- Page 1 Projection Television Instructions for use 9P5511C1 9P5514C1...
- Page 2 And we’ll do everything in our power to keep you happy with your purchase for many years to come. As a member of the PHILIPS MAGNAVOX “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.
- Page 3 SAFETY INSTRUCTIONS - Read before operating equipment This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. Read Instructions - All the safety and operating instructions should be read before the appliance is operated.
-
Page 4: Table Of Contents
Because of continuous product improvements, the informa- tion mentioned in the documents accompanying your product are subject to change without notice. Copyright © 1999 Philips Consumer Electronics Company. All rights reserved. General Information UP AND UICK UIDE... -
Page 5: On-Screen Features
First Time Set Up - automatically sets the TV for local channels and the correct picture signal (antenna or cable). See your Set-up and Quick Use Guide for details. Infrared Remote Control - operates your TV set and all on screen feature controls. Standard TV broadcast (VHF/UHF) or Cable TV (CATV) channel capability. -
Page 6: Picture Menu
ICTURE COLOR, BRIGHTNESS, SHARPNESS, TINT, PICTURE o adjust your TV color and picture controls, select a TV channel and follow the steps shown below: BEGIN Select BRIGHTNESS, PIC- TURE, COLOR, TINT, or SHARPNESS picture control. With the PICTURE MENU on screen, move the RED highlight with the MENU buttons. - Page 7 ICTURE CLEARVIEW learview is a sharpness feature which smoothes out back- ground snow (or picture noise) without losing picture image detail or crispness. BEGIN Select CLEARVIEW control. With the PICTURE MENU on screen, move the RED highlight with the MENU buttons.
- Page 8 ICTURE RED/BLUE CONVERGENCE onvergence is the correct lin- ing up of the red and blue light paths on the TV screen. NOTE: If no color fringing (see Smart Help) shows, then no Convergence adjustments are nec- essary for your TV. BEGIN Select CONVERGENCE con- trol.
- Page 9 EATURE PICTURE SOURCE he picture for the TV can come through either the ANTENNA plug or the AUDIO/VIDEO INput jacks (on the rear of the TV). The Picture Source control simply tells the TV which one of these picture sources it is to show on the TV screen.
- Page 10 EATURE CLOSED CAPTION losed Captioning (CC) allows you to read the voice content of television programs on the TV screen. Designed to help the hearing impaired this feature uses on-screen "text boxes" to show dialogue and conversations while the TV program is in progress.
- Page 11 EATURE CABLE TUNING OTE: If you went through First Time Setup (in your Quick Use Guide), this task has already been completed for you. You need to make sure the TV is set to pick up either Cable TV or Antenna signals.
- Page 12 EATURE CHANNEL MEMORY AUTO-PROGRAMMING OTE: If you went through First Time Setup (in your Quick Use Guide), this task has already been completed for you. Your TV can automatically set itself for local area (or Cable TV) chan- nels. This makes it easy for you to select only the TV stations in your area when the CHANNEL but-...
- Page 13 EATURE ADD/DELETE CHANNELS uto-Programming (see previous page) adds all the channels it can find (on your Antenna or Cable TV system) into the TV's memory. Add/Delete Channels makes it easy for you to add other channels, or drop unwanted channels, from the list of channels in the TV's memory.
- Page 14 EATURE SET CLOCK OTE: If you went through First Time Setup (in your Quick Use Guide), this task has already been completed for you. Your TV comes with an on-screen clock. During normal operation the clock appears on the screen with every channel change (and when the STATUS button is pressed).
- Page 15 EATURE SET ALARM TIMER ust like an alarm clock you can set the TV to turn itself on at the same time everyday. BEGIN Select SET ALARM TIMER control. With FEATURES MENU (2 of 3) on screen, move the RED highlight with the MENU buttons.
- Page 16 EATURE PARENTAL CONTROL SETUP CODE NUMBER arental Control allows parents to block out, or "censor", any channels they think children should not watch. A channel placed under Parental Control cannot be viewed until a correct access code is used to unlock the channel for viewing.
- Page 17 EATURE PARENTAL CONTROL CHANNEL BLOCKING fter you Setup your personal Parental Access Code number (see previous page), you are now ready to select the channels you want to block out or censor from viewing. BEGIN Select the CHANNEL BLOCKING control. With FEATURES MENU (3 of 3) on screen, move the RED highlight with the MENU...
- Page 18 EATURE PARENTAL CONTROL CONTENT ADVISORY nother new area available to parents for the censoring of program material is through the TV Guidelines and Movie Ratings system. Program Content Advisory data will soon be contained within the broadcast signals of received TV programs.
-
Page 19: Content Advisory Movie Ratings
EATURE CONTENT ADVISORY MOVIE RATINGS ovie Ratings set viewing access levels for TV pro- gramming according to current Motion Picture Association of America (MPAA) ratings. These ratings are similar to the cate- gories used with the rated movies appearing in cinema theaters and with video rental material. -
Page 20: Parental Guidelines
EATURE CONTENT ADVISORY PARENTAL GUIDELINES arental Guidelines can be even more defined and specific in the degree and extent of materi- al parents may allow for TV pro- gram viewing. Sub-settings for Language, Violence, and other blocking factors can be manually switched On or Off for use within the major Parental Guideline cate- gories (TV-Y7, TV-PG, etc.). -
Page 21: Blocking Options/Review Settings
EATURE CONTENT ADVISORY BLOCKING OPTIONS he Content Advisory system also has “Blocking Option”controls which can be used to deny viewing access for channel programs and movies even when they are “unrated”, or contain “no rating” information as broadcasted. BEGIN Select the BLOCKING OPTIONS Menu control. - Page 22 EATURE CHANNEL DISPLAY ith the Channel Display con- trol you can change the size and location of the on screen channel and clock information. BEGIN Select CHANNEL DISPLAY control. With FEATURES MENU (2 of 3) on screen, move the RED high- light with the MENU buttons.
