Grizzly T10281 Instructions

Introduction
the Model t10281 welding cart is designed to
hold a small welder, welding tools, accessories,
consumables, and a gas bottle. the sturdy cast-
ers and wheels make moving the welding equip-
ment to the job site easy and convenient.
figure 1. Model t10281 Welding Cart.
Specifications
Weight Capacity ...................................... 110 lbs.
Maximum gas Bottle dimensions .. 7
Maximum Welder Footprint ................12
overall dimensions ....31
Weight .......................................................25 lbs.
If you need help with your new welding cart, call
our Tech Support at: (570) 546-9663.
WARNING: NO PORTION Of ThIS MANUAL MAy bE REPRODUCED IN ANy ShAPE
OR fORM WIThOUT ThE WRITTEN APPROvAL Of GRIzzLy INDUSTRIAL, INC.
⁄ "d x 19"h
1
2
⁄ " x 19"
1
2
⁄ "l x 16 ⁄ "W x 19 ⁄
7 1 5
8 2 8
Copyright © AUgUSt, 2010 By grizzly indUStriAl, inC.
#tS13128 printed in ChinA
MODEL T10281
ANGLED TOP
WELDING CART
Inventory
refer to the parts diagram and list on Page 3 to
inventory the contents of the box.
if any nonproprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
To reduce the risk of serious personal inju-
ry when using this welding cart:
• Do not allow children to play with, on, or
near the cart.
• Do not exceed the cart weight capacity
of 110 lbs.
• Make sure the gas bottle is firmly secured
to the cart before attempting to use it or
move the cart.
• Inspect the cart for worn or damaged
parts before using.
• Do not use the cart as a ground for the
welder.
• Always read, understand, and follow the
"h
safety instructions included in the weld-
ers owner's manual.
• Use this cart only for the designed
purpose. Do not modify the cart in any
way.
