SAFETY INSTRUCTIONS ................................................................................
GENERAL INFORMATION ..............................................................................
Introduction ......................................................................................................................
Definitions........................................................................................................................
Typographical conventions ..............................................................................................
Machine and Manufacturer's identification data ..............................................................
Equipment identification ..................................................................................................
B5.1
How to identify the technical data........................................................................
B5.2
How to interpret the factory description...............................................................
Copyright .........................................................................................................................
Liability.............................................................................................................................
Personal Protection Equipment .......................................................................................
Keeping the manual.........................................................................................................
Users of the manual ........................................................................................................
C
GENERAL SAFETY RULES ............................................................................
Introduction......................................................................................................................
Protection devices installed on the machine .......................................................
Safety signs to be placed on the machine or near the work area........................
Decommissioning ............................................................................................................
Instructions regarding use and maintenance...................................................................
Foreseeable improper use...............................................................................................
Residual risks ..................................................................................................................
D
GENERAL DESCRIPTION OF MACHINE .......................................................
General description .........................................................................................................
E
TECHNICAL DATA ...........................................................................................
Main technical characteristics..........................................................................................
Power supply characteristics ...........................................................................................
TRANSPORT, HANDLING AND STORAGE....................................................
Introduction......................................................................................................................
Transport: Instructions for the carrier...................................................................
Handling ..........................................................................................................................
Procedures for handling operations.....................................................................
Shifting ................................................................................................................
Placing the load ...................................................................................................
Storage ............................................................................................................................
G
INSTALLATION AND ASSEMBLY ...................................................................
Customer responsibilities ................................................................................................
Characteristics of the place of installation .......................................................................
Positioning .......................................................................................................................
Disposal of packaging .....................................................................................................
Plumbing connections .....................................................................................................
CONTENTS
Guards ..............................................................................................
Page 5
Page 6
Page 6
Page 6
Page 6
Page 7
Page 7
Page 7
Page 7
Page 7
Page 8
Page 8
Page 8
Page 8
Page 9
Page 9
Page 9
Page 9
Page 9
Page 9
Page 9
Page 10
Page 10
Page 11
Page 11
Page 11
Page 11
Page 12
Page 13
Page 13
Page 13
Page 13
Page 13
Page 13
Page 13
Page 13
Page 14
Page 14
Page 14
Page 14
Page 15
Page 15
3
Advertisement
Table of Contents
Related Manuals for Electrolux EGWSSIC
Summary of Contents for Electrolux EGWSSIC
-
Page 1: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ................Page 5 GENERAL INFORMATION ................Page 6 Introduction ........................Page 6 Definitions........................Page 6 Typographical conventions ....................Page 6 Machine and Manufacturer's identification data .............. Page 7 Equipment identification ....................Page 7 B5.1 How to identify the technical data................ Page 7 B5.2 How to interpret the factory description............... - Page 2 Electrical connections ...................... Page 15 G6.1 Safety devices ..................... Page 16 Installation diagram......................Page 16 DESCRIPTION OF CONTROL PANEL ............Page 17 Basic controls ........................Page 17 COMMISSIONING..................... Page 18 Preliminary checks, adjustments and operational tests ........... Page 18 I1.1 Electrical and plumbing checks ................
-
Page 3: Asafety Instructions
Foreword The instruction manual (hereinafter Manual) provides the operator with useful information for working cor- rectly and safely, facilitating him in using the machine (hereinafter “machine”, “dishwasher” or “equipment”). The following must not be considered a long and exacting list of warnings, but rather a set of instructions suitable for improving machine performance in every respect and, above all, preventing injury to persons and animals and damage to property due to improper operating procedures. -
