Able Desk ADC-CH1-101 Assembly Instructions Manual

Desk chair

Download this manual

No. ADC – C H1 – 101

Desk chair

Assembly instructions

Page 1 No. ADC – C H1 – 101 Desk chair Assembly instructions...
Page 2 Cautions and use Parts key Assembly Specs Functions...
Page 3 This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury. Important If any parts are missing or faulty, contact ABLE Desk Co for assistance. Atención Lea todo el manual de instrucciones antes de comenzar la instalación y ensamble de la unidad.
Page 4 Part G (2x) Back set Part A (1x) Back rest Part H (2x) Arm rest lever Part B (1x) Part I (2x) Center bracket M8x38 Part C (1x) Part J (1x) Seating Gas lift Part D (3x) Part K (1x) M8x35 Base Part E (3x)
Page 5 Step 1 : Attach back rest to seating Par t A (1x) Par t B (1x) Par t C (1x) Par t D (3x) Par t E (3x) Par t M (1x) Step 2 : Attach arm rests and levers Par t F (1x set) Par t G (2x) Par t H (2x)
Page 6 Step 3 : Connect seat to gas lift, base and insert casters Par t J (1x) Par t K (2x) Par t L (5x) Specs Dimensions 24.2” x 24.2” x 41.3” Height range 41.3” to 44.5” Weight 40 lbs Weight capacity 330 lbs Maintenance Check that the bracket is secure and safe to use at...
Page 7 Seating functions Tension control Arm rest functions...
Page 8 For assistance, visit abledesk.co/help or email support@abledesk.co...
