- Page 1 INSTRUCTION MANUAL Cordless Rivet Gun DRV150 DRV250 Read before use.
-
Page 2: Specifications
Vibration Intended use The vibration total value (tri-axial vector sum) deter- mined according to EN62841-1: The tool is intended for installing blind rivet. Model DRV150 Noise Work mode: Installing blind rivet Vibration emission (a ) : 2.5 m/s or less Uncertainty (K) : 1.5 m/s... -
Page 3: Ec Declaration Of Conformity
Do not abuse the cord. Never use the cord for WARNING: The vibration emission during carrying, pulling or unplugging the power tool. actual use of the power tool can differ from the Keep cord away from heat, oil, sharp edges declared value(s) depending on the ways in which or moving parts. - Page 4 Use power tools only with specifically desig- nated battery packs. Use of any other battery packs may create a risk of injury and fire. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another.
-
Page 5: Functional Description
If not, causing fires, personal injury and damage. It will it may accidentally fall out of the tool, causing injury to also void the Makita warranty for the Makita tool and you or someone around you. charger. -
Page 6: Overheat Protection
Overheat protection Indicating the remaining battery capacity When the tool or battery is overheated, the tool stops automatically and the lamp blinks. In this case, let the tool and battery cool before turning the tool on again. Only for battery cartridges with the indicator Overdischarge protection When the battery capacity is not enough, the tool stops automatically. - Page 7 Pull the switch trigger to light up the lamp. The lamp Loosen the jaw case with a wrench while holding keeps on lighting while the switch trigger is being pulled. the joint with another wrench. The lamp goes out approximately 10 seconds after releasing the switch trigger.
-
Page 8: Operation
Installing or removing the mandrel container NOTICE: Be sure to install the mandrel container to the tool before operating the tool. If the mandrel container is not installed to the tool, the tool will not operate. To remove the mandrel container, rotate it counter clock- wise. -
Page 9: Maintenance
Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. 9 ENGLISH... - Page 10 Install the jaws to the jaw case. Cleaning the jaws and jaw case Interval of cleaning: Every 3,000 installations of rivet If the dust is accumulated, it deteriorates the movement of jaws and may accelerate wear of jaws and jaw case. To clean the jaws and jaw case, follow the steps below.
-
Page 11: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885691-222 www.makita.com 20190701...
