LCD
Digital Color TV
Setup Guide
(Operating Instructions)
KDL-46EX523 / 46EX521 / 46EX520 / 40EX523 / 40EX521 / 40EX520 / 32EX523 / 32EX521
KDL-32EX520
4-267-385-12(1)
Getting Started
Using Your BRAVIA TV
Network Setup
Additional Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Please Do Not Return
the Product to the Store

Advertisement

Table of Contents
loading

Related Manuals for Sony BRAVIA KDL-32EX521

Summary of Contents for Sony BRAVIA KDL-32EX521

  • Page 1 KDL-46EX523 / 46EX521 / 46EX520 / 40EX523 / 40EX521 / 40EX520 / 32EX523 / 32EX521 KDL-32EX520 4-267-385-12(1) Getting Started Using Your BRAVIA TV Network Setup Additional Information Sony Customer Support U.S.A.: www.sony.com/tvsupport Canada: www.sony.ca/support United States Canada 1.800.222.SONY 1.877.899.SONY Please Do Not Return...
  • Page 2 “BRAVIA” and , S-Force, BRAVIA Sync, and are trademarks or registered marks of Sony Corporation. “PlayStation” is a registered trademark and “PS3” is a trademark of Sony Computer Entertainment Inc. ® DLNA , the DLNA Logo and DLNA ® CERTIFIED...
  • Page 3 ® The BRAVIA Full HDTV Experience Thank you for choosing Sony! Your new ® BRAVIA TV opens the door to the “Full HDTV Experience.” This document will help you get the most out of your TV. Please take a moment to register your TV at: U.S.A.: http://productregistration.sony.com...

  • Page 4: Table Of Contents

    Table of Contents Getting Started Checking the accessories ... 6 Inserting batteries into the remote control... 6 Before setting up your TV ... 7 1: Attaching the Table-Top Stand ... 7 2: Adjusting the viewing angle of the TV ... 8 3: Connecting the TV ...

  • Page 5: Parts Description

    After setting up your BRAVIA TV and learning basic operations with this manual, see the built-in manual (i-Manual) for further explanation of the features of your TV. This TV has a built-in manual (i-Manual). To access the i-Manual, press i-MANUAL on the remote control, and select an item.

  • Page 6: Getting Started

    Getting Started Checking the accessories Remote control (1) Size AAA batteries (2) Table-Top Stand (1) Fixing screws for Table-Top Stand (M5 × 16) (3) Assembling screws for Table-Top Stand (M6 × 14) (4) (for KDL-46EX52x) Assembling screws for Table-Top Stand (M6 × 14) (3) (for KDL-40/32EX52x except KDL-40/32EX521 (Mexico models)) Assembling screws for Table-Top...

  • Page 7: Before Setting Up Your Tv

    Before setting up your TV Some TV models are packaged with a detached Table-Top Stand so you can mount your TV to a wall right away. If you are not mounting the TV to a wall, you will need to attach the Table-Top Stand. You will need a Phillips screwdriver and the supplied screws to complete the task.

  • Page 8: 2: Adjusting The Viewing Angle Of The Tv

    B KDL-40/32EX521 (Mexico models) Guide pins • Align the TV from the top, slide it in until the guide pins cannot be seen. Use the supplied screws to attach the TV unit to the Table-Top Stand. B KDL-46/40/32EX52x (except KDL-40/32EX521 (Mexico models)) B KDL-40/32EX521 (Mexico models) •...

  • Page 9: 3: Connecting The Tv

    B KDL-40/32EX521 (Mexico models) 15° 15° Angle adjustment (Tilt) • Be careful not to pinch your fingers between the TV and stand when adjusting the angle. B KDL-46/40/32EX52x (except KDL-40/32EX521 (Mexico models)) B KDL-40/32EX521 (Mexico models) 0° 3: Connecting the TV 15°...
  • Page 10 Shown with a Set Top Box with COMPONENT connection Set Top Box Shown with HD BRAVIA **Optical *Rear of TV * Signifies a BRAVIA Sync capable device. ** The optical connection is only needed for A/V receivers that do not support ARC (Audio Return Channel).
  • Page 11 Shown with HD Basic Connection with Home Theater System Rear of TV Cable/ Antenna * The optical connection is only needed for A/V receivers that do not support ARC (Audio Return Channel). Shown with PC Connection with SD VCR/DVD Rear of TV Splitter Cable/Antenna Home Theater System...

  • Page 12: 4: Securing The Tv

    An alternative way to secure the TV is with an optional Sony Support Belt Kit. Screw hole on the Table-Top Stand Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name. • For United States call: 1-800-488-7669 or visit: www.sony.com/accessories...

  • Page 13: 5: Bundling The Cables

    Anchor the TV to the Wall. Anchor the TV to the wall by using bolts, wall anchor and chain (or rope). Anchor bolts (M6) (not supplied) Wall- mount holes • Your TV is shipped with screws attached to the rear of the TV depending on the TV model. (They are fastened in the screw holes for wall mounting.) Be sure to remove the upper two screws prior to anchoring the TV on a wall.

  • Page 14: 6: Running Initial Setup

    For product protection and safety reasons, Sony strongly recommends that you use the Wall-Mount Bracket designed for your TV and the installation should be performed by a Sony dealer or licensed contractor. • Follow the instruction guide provided with the Wall-Mount Bracket for your model.

