Panasonic TH-L24XM6Z Service Manual

Chassis: km21
Hide thumbs Also See for TH-L24XM6Z:
Table of Contents

Advertisement

Quick Links

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.1.1. Leakage Current Cold Check---------------------- 3
1.) --------------------------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
2.2. About lead free solder (PbF)---------------------------- 5
3 Service Navigation ----------------------------------------------- 6
3.1. Service Hint ------------------------------------------------- 6
4 Specifications ----------------------------------------------------- 7
5 Service Mode ------------------------------------------------------ 8
5.1. How to enter into Service Mode ----------------------- 8
5.1.1. Contents of adjustment mode --------------------- 8
5.1.2. How to exit---------------------------------------------- 8
5.1.3. Display of SOS History ------------------------------ 9
5.1.4. POWER ON TIME/COUNT ------------------------ 9
5.1.5. Exit-------------------------------------------------------- 9
5.1.6. Self Check (Device) ---------------------------------10
Model No.
Chassis:
Destination:
PAGE
5.1.7. Hotel Mode Adjustment ---------------------------- 10
5.1.8. Hotel Mode-------------------------------------------- 10
6 Troubleshooting Guide --------------------------------------- 11
6.1. Check of the IIC bus lines------------------------------ 11
6.1.1. How to access --------------------------------------- 11
6.1.2. Exit ------------------------------------------------------ 11
6.1.3. Screen Display --------------------------------------- 11
6.2. Power LED Blinking timing chart --------------------- 12
6.3. No Power--------------------------------------------------- 12
7.1. LVDS and LED Assembly ----------------------------- 13
7.3. Install Metal Chassis Frame--------------------------- 15
7.4. Small Part & Tightening Screw ----------------------- 16
7.5. Pedestal Assembly -------------------------------------- 18
8 Measurements and Adjustments -------------------------- 19
8.1. Voltage chart of A-board ------------------------------- 19
8.2. Voltage chart of P-board ------------------------------- 19
9 Block Diagram --------------------------------------------------- 20
9.1. Main Block Diagram ------------------------------------- 20
ORDER NO. MTV1301127CE
TH-L24XM6Z
KM21
NEW ZEALAND
© Panasonic Corporation 2013.
LED TV
PAGE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TH-L24XM6Z

Summary of Contents for Panasonic TH-L24XM6Z

  • Page 1: Table Of Contents

    8.1. Voltage chart of A-board ------------------------------- 19 5.1.4. POWER ON TIME/COUNT ------------------------ 9 8.2. Voltage chart of P-board ------------------------------- 19 9 Block Diagram --------------------------------------------------- 20 5.1.5. Exit-------------------------------------------------------- 9 5.1.6. Self Check (Device) ---------------------------------10 9.1. Main Block Diagram ------------------------------------- 20 © Panasonic Corporation 2013.
  • Page 2 TH-L24XM6Z 10 Wiring Connection Diagram --------------------------------- 21 10.1. Wire Dressing --------------------------------------------- 21 11 Schematic Diagram--------------------------------------------- 22 12 Printed Circuit Board ------------------------------------------ 44 13 Exploded View and Replacement Parts List ----------- 49 13.1. Exploded View and Mechanical Replacement Parts List --------------------------------------------------- 49...

  • Page 3: Safety Precautions

    TH-L24XM6Z 1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 4: Warning

    TH-L24XM6Z 2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components.

  • Page 5: About Lead Free Solder (Pbf)

    TH-L24XM6Z 2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).

  • Page 6: Service Navigation

    TH-L24XM6Z 3 Service Navigation 3.1. Service Hint Board Name Main Device Remarks A BOARD TUN, OFDM, ADV, LD4, STBY EEP Repairable P BOARD Power Supply Repairable K BOARD LED/RM/CATS Repairable...

