VAIO C1 PictureBook
®
™
Computer User Guide
PCG-C1XS
®

Advertisement

Table of Contents
loading

Related Manuals for Sony PCG-C1XS Computer

Summary of Contents for Sony PCG-C1XS Computer

  • Page 1 VAIO C1 PictureBook ® ™ Computer User Guide PCG-C1XS ®...

  • Page 2: Notice To Users

    This product contains software owned by Sony and licensed by third parties. Use of such software is subject to the terms and conditions of license agreements enclosed with this product.
  • Page 3 VAIO PCG-C1XS PictureBook Computer. Record the serial number in the space provided here. Refer to the model and serial numbers when you call your Sony Service Center. Model Number: PCG-C1XS Serial Number:________________________ To prevent fire or shock hazard, do not expose your notebook computer to rain or moisture.
  • Page 4 For questions regarding your product or for the Sony Service Center nearest you, call 1-888-476-6972 in the United States or 1-800-961-7669 in Canada. The number below is for FCC related matters only. Declaration of Conformity Trade Name: SONY Model No: PCG-C1XS Responsible Party: Sony Electronics Inc.
  • Page 5 Repair of this equipment should be made only by a Sony Service Center or Sony authorized agent. For the Sony Service Center nearest you, call 1-888-4SONYPC (1-888-476-6972).
  • Page 6 You can return your unwanted lithium ion batteries to your nearest Sony Service Center or Factory Service Center. For the Sony Service Center nearest you call 1-888-476-6972 in the United States or 1-800-961-7669 in Canada NOTICE: The Industry Canada label identifies certified equipment.
  • Page 7 Repairs to certified equipment should be coordinated by a representative designated by the supplier. Equipment malfunctions or any repairs or alterations made by the user to this equipment may give the telecommunications company cause to request that the user disconnect the equipment.

  • Page 9: Table Of Contents

    Features ... 1 Unpacking Your VAIO C1 PictureBook Computer... 2 Manuals ...2 Software CDs ...3 Recovery CDs ...3 Other ...3 Locating the Controls and Connectors ... 5 Front...5 Left ...6 Right...7 Bottom ...7 Connecting a Power Source ... 8 Using the AC Adapter...8 Using Battery Power...9 Conserving Battery Power...
  • Page 10 Using the Pointing Device...22 VAIO Action Setup ...24 Jog Dial™ Control...24 Using the Jog Dial™ Control...26 Software that does not support the Jog Dial Control ...27 Internal Timer...28 AutoAlert E-mail Notification System...28 i.LINK Interface...28 Using the built-in MOTION EYE camera ...29 Capturing a still image...29 Using the Floppy Disk Drive ...33 Using PC Cards ...35...
  • Page 11 Troubleshooting ... 64 Power Management...71 Using the System and Application Recovery CDs... 72 Using the System Recovery CD(s)...72 Using the Application Recovery CD(s)...74 Hard Drive Partition...75 Specifications ... 76...

  • Page 13: Features

    Exceptional performance - Your computer includes a fast Intel processor. Portability - The rechargeable battery pack provides hours of use without AC power. Sony audio and video quality - A high-resolution LCD screen enables you to take advantage of today’s advanced multimedia applications, games, and entertainment software. ®...

  • Page 14: Manuals

    Remove the following hardware items from the box: ® The V AIO C1 PictureBook Computer User Guide (this manual) contains information on how to get the most from your computer, find help and solve common problems. It also includes product specifications. Read Me First contains Frequently Asked Questions, the most up-to- date information on using your computer, and software information.

  • Page 15: Recovery Cds

    ® Microsoft Word 2000 System Recovery CD(s) Application Recovery CD(s) ® Setting up your VAIO C1 PictureBook™ Computer (poster) Packet containing special product offers...
  • Page 17 This section describes how to start using your computer and how to use your computer’s internal and external devices, such as the pointing device and floppy disk drive.