  • Page 15: Installing The Tv Against A Wall Or Enclosed Area

    • Be sure to use the screws supplied with the Wall-mount bracket when attaching the mounting hooks to the TV set. The supplied screws are designed so that they are 8 mm to 12 mm in length when measured from the attaching surface of the mounting hook.

  • Page 16: Using Your Bravia Tv

    Using Your BRAVIA TV Watching the TV GUIDE Turn on the TV. Press 1 (power) on the TV or I/1 on the remote control to turn on the TV. Select a TV channel or select an input. To use the Guide Press GUIDE to display the Rovi On Screen Guide to view scheduled programs or to select a program to watch.
  • Page 17 Parts and controls of the remote control Use the supplied remote control to control your TV. Basic remote control operations are explained here. For details on all of the remote control functions, press i-MANUAL and see the built-in manual (i-Manual) (page 20). 1 :/1 Press to turn the TV on and off from standby mode.

  • Page 18: Selecting Various Functions And Settings (Home Menu)

    Selecting various functions and settings (Home Menu) You can select the features of your TV from the Home menu. See page 19 for the Home menu map. 1, 3 Press HOME. Press F/f/G/g/ To select items in the Home menu (e.g., selecting “Settings”) 1 Press G/g to select Settings.
  • Page 19 Home menu map After pressing HOME on the remote control, following icons are displayed as categories. The categories are available depending on your TV model, region, country and broadcasting conditions. Media Inputs Favorites/History Settings Widgets Applications Qriocity Internet Content Recommendations You can select a list of TV channels, or a program guide.

  • Page 20: Displaying Operating Instructions (I-Manual)

    Displaying Operating Instructions (i-Manual) Operating instructions are built into your BRAVIA TV and can be displayed on the screen. To learn more about your TV features, access your i-Manual with the touch of a button. Press i-MANUAL. Press F/f/G/g/ select items. To select items in the i-Manual 1 Press F/f to select an item.
  • Page 21 Description of the i-Manual screen To use the bookmark The i-Manual has a bookmark function. Pages can be bookmarked with the color buttons, according to the instructions at the bottom of the screen. To access your registered bookmarks, go to the top page of the i-Manual and select Bookmarks. To memorize the last displayed page i-Manual memorizes the last displayed page.

  • Page 22: Network Setup

    Network Setup When you connect this TV to the Internet, you can enjoy multiple functions: displaying a photograph that shows its location on the map, enjoying Internet video, etc. For details on the functions, refer to the i-Manual. • You will need to contract with an Internet service provider to connect to the Internet.

  • Page 23: Setting Up The Internet Connection

    Setting up the Internet connection Using the network feature you can connect the TV to the Internet. The setup procedure differs depending on the type of network and LAN router. Before setting up the Internet connection, be sure to set up a LAN router.

  • Page 24: If You Cannot Connect To The Internet

    Select Scan, then select a network from the list of scanned wireless networks. Follow the instructions on the setup screen. • If you use WPS for network setup, the security settings of the wireless LAN router activate, and any equipment previously connected to the wireless LAN in a non-secure status will be disconnected from the network.

  • Page 25: Adjusting The Server Display Settings

    Select Check Connection. This may take several minutes. You cannot cancel the diagnostic after selecting Check Connection. Adjusting the server display settings You can select home network servers to be displayed on the Home Menu. Up to 10 servers can be displayed in the Home Menu automatically.

  • Page 26: Additional Information

    When the 1 (standby) indicator is flashing, count how many times it flashes (interval time is three seconds). Press 1 (power) on the TV to turn it off, disconnect the AC power cord, and contact Sony Customer Support (information provided on the front cover) with how many times the indicator flashes.

  • Page 27: How To Care For Your Bravia

    Condition Explanation/Solution The remote control does • Replace the batteries. • Your TV may be in SYNC mode. Press SYNC MENU, not function. The TV and its • When the TV is used for an extended period of time, the TV surrounding become warm.

  • Page 28: Specifications

    Specifications System Television system Channel coverage Panel system Speaker output Input/Output jacks CABLE/ANTENNA VIDEO IN 1/2 COMPONENT IN HDMI IN 1/2/3/4 AUDIO OUT/Headphones DIGITAL AUDIO OUT (OPTICAL) PC IN PC/HDMI 4 AUDIO IN USB/DLNA Model name KDL- Power and others Power requirement Power consumption in use...
  • Page 29 Model name KDL- 46EX52x Operating temperature 32 °F - 104 °F (0 °C - 40 °C) *1 Except KDL-40EX521 (Mexico model). *2 Mexico model. *3 Except KDL-32EX521 (Mexico model). *4 Download Acquisition Mode (DAM) is used for software updates and/or collecting data for Rovi On Screen Guide.

  • Page 30: Declaration Of Conformity

    TV model and download “Additional Information for Using Sony Wall-Mount Bracket”. To Customers Sufficient expertise is required for TV installations. Be sure to subcontract the installation to a Sony dealer or licensed contractor and pay adequate attention to safety during the installation.
  • Page 32 Online Registration: Software Updates: © 2011 Sony Corporation Printed in U.S.A. For Your Convenience Be sure to register your TV. United States http://productregistration.sony.com Canada http://www.SonyStyle.ca/registration Your TV is capable of receiving software updates. For the latest information about software updates for your TV, visit: United States http://www.sony.com/tvsupport...
