Cisco 605 Quick Start

Quick Start
C 605
F O R I S C O
The Cisco 605 Personal PCI ADSL Modem is PCI adapter for use in
PCI-compliant personal computers. Designed for easy installation, the
modem slides into any PCI slot.
Related Information
This Quick Start provides instructions for installing the Cisco 605
hardware only. For information on installing the Cisco 605 software,
refer to the Cisco 605 Personal PCI ADSL Modem User's Guide.
Parts List
• Cisco 605 Personal PCI ADSL modem
• Cisco 605 CD-ROM
• Cisco 605 Personal PCI ADSL Modem User's Manual
• ADSL cable (RJ-11 phone cable)
Optionally, your shipment may include in-line EZ-DSL Microfilters,
wall-mount microfilters, or filter cables.
Hardware and Software Requirements
The following hardware and software requirements are necessary to
configure and use the Cisco 605:
• A Pentium, PentiumPro, or compatible processor with an available
bus-mastering PCI expansion slot
• 10BaseT or 10/100BaseT Ethernet adapter
• CD-ROM drive
• Windows 95, Windows 98, or Windows NT 4.0. All three platforms
should have Dial-Up Networking (DUN) installed and Windows NT
4.0 should have the Remote Access Service (RAS) installed.
• Windows 95 requires the Dial-Up Networking update Version 1.2.
Installing the Cisco 605
Before Installation
Install the executable from the Cisco 605 CD-ROM before
checksw.exe
installing the card. Also, determine the following information.
• Your operating system: Windows NT 4.0, Windows 95, or
Windows 98.
• Driver software you want to install: PPP or 1483
• If you are using 1483 driver software, the MAC address of the
Cisco 605 (located on a sticker on the Cisco 605 unit)
• Your configuration: EZ-DSL or POTS Splitter.
• Number of virtual connections the Cisco 605 will use: one, two, or
three
• Virtual circuit number
If you have questions about any of the preceding information, contact your
Internet service provider (ISP).
Unpacking the Box
Unpack the shipping carton and ensure that parts listed in the "Parts List"
section of this document are included.
Examining the Cisco 605
After you open the box, unpack and examine the Cisco 605.
Caution
Static discharge or electricity can severely damage
the Cisco 605. Before you handle the Cisco 605 or any PC boards
inside your PC, take standard precautions, such as touching the
metal covering on the PC box, to ground yourself.
