- Page 1 Cutter Kit For PX4ie, PX6ie Installation Guide PX4-6IE-CUTR-IG-1 Rev A 01/20...
- Page 2 Introduction The PX4ie and PX6ie printers can easily be fitted with an optional cutter, provided the printer is not already fitted with a label-taken sensor. The cutters are almost identical with exception for the width. The cutter unit is fitted by replacing the front door and the printer hinges, and is connected by a single cable to the DIN-connector on the printer’s front.
- Page 3 Contents The cutter kit consists the following, • Cutter unit • Two hinges with torx wrench Installing the Cutter Kit Follow the procedure to physically install the cutter. Note: This procedure applies to both the PX4ie and PX6ie Printers. For simplicity, the PX4ie Printer is depicted in the illustrations.
- Page 4 Remove the existing two hinges held by four #T10 Torx screw at the bottom of the printer. Replace the hinges with the new ones that came with the cutter unit using the same four #T10 Torx screw. Fit the cutter unit to the vacant hinges. Make sure that the locking plate snaps into the groove of the right-hand hinge and that the angled plate at the bottom of the cutter is inserted under the printer’s bottom plate.
- Page 5 Fit the cable from the cutter unit into the DIN connector on the printer’s front. Press sideways Tilt the cutter unit upwards until it locks into place. If the cutter does not lock properly, the hinges of the cutter unit may need to be adjusted using a #T10 Torx screwdriver.
- Page 6 Cutter for PX4ie Printer Cutter Installed PX4ie Printer PX4ie and PX6ie Cutter Kit Installation Guide...
- Page 7 Cutter for PX6ie Printer Cutter Installed PX6ie Printer PX4ie and PX6ie Cutter Kit Installation Guide...
-
Page 8: Controlling The Cutter
Controlling the Cutter The cutter can be controlled using the printer command languages and the supported printer command languages are, • Fingerprint • Direct Protocol (DP) • Intermec Printer Language (IPL) • Datamax Printer Language (DPL) • Zebra Simulator (ZSim) To learn how the cutter is controlled using the printer languages, refer to the respective command reference manual. -
Page 9: Troubleshooting
Troubleshooting Use this table to understand and troubleshoot some common errors you may receive and how to fix them. Error, Probable cause, and Solution Error Alert Probable Cause Solution Error 1701 A cut has been performed but Clean the shears “Cutter Jammed”... -
Page 10: Limited Warranty
For patent information, see www.hsmpats.com. Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made.