Page 4: Bgeneral Information
Manufacturer The following symbols are used in the manual to indi- Electrolux Professional S.p.A. or any other assistance cate and identify the various types of hazards: centre authorised by Electrolux Professional S.p.A. ATTENTION! -
Page 5: B4 Machine And Manufacturer's Identification Data
Descrizione variabili 2016 F.Mod. EGWSSIC Comm. Model EGWSSIC (1) Brand Z = Zanussi, E = Electrolux, N = To Brand, X = KxT. 9CGX 402125 00 Ser.Nr. 60210001 AC 230V 1N 50 Hz 3.3 kW (2) Machine type GW = Glass washer... -
Page 6: B7 Liability
(1) Use heat resistant gloves suitable for contact with use. water and the substances used (see the safety data Electrolux Professional S.p.A. declines any liability for sheet of the substances used to check other possible any inaccuracies contained in the manual, if due to PPE). -
Page 7: General Safety Rules
GENERAL SAFETY RULES Introduction ATTENTION! The machines are provided with electric and/or Do not remove, tamper with or mechanical safety devices for protecting workers and the machine itself. Therefore the user must not remove make labels or tamper with such devices. machine illegible. -
Page 8: C4 Foreseeable Improper Use
Nevertheless, through this manual the Manufacturer ATTENTION! has taken steps to inform operators of such risks, care- Before carrying out any opera- fully indicating the personal protection equipment to be used by them. tion on the machine, always Sufficient spaces are provided for during the machine consult the manual, which installation stages in order to limit these risks. -
Page 9: General Description Of Machine
6. Salt container cap 7. Lower rinse arm 8. Tank filter 9. Overflow 10.Adjustable feet 11.Screw for adjusting rinse aid quantity TECHNICAL DATA Main technical characteristics MODEL EGWSSIC - EGWSIC... - EGWSICWG...U EGWS...3 EGWSICGMS - ZWGSSIC ZGWSIC... - NGWSIC..U ZGWSICGMS - NGWSIC... -
Page 10: E2 Power Supply Characteristics
Power supply characteristics The AC power supply to the machine must meet the following conditions: • max. voltage variation ± 10% • max. frequency variation ± 1% continuous ± 2% for a short period. Harmonic distorsion, unbalanced three-phase supply voltage, voltage pulses, interruption, dips and the other electric characteristics must respect the provisions of par. -
Page 11: Ftransport, Handling And Storage
TRANSPORT, HANDLING AND STORAGE Introduction • handle the machine, keeping it at minimum height from the ground. Transport (i.e. transfer of the machine from one place to another) and handling (i.e. transfer inside work- ATTENTION! places) must occur with the use of special and ade- quate means. -
Page 12: Installation And Assembly
INSTALLATION AND ASSEMBLY Positioning ATTENTION! The machine must be taken to the place of installation Machine installation opera- and the packing base removed only when being installed. tions must only be carried out Arranging the machine: specialised Technicians • Wear protective gloves and unpack the machine provided with all the appropri- (Figure 4). -
Page 13: G4 Disposal Of Packaging
ATTENTION ATTENTION If the equipment is replaced, always use the new inlet hose provided. Be sure that the non-return valve “B” and the filter supplied are fitted correctly as shown in Figure 8. • Make sure the dynamic pressure of the water sup- ply, measured upstream of the equipment, is between 180 and 300 kPa (the tests must be car- ried out while the dishwasher is filling water in the... -
Page 14: G6.1 Safety Devices
• Do not pull the mains cable to disconnect the appli- G6.1 Safety devices ance. Always pull the mains plug. • An automatic-reset overload protector incorpo- • Do not touch the mains cable or the mains plug with rated in the electric pump windings cuts off the wet hands. -
Page 15: Hdescription Of Control Panel
DESCRIPTION OF CONTROL PANEL Legend A = ON/OFF button E = "Tank temperature" indicator H = Wash cycle 2 B = Softener regeneration cycle = "Boiler temperature" = Wash cycle 1 with cold rinse C = Drain / self-cleaning cycle indicator D = Display G = Wash cycle 1... -
Page 16: Commissioning
COMMISSIONING Preliminary checks, adjustments and Detergent/rinse aid dispensers and operational tests prearrangements If the machine is connected to a water softener and/or I1.1 Electrical and plumbing checks a reverse osmosis system, contact the detergent sup- Before starting the machine, it is necessary to: plier for a specific product. -
Page 17: I3.2.1 Detergent Dispenser Manual Activation
Info If changing to a different type of detergent rinse aid (even the same brand), it is necessary to rinse the inlet and outlet pipes with clean water before connecting the new detergent/rinse aid container. Otherwise, the Amount of detergent during the cycle: mixing of different types of detergent/rinse causes a crystallization, with possible breakage of the dosing pump. -
Page 18: Normal Machine Use
NORMAL MACHINE USE Foreseen use Our appliances are designed and optimised to ensure high performance and efficiency. This equipment must only be used for its expressly designed purpose, i.e. washing dishes with water and specific detergents. Any other use is deemed improper. •... -
Page 19: J6 Operation
• Cycle 1 with final a cold rinse, 120 seconds: it corresponds to a 90 second wash cycle with hot water and detergent, a pause of 4 seconds, a 16 second rinse cycle with hot water and shining prod- uct and a cold rinse of 10 seconds. - Page 20 Degrees of water hardness Level Characteristic Degrees °fH °dH °cH soft 0 - 5.5 0 - 3 0 - 4 medium 7 - 14 4 - 8 5 - 10 hard 16 - 26.5 9 - 15 11- 18.6 very hard >...
-
Page 21: J8 Machine Cleaning
Machine cleaning For the models with drain pump, remove the overflow pipe from its housing and press the but- ATTENTION! ton “Drain / self-cleaning cycle (C)” until the washing tank is empty. Before carrying out any main- • Press button A to switch off the machine. tenance operations, turn off •... -
Page 22: J8.2 Long Idle Periods
Maintenance ATTENTION ATTENTION Machine maintenance operations must only be carried out by specialised Technicians provided with all the appropriate personal protection equip- ment (safety shoes, gloves, glasses, overalls, etc.), tools, utensils and ancillary means The inspection and maintenance intervals depend on the actual machine operating conditions (total wash hours) and ambient conditions (presence of dust, damp, etc.), therefore precise time intervals cannot be... -
Page 23: J11 Troubleshooting
Troubleshooting CONDENSATE ON GLASSES 1. Make sure there is rinse aid in the container and top- THE DISHWASHER DOES NOT SWITCH ON up if necessary. 1. Make sure the socket is powered. 2. Check the amount of rinse aid used (see paragraph 2.
