Ii-5-5 Radius/Tacacs; Ii-5-5-1 External Radius - Draytek Vigor3910 Series User Manual

I I - 5 - 5 R
I I - 5 - 5 R
Remote Authentication Dial-In User Service (RADIUS) is a security authentication
client/server protocol that supports authentication, authorization, and accounting, which is
widely used in enterprise networks. It is the most common authentication method to manage
the clients' access to the wireless network, the Internet and the VPN.
The router supports external TACACS+ and internal and external RADIUS servers for user
authentication. To configure TACACS+ or RADIUS servers, from the Main Menu select
Applications >> RADIUS/TACACS+.
I I - 5 - 5 - 1 E
I I - 5 - 5 - 1 E
Vigor Router supports the RADIUS client function. The built-in RADIUS client feature allows
the router to authenticate the remote dial-in VPN users, the wireless connections through
802.1X and the access to the Internet.
When it operates as the RADIUS client, Vigor Router needs to work with an External Radius
server, and the External RADIUS Server setting should be configured here.
Item
RADIUS Server Status Log
Enable
Comment
Primary Server
Secondary Server
Click any index number to open the following page. It is used to configure settings for
external RADIUS server. Then users of the Vigor router will be authenticated by this server for
the network application.
108
A D I U S / T A C A C S
A D I U S / T A C A C S
x t e r n a l R A D I U S
x t e r n a l R A D I U S
+
+
Description
Display the record of current status of RADIUS server.
Select to enable the profile.
Displays the comment of the profile.
Displays the IP address of the primary server.
Display the IP address of the secondary server.
Vigor3910 Series User's Guide
