Tripp Lite PDU Power Strips Owner's Manual

IMPORTANT SAFETY INSTRUCTIONS. This manual contains information concerning the proper
installation and use of Tripp Lite's PDU Power Strips. SAVE THESE INSTRUCTIONS.
Do not connect your power strip to an ungrounded outlet. Do not use it with extension cords or
adapters that eliminate its connection to ground. Your power strip is designed for indoor use only.
Install it away from heat emitting devices such as radiators and heat registers. Do not install where
excessive moisture or other conductive contaminants are present. Never install electrical wiring during
a lightning storm.
The power requirement of each device connected to an outlet of your power strip must not exceed the Outlet Power
Rating of your power strip.The total power requirements of all devices connected to your power strip must not exceed
the Maximum Load Rating of your power strip.
Installation
0U Rackmount Installation
1. Install Mounting Ears: Attach the mounting ears (A) to the unit as shown. Use only the man-
ufacturer-supplied screws or their equivalent (#6-32, ¼" flat head) to attach the mounting ears.
2. Mount Unit on Outside of Rack Rails: Put four user-supplied screws (B) or similar mounting
hardware through the unit's mounting ears (A) and into the side of the rack as shown. The
user must determine the fitness of the user-supplied mounting hardware to support the unit
before mounting.
Wallmount/Under Counter Installation
Install mounting ears as described above. Then put four user-supplied screws or similar mounting
hardware through the mounting ears and into the mounting surface. The user must determine the
fitness of the user-supplied mounting hardware to support the unit before mounting.
Features
Circuit Breaker(s)
If the current draw of the equipment connected to
your power strip exceeds your model's Maximum
Load Rating for longer than a few seconds, a cir-
cuit breaker will trip to prevent any possible dam-
age. When a circuit breaker trips, its plunger will
pop up. Remove excess equipment and allow the
breaker to cool one minute before depressing its
plunger to reset the breaker. Caution (PDU2430
model only): If you depress the circuit breaker
plunger during normal operation of your PDU,
power will be interrupted to the receptacles and
connected equipment will not be protected.

Limited Lifetime Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for its lifetime. If the product should prove defective in
material or workmanship within that period, Seller will repair or replace the product, at its sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the product
(with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th Street, Chicago, IL 60609. Seller will pay return shipping charges. Call Tripp Lite at (773) 869-1234 before sending any equip-
ment back for repair.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES
OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES
OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND
CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may have other rights which vary from jurisdiction to jurisdiction).
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to great vari-
ation, the manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any specific application.
Policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
Warranty Registration
Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
This product designed and engineered in the USA.
Regulatory Compliance Identification Numbers
For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series number.
The series number can be found on the product nameplate label, along with all required approval markings and information. When requesting
compliance information for this product, always refer to the series number. The series number should not be confused with the marking name
or model number of the product.
1111 W. 35th Street Chicago, IL 60609 • Customer Support: (773) 869-1234 • www.tripplite.com • Copyright © 2004 Tripp Lite. All rights reserved.
Owner's Manual
PDU Power Strips
Grounding Lug
Use this screw (located by the power strip's receptacles)
to connect your power strip to ground.
0U Rackmount Installation
