User's Manual
KVM CONSOLE EXTENDER
Model #: B013-000
NOTE: Follow these installation and operating procedures to ensure correct performance and to prevent
damage to this unit or to its connected devices.
Copyright © 2000 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners.
Technical specifications are subject to change without notice.

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite B013-000

Summary of Contents for Tripp Lite B013-000

  • Page 1 NOTE: Follow these installation and operating procedures to ensure correct performance and to prevent damage to this unit or to its connected devices. Copyright © 2000 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners. Technical specifications are subject to change without notice.
  • Page 2 Category 5 cabling makes for a much neater, more convenient, more reliable data transfer connection. Setup is as easy as can be - simply connect the PC system box and local console to the Local B013-000 Module; run the STP cable to the Remote B013-000 Module (up to 150 meters away);...

  • Page 3: System Requirements

    Features Uses Inexpensive, Reliable, Category 5 STP Ethernet Cable to Connect the Local and Remote Units Dual Console Operation - Control Your System From Both the Local and Remote PS/2 Keyboard, Mouse, and Monitor Consoles Push Button Selection of the Active Console High Resolution Video - Up To 1024 x 768 @ 150 m (max.) Supports VGA, SVGA, and Multisync Monitors Local Monitor Supports DDC;...
  • Page 4 Custom KVM Cable that is provided with this package. It is not possible to use standard extender cables to link computers with AT type keyboard and mouse ports to the B013-000 Local. For those computers, using CS Custom KVM Cables must be used.
  • Page 5 Components The Local Unit (B013-000 Local) Front View: 1. Operating Mode Selection Switch Pressing this button cycles you through the operating mode choices: Local - only the local console can control the system(s); Auto - both consoles can control the system(s)).
  • Page 6 The extension cable that connects to the computer’s Mouse port plugs into this connector. Note: If you are combining the B013-000 with a KVM switch, the extension cable connects back to the respective ports on the Console section of the switch.
  • Page 7 The Remote Unit (B013-000 Remote) Front View 1. LEDs The Remote Unit has two LEDs (Power and On Line) to indicate the operating status of the Local and Remote units (see p. 8, for details). 2. Mouse Port The remote PS/2 mouse plugs into this connector.

  • Page 8: Installation

    Console side of the Local Unit (B013-000 Local). 3. Plug the appropriate connectors on the KVM extension cable supplied with this unit into the CPU side of the B013-000 Local. Each connector is marked with an appropriate icon to indicate which it is.

  • Page 9: Operation

    Operation The Local and Remote Units each have two LEDs to indicate their operating status, as shown in the tables, below: B013-000 Local (Local Unit): Local Local Lights to indicate that the local console is active (the Remote LED is out).

  • Page 10: Troubleshooting

    Appendix Troubleshooting Symptom No Video Make sure that all cables are securely plugged into their sockets. TP Wiring Diagram PAIR 3 PAIR 2 PAIR 1 1 2 3 4 5 6 Bl W-Bl JACK POSITIONS T568B AT&T 258A TP Pin Assignments Action PAIR 4 G W-Br Br...

  • Page 11: Specifications

    Dimensions (L x W x H) * DDC, DDC2, and DDC2B support is for the Local monitor only. B013-000 Local 2 x 6 pin mini-DIN female 6 pin mini-DIN female 2 x 6 pin mini-DIN female 6 pin mini-DIN female...

  • Page 12: Preventing Radio & Tv Interference

    1-YEAR LIMITED WARRANTY TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
  • Page 13 - 13 -...
  • Page 14 - 14 -...
  • Page 15 - 15 -...
  • Page 16 PAPE-1142-203 - 16 -...
