LCD
Digital Color TV
Setup Guide
(Operating Instructions)
KDL-60NX720 / 55HX820 / 55NX720 / 46HX820 / 46NX720
XBR-55HX929 / 46HX929
4-270-401-11(1)
Getting Started
Using Your BRAVIA TV
Network Setup
Additional Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Please Do Not Return
the Product to the Store

Advertisement

Table of Contents
loading

Related Manuals for Sony Bravia KDL-60NX720

Summary of Contents for Sony Bravia KDL-60NX720

  • Page 1 Network Setup Setup Guide (Operating Instructions) Additional Information Sony Customer Support U.S.A.: www.sony.com/tvsupport Canada: www.sony.ca/support United States Canada 1.800.222.SONY 1.877.899.SONY Please Do Not Return the Product to the Store KDL-60NX720 / 55HX820 / 55NX720 / 46HX820 / 46NX720 XBR-55HX929 / 46HX929...

  • Page 2: Model Name

    Corporation. (such as a pediatrician or eye doctor) “PlayStation” is a registered trademark before allowing young children to and “PS3” is a trademark of Sony watch 3D video images or play Computer Entertainment Inc. stereoscopic 3D games. Adults should supervise young children to ensure they follow the recommendations listed above.
  • Page 3 Your BRAVIA TV is ENERGY STAR ® qualified in the “Home” mode. It meets strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and Department of Energy. ENERGY STAR is a joint program of these government agencies, designed to promote energy efficient products and practices.
  • Page 4 Full HDTV • Receive over-the-air HD broadcasts with Experience an HD-quality antenna connected directly to the back of your TV. Thank you for choosing Sony! Your new Visit www.antennaweb.org for more ® BRAVIA TV opens the door to the “Full information on antenna selection and setup.

  • Page 6: Table Of Contents

    Table of Contents Getting Started Checking the accessories ................... 8 Inserting batteries into the remote control..............8 Before setting up your TV ................... 9 1: Attaching the Table-Top Stand ................10 2: Adjusting the viewing angle of the TV ..............11 3: Connecting the TV ....................

  • Page 7: Troubleshooting

    After setting up your BRAVIA TV and learning basic operations with this manual, see the built-in manual (i-Manual) for further explanation of the features of your TV. This TV has a built-in manual (i-Manual). To access the i-Manual, press i-MANUAL on the remote control, and select an item.

  • Page 8: Getting Started

    Remote control (1) Size AAA batteries (2) Table-Top Stand (1) Fixing screws for Table-Top Stand (M5 × 16) (3) (except KDL-60NX720) Assembling screws for Table-Top Stand (M6 × 14) (4) Hexagon wrench (1) Video/Component Adapter (1) Operating Instructions (this manual)

  • Page 9: Before Setting Up Your Tv

    • If you are having problems with the • Avoid moving the TV from a cold area remote control, reinsert or replace your to a warm area. Sudden room batteries and make sure that they are temperature changes may cause moisture correctly inserted.

  • Page 10: 1: Attaching The Table-Top Stand

    For KDL-60NX720 1: Attaching the Table-Top Align with the two dowels of the Stand Table-Top Stand, and gently place the TV, checking that the f mark is Refer to the supplied Table-Top Stand facing the front. instruction leaflet for proper attachment.

  • Page 11: 2: Adjusting The Viewing Angle Of The Tv

    This TV can be adjusted within the angles TV, remove the screws fixed in step 2. as illustrated. For KDL-60NX720, be sure to remove the screws for detaching the head when the Angle adjustment (Swivel) Table-Top Stand is not attached to the TV.

  • Page 12: 3: Connecting The Tv

    Shown with a Set Top Box with 3: Connecting the TV COMPONENT connection • Use an antenna cable connector no greater than 14 mm thick. • Use an HDMI cable connector within 12 mm (thickness) × 21 mm (width). Shown with a Set Top Box with HDMI connection Video/Component Adapter (supplied)
  • Page 13 Cable System or VHF/UHF Antenna System Cable or Antenna ® Shown with HD BRAVIA Sync™ Basic Connection *Side Panel *A/V Receiver *Rear of TV *Blu-ray Disc **Optical HD Cable Box or Connection HD Satellite Receiver (Dish) Cable/ Antenna * Signifies a BRAVIA Sync capable device. ** The optical connection is only needed for A/V receivers that do not support ARC (Audio Return Channel).
  • Page 14 Shown with HD Basic Connection with Home Theater System *Optical Side Panel Connection Rear of TV Home Theater System Cable/ Blu-ray Disc/DVD Antenna Video/Component Adapter Cable/SAT (Dish) SD Cable Box or SD Satellite Receiver * The optical connection is only needed for A/V receivers that do not support ARC (Audio Return Channel).

  • Page 15: 4: Securing The Tv

    – slippery, unstable and/or uneven an optional Sony Support Belt Kit. The surfaces. Sony Support Belt Kit is available as an – furniture that can easily be used as optional accessory, depending on your TV steps, such as a chest of drawers.

  • Page 16: 5: Bundling The Cables

    5: Bundling the cables Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name. • Before bundling the cables, remove the cable • For United States call: 1-800-488-7669 or holder from the AC cover (see step 1 and 2).

  • Page 17: Using A Wall-Mount Bracket

    • Home mode sets the TV to settings optimized designed for your TV and the installation for home viewing (this setting is ENERGY should be performed by a Sony dealer or STAR compliant). licensed contractor. • Refer to “Compatible optional accessories information”...