  • Page 20: Other

    You can use either AC power or a rechargeable battery pack as a power source. Plug the cable attached to the AC adapter into the DC In connector on the computer. Plug one end of the power cord into the AC adapter. Plug the other end of the power cord into an AC outlet.
  • Page 21 You can use a battery pack as a source of power. The PCGA-BP51A battery pack that comes with your computer is not fully charged at the time of purchase. Follow the steps below to insert and charge the battery pack. Make sure the Lock lever on the bottom of the computer is in the release position.
  • Page 22 Connect the AC adapter to the computer. Insert the battery pack. The computer automatically charges the battery (the battery indicator light flashes in a double blink pattern as the battery charges). When the battery is 85 percent full, the battery indicator light turns off. This process takes approximately one and one half hours.
  • Page 24 Turn off the computer. Slide the release levers to the away from the computer. Insert the battery pack with the VAIO logo side facing down. See the manual that came with the battery pack for more information. position and slide the battery...
  • Page 25 When using the notebook computer with a battery, the LCD display and the hard drive can be set to switch off automatically to conserve battery power (Power Management function). For details, refer to page 41. The PowerPanel software supplied with the notebook computer allows you to make power conservation settings to suit your usage requirements.
  • Page 26 Lift the cover while holding the bottom of the computer firmly. Do not grasp the camera lens when opening the cover as this may damage the unit. Press the power button until the green power indicator light turns on. If necessary, adjust the brightness controls for the LCD display. To decrease the brightness, press Fn+F5 and then the down or left arrow key.
  • Page 27 Click the Start button on the Windows 98 taskbar. Click Shut Down at the bottom of the Start menu to display the Shut Down Windows dialog box. Select Shut down. Click OK. Wait for your computer to turn off automatically. The power indicator turns off.
  • Page 28 You can take advantage of Sony’s commitment to quality customer support and receive the following benefits by registering your computer with Sony: Extended Limited Warranty – Protect your investment. Extend your Warranty nine months for a total of 12 months from the original date of purchase when you register your computer.

  • Page 29: Front

    Your keyboard is very similar to a typewriter’s, but the keyboard has additional keys that perform specific computer-related tasks. Numeric keypad Contains the keys found on a typical calculator. area Use the numeric keypad area to type numbers or to perform mathematical calculations such as addition and subtraction.