  • Page 7: Specifications

    TH-L24XM6Z 4 Specifications Power Rating AC 220 - 240 V, 50/60 Hz 0.4 A Normal (Home) mode 26 W Standby power consumption 0.2 W Display panel Panel TFT LCD Module with LED Backlight Visible screen size (diagonal) 61 cm (24 inches) 1,049,088 (1,366 (W) ×...

  • Page 8: Service Mode

    TH-L24XM6Z 5 Service Mode 5.1. How to enter into Service Mode While pressing [VOLUME ( - )] button of the main unit, press [INFO] button of the remote control three times within 2 seconds. Contents of adjustment mode 5.1.1. • Value is shown as a hexadecimal number.

  • Page 9: Display Of Sos History

    TH-L24XM6Z 5.1.3. Display of SOS History SOS History (Number of LED blinking) indication. From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment. This indication except 2nd and 1st occurrence after shipment will be cleared by [Self-check indication and forced to factory shipment setting].

  • Page 10: Self Check (Device)

    TH-L24XM6Z 5.1.6. Self Check (Device) 1. Press the ‘MENU’ button (on the remote control) and the ‘VOL DOWN’ button on the LCD panel. 2. Press ON/OFF button on the panel to Exit. NOTE: After self check, the following process need to follow.

  • Page 11: Troubleshooting Guide

    TH-L24XM6Z 6 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 6.1. Check of the IIC bus lines 6.1.1. How to access Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.

  • Page 12: Power Led Blinking Timing Chart

    TH-L24XM6Z 6.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality occurs, the protection circuit will operate and reset the unit to stand by mode. During this time, the defective block can be identified by the number of blinking times of the Power LED on the front panel of the unit as follow:...

  • Page 13: Disassembly And Assembly Instructions

    TH-L24XM6Z 7 Disassembly and Assembly Instructions 7.1. LVDS and LED Assembly 1. Fix LCD PANEL, LED PANEL ( with board & wire ) to CABINET COMPLETE ASSY. 2. Fix LVDS CABLE and PET TAPE to LCD PANEL. < Caution Point >...

  • Page 14: Lcd Panel Fixing & Handling Method

    TH-L24XM6Z 7.2. LCD Panel Fixing & Handling Method 1. Place down the cabinet as shown below. 2. Fix LCD panel into the cabinet by taking below precautions. Other general precautions 1. Do not press panel surface to avoid blue spot on the panel display.

  • Page 15: Install Metal Chassis Frame

    TH-L24XM6Z 7.3. Installing Metal Chassis Frame 1. Fixing Metal CH Frame to LCD Panel. 2. Fixing screw to LCD Panel & Metal CH Frame at left bottom side. 3. Stick Barrier P (Peel off the separator) to Metal CH Frame.

  • Page 16: Small Part & Tightening Screw

    TH-L24XM6Z 7.4. Small Part & Tightening Screw 1. Insert P-print and A-print to Metal CH Frame. 2. Fixing small mechanical part to set (cabinet & metal ch.frame). 3. Fixing Key Indi Sheet to Key Button Bracket and slot at P-print board.
  • Page 17 TH-L24XM6Z Description Remarks SP UNIT SPEAKER BRACKET (R) SPEAKER BRACKET (L) SCREW (SP BRK4) 6 ± 1Kgf.cm SCREW 10.9 12 ± 2Kgf.cm LCD MTG SIDE SIDE AV BRACKET KEY BUTTON ASSY KEY BUTTON BRACKET KEY INDI SHEET...

  • Page 18: Pedestal Assembly

    TH-L24XM6Z 7.5. Pedestal Assembly Part no Description Remarks TBL5ZG30211 RUBBER FOOT TBL5ZB32861 BASE COVER TBL5ZB33111 STAND MOLD XTV3 + 12JFJK SCREW 6 ± 1Kgf.cm TPE4GB004 BAG FOR PEDESTAL...

  • Page 19: Measurements And Adjustments

    TH-L24XM6Z 8 Measurements and Adjustments 8.1. Voltage chart of A-board Set A-Board to a dummy set and check the satisfaction with the specified voltage as following table. Power Supply Name Measurement Point Specification PNL12V TP4097 12.1V ± 0.8V SUB3.3V TP5400 3.32V ±...