  • Page 18: Installing The Tv Against A Wall Or Enclosed Area

    • Be sure to use the screws supplied with Installing the TV Against a the Wall-mount bracket when attaching Wall or Enclosed Area the mounting hooks to the TV set. The supplied screws are designed so that Make sure that your TV has adequate they are 8 mm to 12 mm in length when ventilation.

  • Page 20: Using Your Bravia Tv

    Using Your BRAVIA TV Watching the TV Turn on the TV. 1 Check the ENERGY SAVING switch is set to on (z). 2 Press 1 (power) on the TV or I/1* on the remote control to turn on the TV. (You may use the I/1* button located on the front or back of the remote control.) * Button name differs by the remote...
  • Page 21 Parts and controls of the remote control Use the supplied remote control to control your TV. Basic remote control operations are explained here. For details on all of the remote control functions, press i-MANUAL and see the built-in manual (i-Manual) (page 24). 1 :/1 Press to turn the TV on and off from standby mode.

  • Page 22: Selecting Various Functions And Settings (Home Menu)

    Selecting various functions and settings (Home Menu) You can select the features of your TV from the Home menu. See page 23 for the Home menu map. Press HOME. Press F/f/G/g/ to select items. 1, 3 To select items in the Home menu (e.g., selecting “Settings”) 1 Press G/g to select Settings.
  • Page 23 Home menu map After pressing HOME on the remote control, following icons are displayed as categories. The categories are available depending on your TV model, region, country and broadcasting conditions. You can select a list of TV channels, or a program guide.

  • Page 24: Displaying Operating Instructions (I-Manual)

    Displaying Operating Instructions (i-Manual) Operating instructions are built into your BRAVIA TV and can be displayed on the screen. To learn more about your TV features, access your i-Manual with the touch of a button. Press i-MANUAL. Press F/f/G/g/ to navigate and select items.
  • Page 25 Description of the i-Manual screen Press G to go back to the previous page Press f to go to the next page Page number/Total number of pages Press RETURN to go back to the previous page Press to launch the function •...

  • Page 26: Programming The Remote Control (For Rm-Yd057 And Rm-Yd067 Remote Control Users)

    1 Look for the code in the Manufacturer’s Code List (refer to i-Manual) that corresponds to the equipment you would like to operate with the Sony remote control. If more than one code is provided, try programming the first code listed. If your equipment’s code is not listed, visit...

  • Page 27: Network Setup

    Network Setup When you connect this TV to the Internet, Preparing a wireless LAN you can enjoy multiple functions: displaying a photograph that shows its The built-in wireless LAN device allows location on the map, enjoying Internet you to access the Internet and your home video, etc.

  • Page 28: Setting Up The Internet Connection

    Type 1: Secured network with Setting up the Internet Wi-Fi Protected Setup (WPS) connection The WPS standard makes security of a Using the network feature you can connect wireless home network as straightforward the TV to the Internet. The setup procedure as pressing the WPS button on the wireless differs depending on the type of network LAN router.

  • Page 29: If You Cannot Connect To The Internet

    Select Scan, then select a network Type 4: Wired network setup from the list of scanned wireless Enter the respective alphanumeric values networks. for your router if necessary. The items that Follow the instructions on the setup need to be set (e.g. IP Address, Subnet screen.

  • Page 30: Adjusting The Server Display Settings

    Select Check Connection. This may take several minutes. You cannot cancel the diagnostic after selecting Check Connection. Adjusting the server display settings You can select home network servers to be displayed on the Home Menu. Up to 10 servers can be displayed in the Home Menu automatically.

  • Page 31: Additional Information

    When the 1 (standby) indicator is flashing, count how many times it flashes (interval time is three seconds). Press 1 (power) on the TV to turn it off, disconnect the AC power cord, and contact Sony Customer Support (information provided on the front cover) with how many times the indicator flashes.

  • Page 32: How To Care For Your Bravia

    Condition Explanation/Solution The remote control does • Replace the batteries. • Your TV may be in SYNC mode. Press SYNC MENU, not function. select TV Control and then select Home (Menu) or Options to control the TV. • When the TV is used for an extended period of time, the TV The TV and its and its surroundings may become warm to touch.

  • Page 33: Specifications

    Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel Speaker output 10 W + 10 W + 10 W + 10 W (for KDL-60NX720) 10 W + 10 W + 10 W (except KDL-60NX720) Input/Output jacks CABLE/ANTENNA...
  • Page 34 23.1 / 50.9 Supplied accessories See “Checking the accessories” (page 8). Optional accessories Connecting cables Support Belt Kit Wall-Mount Bracket: SU-WL700 (except KDL-60NX720) SU-WL500 Wall-Hanging Bracket: SU-WH500 TV Stand: SU-B551S (XBR-55HX929, KDL-55HX820, KDL-55NX720) 3D Glasses: TDG-BR250/TDG-BR200/TDG-BR100/TDG-BR50 USB Wireless LAN Adapter Operating temperature 32 ºF –...
  • Page 35 Some of these TV stand models may not be available in your area. To Customers Sufficient expertise is required for TV installations. Be sure to subcontract the installation to a Sony dealer or licensed contractor and pay adequate attention to safety during the installation.

  • Page 36: Software Updates

    TV, visit: United States http://www.sony.com/tvsupport Software Canada http://www.sony.ca/support Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by selecting Settings, Product Support and then Automatic Software Update. © 2011 Sony Corporation Printed in U.S.A.
  • Page 37 4-270-904-11(1) 32, 37, 40 46, 55 3 N•m {30 kgf•cm} © 2011 Sony Corporation...
  • Page 38 1.5 N•m/1,5 N•m {15 kgf•cm} 6° 0°...