  • Page 30: Left

    Escape key The Esc (Escape) key is used to cancel commands. Print Screen key The Print Screen key takes an electronic snapshot of the screen and places it in the Windows Clipboard. You can then paste the screen shot into a document and print it.
  • Page 31 + F1 Displays Windows Help. + Tab Switches the selected button on the taskbar. Displays Windows Explorer. Displays the Windows Find: All Files window to find a file or folder. This is the equivalent of selecting Find and then Files or Folders from the Start menu.
  • Page 32 Power Power on: lights green. System Idle mode: lights amber. System Suspend mode: flashes amber. Battery Indicates the status of the battery inserted in the computer. Hard disk Lights when data is read from or written to the hard drive. Do not enter System Suspend mode or turn off the computer when this indicator light is on.
  • Page 33 (ESC) System Suspend (F3) Speaker switch (F4) Speaker volume (F5) Brightness control (F7) Switch to the external display (F8) Switch to the TV (F12) System Hibernation Fn+D Video standby Fn+B Bass Boost Fn+S System Idle Puts the system into System Suspend mode, a power management state.
  • Page 34 The pointing device on the keyboard allows you to point to, select, drag, and scroll objects on the screen. Point Press the pointing device in a direction to place the pointer on an item or object. Click Press the left button once. Double-click Press the left button twice.
  • Page 35 You can take off the pointing device cover and replace it with the additional cover supplied with your computer.
  • Page 36 VAIO Action Setup manages the settings for your computer’s Jog Dial control and i.LINK interface. An overview of each of these functions is provided in the next few pages. For more information on changing the settings using VAIO Action Setup, right-click the Jog Dial control icon, , in the task tray and click Help Topics.
  • Page 37 Depending on the software you are using, you can select items from the displayed list using the Jog Dial control. Some Sony software applications have two modes in List View, Simple Menu and Full Menu. You can switch the mode by pressing the...
  • Page 38 This section explains how to use the Jog Dial control. For information on how to change the Jog Dial control’s settings, right-click the Jog Dial control icon in the task tray and click Help Topics. To use the Jog Dial control, click the Jog Dial control window or the Jog Dial control icon in the task tray.
  • Page 39 The Jog Dial control window displays the Jog Dial’s function. If Sony software that supports the Jog Dial control is active, you can use the Jog Dial’s functions that are allocated to that software. For more information on functions allocated to software, see the software applications online Help.
  • Page 40 Your computer comes equipped with an i.LINK port. The port is a digital interface (IEEE-1394) for high-speed communication. By using your ® computer, a Sony Digital Handycam Camcorder or other camera that supports the i.LINK interface, you can easily create and edit your own home videos.
  • Page 41 Your computer includes a built-in MOTION EYE camera. You can use the camera to shoot still images and record video clips. Press the CAPTURE button to start Smart Capture. Need Art Select Still Viewer/Movie Player from the application list. Choose Still by clicking the on-screen Capture Mode button. To switch to Motion, click the Capture Mode button again.
  • Page 42 The Finder window appears. Turn the MOTION EYE camera lens towards the subject you want to photograph. Adjust the focusing ring. Half-press the CAPTURE button on the computer. The image remains still for a few seconds. To display another image, release the CAPTURE button and press again.
  • Page 43 You can create panoramic images by connecting still images captured with the MOTION EYE camera. Capture the still images. Using the Panoramic-assist function of Smart Capture, capture still images to be used to create your panoramic image. For details, see Smart Capture online Help. Start the PictureGear software.
  • Page 44 Click Mode tab and click the item you want to set. Field/Frame Set according to the movement of subjects. White balance Adjust the colors to be more natural. Shutter speed Set the shutter speed: Click OK. Field: Suitable for moving subjects. Frame (interpolation): The middle mode between the Field mode and Frame mode.
  • Page 45 You can connect the floppy disk drive to the USB connector on your computer. Plug the USB cable on the floppy disk drive into the the computer. When using the disk drive, the VAIO logo should face up. Hold the diskette with the label side facing up. Gently push the diskette into the drive until it clicks into place.
  • Page 46 When you finish using the diskette, wait until the LED indicator turns off and then press the Eject button to remove the diskette. If the diskette does not come out by pressing the Eject button, disconnect the floppy disk drive from the computer. Wait until the LED indicator turns off, and then unplug the USB cable from the computer.
  • Page 47 Your computer includes a PC card slot. PC cards allow you to connect portable external devices, such as a CD-ROM drive, or to connect to a network. Insert the PC card into the PC card slot with the front label facing up. Gently push the card into the slot until it is fixed into the connector;...