  • Page 20: Block Diagram

    TH-L24XM6Z 9 Block Diagram 9.1. Main Block Diagram XERWE0 XERWE0 STB5/5VS S12/S5 CPU BUS XECS1 CTRL AAR/DATA ERXW S5/ S3.3 (SD-Data-VCC) BOOTSWAP S9 REG S9-REG Analog XRST 3.3/1.8 ASIC XRSTSTM UHS-1 < (SDVOLC) AN34043A Only DTMB models(HK) STB3.3V/1.2V_REG Support < TV_SOS...

  • Page 21: Wiring Connection Diagram

    TH-L24XM6Z 10 Wiring Connection Diagram 10.1. Wire Dressing A15 ~ SP (R) A10 ~ KA10 Description Remarks CLAMPER PET TAPE 0.07 1 × 70mm PET TAPE 0.12 1 × 120mm...

  • Page 22: Schematic Diagram

    TH-L24XM6Z 11 Schematic Diagram Model No. : TH-L24XM6Z A-Board (1/18)
  • Page 23 Model No. : TH-L24XM6Z A-Board (2/18-1)
  • Page 24 Model No. : TH-L24XM6Z A-Board (2/18-2)
  • Page 25 Model No. : TH-L24XM6Z A-Board (3/18)
  • Page 26 Model No. : TH-L24XM6Z A-Board (4/18)
  • Page 27 Model No. : TH-L24XM6Z A-Board (5/18)
  • Page 28 Model No. : TH-L24XM6Z A-Board (6/18)
  • Page 29 Model No. : TH-L24XM6Z A-Board (7/18-1)
  • Page 30 Model No. : TH-L24XM6Z A-Board (7/18-2)
  • Page 31 Model No. : TH-L24XM6Z A-Board (8/18)
  • Page 32 Model No. : TH-L24XM6Z A-Board (9/18)
  • Page 33 Model No. : TH-L24XM6Z A-Board (10/18)
  • Page 34 Model No. : TH-L24XM6Z A-Board (11/18)
  • Page 35 Model No. : TH-L24XM6Z A-Board (12/18)
  • Page 36 Model No. : TH-L24XM6Z A-Board (13/18)
  • Page 37 Model No. : TH-L24XM6Z A-Board (14/18)
  • Page 38 Model No. : TH-L24XM6Z A-Board (15/18)
  • Page 39 Model No. : TH-L24XM6Z A-Board (16/18)
  • Page 40 Model No. : TH-L24XM6Z A-Board (17/18)
  • Page 41 Model No. : TH-L24XM6Z A-Board (18/18)
  • Page 42 Model No. : TH-L24XM6Z K-Board...
  • Page 43 Model No. : TH-L24XM6Z P-Board...

  • Page 44: Printed Circuit Board

    TH-L24XM6Z 12 Printed Circuit Board Model No. : TH-L24XM6Z A-Board (Top Component Side)
  • Page 45 Model No. : TH-L24XM6Z A-Board (Bottom Component Side)
  • Page 46 Model No. : TH-L24XM6Z K-Board...
  • Page 47 Model No. : TH-L24XM6Z P-Board (Top Component Side)
  • Page 48 Model No. : TH-L24XM6Z P-Board (Bottom Component Side)