- Page 23 OUND BASS, TREBLE, BALANCE our TV also has individual sound adjustment controls. The BASS (low frequency), TREBLE (high frequency) , and Speaker BALANCE may all be used to adjust the sound playback of TV programs. BEGIN Select BASS, or TREBLE, or BALANCE sound control.
-
Page 24: Sound Menu
STEREO our TV is able to receive broadcast stereo TV programs. The TV is equipped with an ampli- fier and twin speaker system through which the stereo sound can be heard. Note: STEREO will appear on the TV’s channel status screen to indi- cate when a stereo broadcast sig- nal is available and received. -
Page 25: Controls
OUND INCREDIBLE STEREO he Incredible Stereo control can be used to add greater depth and dimension to both monaural (MONO) and STEREO TV sound. BEGIN Select INCREDIBLE STEREO control. With the SOUND MENU on the screen, move the RED highlight with the MENU buttons. - Page 26 OUND TV SPEAKERS ould you like to hear TV pro- grams through your audio hi- fi system? The TV's Variable Audio Output jacks and TV Speaker On/Off control work together to offer you this TV sound option. BEGIN Connect the R(ight) and L(eft) VARIABLE AUDIO OUT jacks on the TV to the R and L Audio Input jacks on your amplifier or...
-
Page 27: Variable Audio Output Control
OUND SURROUND SOUND y adding optional external speakers to the TV's sound sys- tem, you can create the feeling of reflected sound that surrounds you at a movie theater or concert hall. BEGIN Connect both external speak- ers to the speaker wire terminals on the TV. - Page 28 SING THE AUX 1 VIDEO INPUTS he TV's Audio/Video Input jacks are for direct picture and sound connections between the TV and a VCR (or Video Disc Player, etc.) that has Audio/Video Output jacks. To view the playback of a VCR tape by using the Audio/Video Input jacks on the TV: BEGIN...
- Page 29 SING THE AUX1 - S-VIDEO INPUTS he S(uper)-Video connection on the rear of the TV can give you better picture detail and clarity, for the playback of S-VHS VCR tapes or Video Discs, than the normal anten- na picture connections. Note: The VCR (or Video Disc Player) must have a S-VIDEO OUT(put) jack in order for you to...
- Page 30 SING THE COMPONENT VIDEO INPUTS omponent Video Inputs pro- vide for the highest possible color and picture resolution in the playback of digital signal source material such as with DVD play- ers. The color difference signals ) and the luminance (Y) sig- nal are connected and received separately which permits for improved color bandwidth infor-...
-
Page 31: Output Jacks
SING THE AUDIO/VIDEO OUTPUTS he Audio/Video Output jacks on the TV can be used to record TV programs on VCRs which have Audio/Video Input jacks. To record TV programs by using the Audio/Video jacks on the TV: BEGIN Connect the VIDEO OUT jack from the TV to the VIDEO IN jack on the VCR. -
Page 32: Tv Help Menu
he on screen HELP menu offers both Operating Tips and a list of Glossary definitions for different features on your TV. These items are given to provide you with more information and details on a select group of feature operations. BEGIN Select "HELP"... - Page 33 lease make these simple checks before calling for ser- vice. These tips can save you time and money since charges for TV installation and adjustment of customer controls are not cov- ered under your warranty. No Power No Picture No Sound Remote Does Not Work TV Displays Wrong...
-
Page 34: Glossary Of Tv Terms
Audio/Video Inputs * Located on the rear of the TV these connec- tors (RCA phono type plug) are used for the input of audio and video signals. Designed for use with VCRs (or other accessories) in order to receive higher picture resolution and offer sound connec- tion options. -
Page 35: Index
Accessories/Optional ...26-27, 28-31*Q/U-1 Adapter Connector ...28-31, *Q/U-1 Add/Delete Channels ...12-13, *Q/U-2 Audio Controls ...23-27 Audio/Video Input ...28-30, *Q/U-2 Automatic Programming ...12, *Q/U-2 Battery Installation ...*Q/U-3 Cable TV Settings...11, *Q/U-1, 2 Channel/Time Display...14, 22, *Q/U-3 Channel Memory...12-13, *Q/U-2 Channel/Time Reminder...14 Clock Setting ...14 Clock Timer ...15 Closed Captioning ...10 Color Controls ...6,*Q/U-4... - Page 36 Indicates In-Home/Carry-In Service NOTE: If you reside in one of our Philips Factory Service Branch areas (see directory on back), you can contact the nearest Service Branch to obtain efficient and expedient repair for your product. If your product is In-Warranty, you should have proof-of-purchase to ensure No Charge Service.
- Page 37 RÉCEPTION DE PRODUITS À RÉPARER À TRAVERS LE PAYS: CONTACTER LE CENTRE DE SERVICE AUX CONSOMMATEURS LE PLUS PROCHE POUR SAVOIR L’EMPLACEMENT DE CES DÉPOTS DANS CÓMO OBTENER UN SERVICIO OPORTUNO Y EFICIENTE POR CORREO, EN CASA O EN PERSONA PARA SU PRODUCTO A TRAVÉS DE UN CENTRO PHILIPS DE SERVICIO. MAS DE 600 SITIOS POR...
-
Page 40: Limited Warranty
Philips Consumer Electronics Company. In coun- tries where Philips Consumer Electronics Company does not distribute the product, the local Philips service organization will attempt to pro- vide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).
