reference Manual. Using the 5.9 in. (0.15 m) CAT-5 LAN cable, plug one connector into the NC port of the MS-ISC-100T card located on the left side of the node controller shelf (Slots 1 to 6) and plug the other connector into the front panel (RJ-45 connector) of the TCC2/TCC2P card in Slot 7.
  • Page 82 Use the same SSC port number (2 through 8) on the left and right EAP for each subtending shelf. Stop. You have completed this procedure. Cisco ONS 15454 DWDM Procedure Guide, R8.0 1-82 78-17704-02...
  • Page 83 Use this procedure to connect a multishelf node and subtending shelves to two Cisco Catalyst 2950s and configure the Cisco Catalyst 2950. Tools/Equipment Two Cisco Catalyst 2950 switches must be installed in same rack as the node controller shelf; refer to the Cisco Catalyst 2950 product documentation for installation instructions.
  • Page 84 LAN traffic. Cisco Catalyst 2950 ports not used by the multishelf configuration cannot be used for any other task. Step 1 At the Cisco IOS command line interface (CLI) for the Catalyst switch, enter the following spanning tree commands: Switch(config)#spanning-tree mode rapid-pvst...