  • Page 49: Exploded View And Replacement Parts List

    TH-L24XM6Z 13 Exploded View and Replacement Parts List 13.1. Exploded View and Mechanical Replacement Parts List Model No. : TH-L24XM6Z Parts Location...
  • Page 50 Model No. : TH-L24XM6Z Packing Exploded View...
  • Page 51 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks CAPACITOR C1958 F1G1E103A059 C 0.01UF 25V C2000 F1G1A105A047 C 1UF 10V C2014 F1K1E106A134 C 10UF, 25V C2023 F1G1C104A077 C 0.1UF 16V C2801 F1G1C1030008 C 0.01UF 16V...
  • Page 52 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C5404 F1J0J2260004 C 22 UF 6.3 V C5407 F1G1E333A059 C 0.033UF, 25V C5408 F1G1H222A830 C 2200PF, 50V C5411 F1G1H1020008 C 1000PF 50V C5420...
  • Page 53 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C7103 F1AAF471A019 C 470PF , 240V C7104 F1AAF471A019 C 470PF , 240V C7128 F1H1H103A219 470PF , 240V C7301A F2A2W6800013 C 0.01UF, 50V C7306...
  • Page 54 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C8107 F1J0G2260001 C 22 UF 4 V C8108 F1J0G2260001 C 22 UF 4 V C8109 F1G1E472A144 C 4700pF 25V C8110 F1H1C105A145 C 1 uF 16 V...
  • Page 55 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks D5191 B0ADCK000001 DIODE D5192 B0ADCK000001 DIODE D5193 B0ADCK000001 DIODE D5194 DA2J10100L DIODE D5195 DZ2J027M0L DIODE D6750 J0ZZB0000175 DIODE D6751 B0ZBZ0000203 DIODE D7101 ERZE08C621CD...
  • Page 56 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks L4904 G1C220MA0533 INDUCTOR L5400 G1C4R7ZA0311 INDUCTOR L5420 G1C6R8MA0533 INDUCTOR L5421 G1C220MA0445 INDUCTOR L6704 J0JYC0000464 BEAD CORE L6706 J0JYC0000464 BEAD CORE L6761 J0JYC0000464 BEAD CORE...
  • Page 57 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R0946 D0GA101JA039 M 100OHM, J, 1/16W R0948 D0GA101JA039 M 100OHM, J, 1/16W R0951 D0GA101JA039 M 100OHM, J, 1/16W R0952 D0GA102JA039 M 1KOHM, J , 1/16W...
  • Page 58 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R4722 D0GA103JA039 M 10KOHM,F,1/16W R4723 D0GA473JA039 M 47KOHM J. 1/10W R4724 D0GA102JA039 M 1KOHM, J , 1/16W R4725 D0GA473JA039 M 47KOHM J. 1/10W...
  • Page 59 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R5403 D1BB2871A106 M 2.87 KOHM,F.1/10 W R5404 D0GD100JA059 M 10 OHM,J,1/4W R5420 D0GAR00J0005 M 0 OHM, 1/16W R5421 D1BA3302A023 M 33KOHM,F. 1/16 W...
  • Page 60 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R7519 D0GB123ZA038 M 12KOHM, 1/10W R7520 D0GB332ZA038 M 3.3KOHM , 1/16W R7521 D0GD123JA052 M 12KOHM,J,1/8W R7523 D0GD473JA052 M 47KOHM,J,1/8W R7524 D0GB473JA072 M 47KOHM J 1/10W...
  • Page 61 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R8302 D0GA360JA023 M 36 OHM, J,1/16W R8303 D1BA6201A023 M 6.2 KOHM,F.1/16 W R8305 D1BA2491A023 M 2.49KOHM,F,1/16W R8306 D0GA360JA023 M 36 OHM, J,1/16W R8307...
  • Page 62 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks JA57 D0GDR00J0004 CHIP RESISTOR JA60 D0GDR00J0004 CHIP RESISTOR JA62 D0GDR00J0004 CHIP RESISTOR JK3101 K1U511D00002 AV TERMINAL JK3102 K1U307E00002 AV TERMINAL JK3103 K1U204D00004 AV TERMINAL...
  • Page 63 Model No. : TH-L24XM6Z Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks Exploded View K2CJ2YY00087 AC CORD L0AA10C00009 SPEAKER L5EDDYY00449 LCD PANEL N2QAYB000817 REMOTE TRANSMITTER TBL5ZX05931 PEDESTAL ASSY TBM4GD1391A MODEL NAME PLATE TKK5ZC50311 LED PANEL...