  • Page 48 Pull the release button, then push it down toward the slot.
  • Page 49 Click the Start button, point to Settings, and then click Control Panel. Double-click PC card. Click the name of your PC card from the list that displays. Click the Stop button, and then OK. Push the release button. Gently grasp the card and pull it out.
  • Page 50 With Smart Connect you can copy, edit, or delete files on another VAIO computer (equipped with Smart Connect) that is connected to your ® computer with an i.LINK cable. You can also print a document on a printer that is connected to another VAIO computer.
  • Page 51 Your computer includes an infrared port, located on the right side of the computer. You can use this port to communicate with other infrared- equipped devices with compatible protocols, such as a digital still camera or other computers. Align the infrared ports on the computer and the digital camera so that they are in a direct line.
  • Page 53 When you use a battery as the source of power for your computer, you can take advantage of power management settings to conserve battery life. In addition to the normal operating mode, which allows you to turn off specific devices, your computer has two distinct power saving modes: System Suspend and System Hibernation.
  • Page 54 The state of the system is saved on the hard drive and power is turned off. The power indicator light is off in this mode. Press Fn+F12. You can also use the PowerPanel utility to enter System Hibernation mode. Turn on the computer by pressing the power button. The computer returns to its previous state.
  • Page 55 You can add functionality to your computer by connecting any of these peripherals: Phone line (page 44) Printer (page 46) External display (page 47) External USB mouse (page 55) CD-ROM drive (page 56) Digital video camera recorder (page 59)
  • Page 56 You need to connect a phone line (not supplied) to take advantage of online services and the Internet. Open the phone line jack cover. The cover opens only to a 45-degree angle. Plug one end of the phone cable into the jack on the inside of the phone line jack cover.
  • Page 57 Plug the other end into the wall jack.
  • Page 58 You can connect a printer that is compatible with Windows 98 to your computer. Plug the optional USB printer cable into the USB connector on your computer and the parallel port on your printer. To use a printer, first install the driver software that came with your printer.
  • Page 59 You can connect an external display to your VAIO C1 PictureBook Computer. For example, you can use the computer with either of the following: Computer display (monitor) (page 47) Projector (page 48) TV (page 49) Use the symbol to locate the mini VGA/TV Out connector. Connect the supplied adapter to the mini VGA/TV Out connector, then plug the display cable into the adapter.
  • Page 60 You can use a projector as an external display, such as the Sony LCD Projector. You can connect a projector using the supplied Display adapter. Plug the VGA adapter into the computer's mini VGA/TV Out connector and the display signal cable to the “VGA Out” connector of the Display adapter.
  • Page 61 Use the supplied display adapter to connect your TV monitor to the computer. Plug the supplied display adapter into the computer's mini VGA/TV Out connector and the video cable to the “TV Out” connector of the display adapter. Plug the other end of the video cable to the Video In connector of the TV.
  • Page 62 This notebook computer uses the NeoMagic video controller. You can select which display is used when the computer is connected to an external display. Click the Start button, select Settings, and then click Control Panel. The Control Panel appears. Click Display. Display Properties appears.
  • Page 63 Select the external display type: LCD panel The internal LCD panel. CRT/Projector An external computer display connected to the Monitor connector on the notebook or the power up station, or an RGB connected projector. A video monitor or television connected to the VIDEO or S VIDEO connector on the power up station.
  • Page 64 When the external display type is set to TV: The internal LCD display cannot be turned off. The content of both the LCD and the TV displays will be the same. The resolution can be set with the resolution slider to either 640×480 or 800×600 dots.
  • Page 65 Click Details in step 6 of Selecting a Display on the previous page. Advanced Settings appears. Select the display type. External display/device: Connection to an external computer display. Projector Connection to a projector. Set the refresh rate/resolution (for Independent display/Timing) When Independent display/Timing is selected in Monitor settings, you can set separate values for the refresh rate and resolution of the internal and external displays.
  • Page 66 If you selected TV in step 6 of “Selecting a Display” on page 50, you can change settings such as the TV format and the display position. Click Details in step 6 of “Selecting a Display” on page 50. Advanced Settings appears. Click the TV Options tab.
  • Page 67 You can connect an external USB mouse PCGA-UMS1 (optional) to your computer. Plug the mouse cable into the USB connector. PCGA-UMS1 driver has already been installed.

  • Page 68: Bottom

    You can use the optional PCGA-CD51 CD-ROM or PCGA-CDRW51 CD-RW drive with your notebook. If you use either optional drive when your computer is running on battery power, the battery life will be shorter. The drive draws power from the computer through a PC card. Remove the PC card slot protector from the PC card slot.
  • Page 69 Insert the PC card into the PC card slot with the SONY logo facing up. See “Using PC Cards” on page 35 for details. Push the Open button in the direction of the arrow to open the CD-ROM drive lid.
  • Page 70 Place the CD-ROM in the tray with the label side facing up. Push the disc onto the hub until the disc clicks into place. Gently slide the tray back into place.
  • Page 71 The VAIO C1 PictureBook Computer includes an i.LINK (IEEE-1394) connector, which you can use to connect to an i.LINK-enabled digital video camera recorder. Plug one end of an i.LINK cable into the S400 side of the computer and the other end into the DV In/Out connector on the digital video camera recorder.
  • Page 72 You can enhance the sound quality of your computer by connecting external speakers. Use the symbol to locate the Headphone connector. Plug the speaker cable into this connector.
  • Page 73 You can enhance the quality of sound input by using an external microphone. Use the m to locate the Microphone connector. Plug the microphone cable into this connector.

  • Page 74: Preinstalled Software

    Sony provides several support options for your Sony computer. When you have questions about your computer and the preinstalled software, check these sources for answers, in the following sequence: Read Me First ® V AIO PictureBook™ Computer User Guide Customizing ®...
  • Page 75 You can use this automated service to request a list of available topics and then select the topics that you want to receive. To contact the Sony fax-on-demand service, call 1-888-4SONYPC (1-888-476-6972). (Requires a fax machine or your fax software.)
  • Page 76 This section describes how to solve common problems you may encounter when using your computer. Many problems have simple solutions, so try these suggestions before you call Sony Customer Support. Check that the computer is plugged into a power source and that it is turned on.
  • Page 77 Remove the floppy disk drive, PC card, and any other peripheral devices from the computer. Turn the computer on again. Press the F2 key when the Sony logo appears. The BIOS setup menu screen appears. Press the arrow keys to select the Exit menu.
  • Page 78 If an external display is connected to the Monitor connector, disconnect the display. This is called a “drift” and is not a malfunction. The pointer stabilizes if you do not touch the pointing device for a few seconds. Check that you have not selected the press-select function. See “Changing the Pointing Device settings”...
  • Page 79 Make sure the label of the CD-ROM is facing up. If the CD-ROM requires software, make sure the software is installed according to the program’s instructions. Moisture condensation may have occurred. Disconnect the CD-ROM drive and disconnect the power to the drive for at least one hour. Make sure the CD-ROM drive is properly connected.
  • Page 80 The built-in speaker is turned off. Press Fn+F3 to turn on the speaker. The speaker volume is turned to the minimum. Press Fn+F4, and then press to increase the volume. If your computer is powered by the battery, check that the battery is connected properly and that it is charged.
  • Page 81 Unplug the computer from the AC adapter and remove the battery pack from your computer. Make sure the PC card is compatible with Windows 98. Use the Sony Notebook Setup utility to disable devices you are not currently using. Right-click the application bar of the PowerPanel software, right-click CPU Speed, and select OS Controlled.
  • Page 82 Shooting under fluorescent light may result in reflections. Red or green interference may occur if the imported images include dark parts. Check that the lens of the MOTION EYE camera is clean. Use the focus ring for focus adjustment. Double-click in the task tray.
  • Page 83 Check to see if you are using any other applications which use the MOTION EYE camera. If any of these applications are running, close them. Check the screen resolution and the color palette settings. These settings use video memory. Selecting lower settings releases video memory.
  • Page 84 The following sections describe how to use the System Recovery and Application Recovery utilities. You need to connect the optional PCGA- CD51 CD-ROM drive to use the System and Application Recovery CDs. You can reinstall software titles that shipped with your computer if they are corrupted or accidentally erased.

  • Page 85: Shutting Down Your Vaio C1 Picturebook Computer

    Slide the power switch forward and hold it for more than four seconds to turn off the computer. Turn on the computer and press the F2 key when the Sony logo appears. The BIOS setup menu screen appears. Press the arrow keys to select the Exit menu.
  • Page 86 72. Turn on your computer. If your computer is already on, close all applications. When the Windows desktop appears, insert the first Sony Application Recovery CD in the CD-ROM drive. The Application Recovery utility loads automatically. When the Application Recovery menu appears, follow the on-screen...
  • Page 87 In order to improve the performance of your computer’s DVgate™ Motion software, the hard disk drive on your computer has been formatted with two partitions. The C drive partition is approximately 8 GB, and the D drive partition is 4 GB. DVgate Motion saves files to the D partition.
  • Page 88 ® 400 MHz* Mobile Intel 12 GB 410,000 pixels (effective 380,000 pixels) 1/6 inch 410,000 pixel CCD 2 elements in 2 groups f = 2.8 mm, F = 2.8 Auto/Indoor/Outdoor/Hold Auto/ YUY2/RGB 24 bit Motion JPEG 30 frames/second maximum (overlay) 30 frames/second maximum (320x240 motion JPEG) 15 frames/second maximum (640x480 motion JPEG) 64 MB SDRAM, expandable to 128 MB...
  • Page 89 20% to 80% (not condensed) when that humidity is less than 65% at 95°F (35°C) (hygrometer reading of less than 84°F (29°C)) -4°F to 140°F (-20°C to 60°C) (temperature gradient less than 10% to 90% (not condensed) when that humidity is less than 20% at 140°F (60°C) (hygrometer reading of less than 95°F (35°C)) †...
  • Page 91 AC adapter AC power accessing online support adding hardware peripherals printers adjusting brightness Alt key Application Recovery CDs Applications key battery pack charging indicator light status indicator lights inserting loading power status rechargeable removing brightness adjusting built-in speaker volume buttons Open Start (Windows 98) cameras...
  • Page 92 infrared parallel printer correction keys Ctrl key cursor-movement keys customer assistance support options DC In digital still camera digital video camera diskettes ejecting inserting into drive troubleshooting disposal of lithium ion battery drives CD-ROM floppy disk DV In/Out Eject button ejecting diskettes electronic...

  • Page 93: Registering Your Computer

    Scroll Lock indicator light selecting power source Shift key Shut Down Windows dialog box Sony Fax-on-Demand service speakers connectors troubleshooting Start button starting computer startup problems switching display monitor System Hibernation mode...

  • Page 94: Vaio Action Setup

    System Suspend mode technical support support options troubleshooting startup turning on computer interference VAIO Action Setup video camera Video Standby mode warranty Windows 98 Control Panel Explorer Find window help key combinations Start button taskbar...
